Page 3961 of 5121

NISSAN TEANA 2008 Service Manual FRONT SEAT SE-97 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] C D E F G H I K L MA B SE N O P Remove the screws (C), and then remove seat cushion duct A (1) and B (2). 2. Remove the clip, seatback duc

Page 3962 of 5121

NISSAN TEANA 2008 Service Manual SE-98 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] REAR SEAT REAR SEAT Exploded ViewINFOID:0000000003809278 1. Seat harness 2. Cup holder 3. Bushing 4. Armrest bracket 5. Armrest assembly 6. Seat heat

Page 3963 of 5121

NISSAN TEANA 2008 Service Manual REAR SEAT SE-99 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] C D E F G H I K L MA B SE N O P Removal and InstallationINFOID:0000000003809279 REMOVAL CAUTION: When removing and installing, use shop clo

Page 3964 of 5121

NISSAN TEANA 2008 Service Manual SE-100 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] REAR SEAT  Lift up seatback from underneath, and then remove seatback from seatback hook that is fixed to the vehicle.  Remove the seatback from t

Page 3965 of 5121

NISSAN TEANA 2008 Service Manual REAR SEAT SE-101 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] C D E F G H I K L MA B SE N O P  Remove the headrest holder. CAUTION: Before installing headrest holder, check its orientation (front/rea

Page 3966 of 5121

NISSAN TEANA 2008 Service Manual SE-102 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] REAR SEAT  Disconnect the harness connector (A).  Remove the screws (C), and then remove seatback duct B (1) and ventilation motor (seatback) (2).

Page 3967 of 5121

NISSAN TEANA 2008 Service Manual POWER SEAT SWITCH SE-103 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] C D E F G H I K L MA B SE N O P POWER SEAT SWITCH Exploded ViewINFOID:0000000003849136 Refer to SE-89, "Exploded View". Removal an

Page 3968 of 5121

NISSAN TEANA 2008 Service Manual SE-104 < ON-VEHICLE REPAIR >[WITH VENTILATION SEAT] HEATED SEAT SWITCH HEATED SEAT SWITCH FRONT SEAT FRONT SEAT : Exploded ViewINFOID:0000000003849128 FRONT SEAT : Removal and InstallationINFOID:00000
