TM-112
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
INH SW3Selector lever in “D” and “L” positions On
Selector lever in “P”, “R” and “N” positions Off
INH SW2Selector lever in “N”, “D” and “L” positions On
Selector lever in “P” and “R” positions Off
INH SW1Selector lever in “R”, “N” and “D” positions On
Selector lever in “P” and “L” positions Off
BRAKE SWDepressed brake pedal On
Released brake pedal Off
FULL SWFully depressed accelerator pedal On
Released accelerator pedal Off
IDLE SWReleased accelerator pedal On
Fully depressed accelerator pedal Off
SPORT MODE SWWhile pushing sport mode switch On
Other conditions Off
INDLRNGSelector lever in “L” position On
Selector lever in other positions Off
INDDRNGSelector lever in “D” position On
Selector lever in other positions Off
INDNRNGSelector lever in “N” position On
Selector lever in other positions Off
INDRRNGSelector lever in “R” position On
Selector lever in other positions Off
INDPRNGSelector lever in “P” position On
Selector lever in other positions Off
SPORT MODE INDWhen sport mode On
Other conditions Off
SMCOIL D During driving Changes ON ⇔ OFF.
SMCOIL C During driving Changes ON ⇔ OFF.
SMCOIL B During driving Changes ON ⇔ OFF.
SMCOIL A During driving Changes ON ⇔ OFF.
LUSEL SOL OUTSelector lever in “P” and “N” positions On
Wait at least for 5 seconds with the selector lever
in “R”, “D” and “L” positionsOff
LUSEL SOL MONSelector lever in “P” and “N” positions On
Wait at least for 5 seconds with the selector lever
in “R”, “D” and “L” positionsOff
STRTR RLY OUTSelector lever in “P” and “N” positions On
Selector lever in other positions Off
STRTR RLY MONSelector lever in “P” and “N” positions On
Selector lever in other positions Off
VDC ONVDC operate On
Other conditions Off
TCS ONTCS operate On
Other conditions Off Item name Condition Display value (Approx.)
Page 4586 of 5121
![NISSAN TEANA 2008 Service Manual TCM
TM-113
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
* Means CVT fluid temperature. Convert numerical values for actual fluid temperature °C (°F). Refer to TM-139, "ATFTEMP COU NISSAN TEANA 2008 Service Manual TCM
TM-113
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
* Means CVT fluid temperature. Convert numerical values for actual fluid temperature °C (°F). Refer to TM-139, "ATFTEMP COU](/manual-img/5/57391/w960_57391-4585.png)
TCM
TM-113
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
* Means CVT fluid temperature. Convert numerical values for actual fluid temperature °C (°F). Refer to TM-139, "ATFTEMP COUNT
Conversion Table".
TERMINAL LAYOUT
PHYSICAL VALUES
ABS ONABS operate On
Other conditions Off
RANGESelector lever in “N” and “P” positions. N·P
Selector lever in “R” position. R
Selector lever in “D” position. D
Selector lever in “L” position. L Item name Condition Display value (Approx.)
