TM-64
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
DescriptionINFOID:0000000003848980
This malfunction is detected when the torque converter clutch does not lock-up as instructed by the TCM. This
is not only caused by electrical malfunctions (circuits open or shorted), but also by mechanical malfunctions
such as control valve sticking, improper solenoid valve operation, etc.
DTC LogicINFOID:0000000003848981
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following condition for at least 30 seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0744 A/T TCC S/V FNCTN” detected?
YES >> Go to TM-64, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003848982
1.CHECK LINE PRESSURE
Perform line pressure test. Refer to TM-146, "
Inspection and Judgment".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts. Refer to TM-146, "
Inspection and Judgment".
2.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
1. Turn ignition switch OFF.
2. Disconnect CVT unit connector.
3. Check torque converter clutch solenoid valve. Refer to TM-65, "
Component Inspection (Torque Converter
Clutch Solenoid Valve)".
Is the inspection result normal?
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P0744 A/T TCC S/V FNCTN CVT cannot perform lock-up even if elec-
trical circuit is good.
TCM detects as irregular by comparing
reference value with slip rotation.
There is a big difference between engine
speed and primary speed sensor when
TCM lock-up signal is on. Torque converter clutch solenoid valve
Hydraulic control circuit
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
VEHICLE SPEED : Constant speed of more than 40 km/h (25 MPH)
Page 4538 of 5121
![NISSAN TEANA 2008 Service Manual P0744 A/T TCC S/V FUNCTION (LOCK -UP)
TM-65
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
YES >> GO TO 3.
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
3 NISSAN TEANA 2008 Service Manual P0744 A/T TCC S/V FUNCTION (LOCK -UP)
TM-65
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
YES >> GO TO 3.
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
3](/manual-img/5/57391/w960_57391-4537.png)
P0744 A/T TCC S/V FUNCTION (LOCK -UP)
TM-65
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
YES >> GO TO 3.
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
3.CHECK LOCK-UP SELECT SOLENOID VALVE
Check lock-up select solenoid valve. Refer to TM-65, "
Component Inspection (Lock-up Select Solenoid
Va l v e )".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
4.CHECK OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR) SYSTEM
Check output speed sensor (secondary speed sensor) system. Refer to TM-55, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.CHECK INPUT SPEED SENSOR (PRIMARY SPEED SENSOR) SYSTEM
Check input speed sensor (primary speed sensor) system. Refer to TM-52, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace damaged parts.
6.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Torque Converter Clutch Solenoid Valve)INFOID:0000000003848983
1.CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
Component Inspection (Lock-up Select Solenoid Valve)INFOID:0000000003848984
1.CHECK LOCK-UP SELECT SOLENOID VALVE
Check resistance between CVT unit connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
CVT unit connector
GroundResistance (Approx.)
Connector Terminal
F24 12 3.0 – 9.0 Ω
CVT unit connector
GroundResistance (Approx.)
Connector Terminal
F24 13 6.0 – 19.0 Ω