SCIA6679J
Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
+ - Signal name Input/Output
1
(P/B)Ground PNP switch 2 Input
Ignition switch ONSelector lever in “N” and “D” and
“L” positions0 V
Selector lever in other positions10.0 V –
Battery
voltage
2
(P/L)Ground PNP switch 3 InputSelector lever in “D” and “L” po-
sitions0 V
Selector lever in other positions10.0 V –
Battery
voltage
3
(G/O)Ground PNP switch 4 InputSelector lever in “R” and “D” po-
sitions0 V
Selector lever in other positions10.0 V –
Battery
voltage
4
(GR)Ground PNP switch 3 (monitor) InputSelector lever in “D” and “L” po-
sitions0 V
Selector lever in other positions10.0 V –
Battery
voltage
5
(B)Ground Ground Output Always 0 V
6
(O)Ground K-LINE Input/Output — —
7
(W)Ground Sensor ground Output Always 0 V
8
(G/W)— CLOCK (SEL2) — — —
Page 4587 of 5121
![NISSAN TEANA 2008 Service Manual TM-114
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
9
(L/R)— CHIP SELECT (SEL1) — — —
10
(BR/R)— DATA I/O (SEL3) — — —
11
(BR/W)Ground PNP switch 1 Input Ignition switch ONSelector lever in “ NISSAN TEANA 2008 Service Manual TM-114
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
9
(L/R)— CHIP SELECT (SEL1) — — —
10
(BR/R)— DATA I/O (SEL3) — — —
11
(BR/W)Ground PNP switch 1 Input Ignition switch ONSelector lever in “](/manual-img/5/57391/w960_57391-4586.png)
TM-114
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
9
(L/R)— CHIP SELECT (SEL1) — — —
10
(BR/R)— DATA I/O (SEL3) — — —
11
(BR/W)Ground PNP switch 1 Input Ignition switch ONSelector lever in “R”, “N” and “D”
positions0 V
Selector lever in other positionsBattery
voltage
13
(V)GroundCVT fluid temperature sen-
sor Input Ignition switch ONWhen CVT fluid temperature is
20°C (68°F)1.9 – 2.2
V
When CVT fluid temperature is
80°C (176°F)0.8 – 1.1
V
14
(R/W)GroundTransmission fluid pres-
sure sensor B (Primary
pressure sensor)Input
“N” position idle0.5 – 0.8
V
15
(V/W)GroundTransmission fluid pres-
sure sensor A (Secondary
pressure sensor)Input1.0 – 1.5
V
19
(G/B)Ground Reverse lamp relay Output Ignition switch ONSelector lever in “R” position 0 V
Selector lever in other positionsBattery
voltage
20
(R/B)Ground Starter relay Output Ignition switch ONSelector lever in “N”, “P” posi-
tionsBattery
voltage
Selector lever in other positions 0 V
25
(W/R)Ground Sensor ground Output Always 0 V
26
(L/O)Ground Sensor power OutputIgnition switch ON —4.75 –
5.25 V
Ignition switch OFF — 0 V
27
(R/G)Ground Step motor D Output
Within 2 seconds after ignition switch ON, measure the
time using the pulse width measurement function (Hi
level) of CONSULT-III.*
CAUTION:
Connect the diagnosis data link cable to the vehicle
diagnosis connector.10.0
msec
28
(R)Ground Step motor C Output30.0
msec
29
(O/B)Ground Step motor B Output10.0
msec
30
(G/R)Ground Step motor A Output30.0
msec
31
(P)— CAN-L Input/Output — —
32
(L)— CAN-H Input/Output — —
33
(LG)GroundInput speed sensor (Prima-
ry speed sensor)InputWhen driving at 20 km/h (12 MPH) in “L” position, use
the CONSULT-III pulse frequency measuring function.680 Hz
34
(LG/R)GroundOutput speed sensor (Sec-
ondary speed sensor)InputWhen driving at 20 km/h (12 MPH) in “D” position, use
the CONSULT-III pulse frequency measuring function.400 Hz
37
(V/R)GroundLock-up select solenoid
valveOutput Ignition switch ONSelector lever in “P”, “N” posi-
tions Battery
voltage
Wait at least for 5 seconds with
the selector lever in “R”, “D” and
“L” positions.0 V Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
+ - Signal name Input/Output
Page 4588 of 5121
![NISSAN TEANA 2008 Service Manual TCM
TM-115
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
*: A circuit tester cannot be used to test this item.38
(L/W)GroundTorque converter clutch so-
lenoid valveOutputWhen vehicle NISSAN TEANA 2008 Service Manual TCM
TM-115
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
*: A circuit tester cannot be used to test this item.38
(L/W)GroundTorque converter clutch so-
lenoid valveOutputWhen vehicle](/manual-img/5/57391/w960_57391-4587.png)
TCM
TM-115
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
*: A circuit tester cannot be used to test this item.38
(L/W)GroundTorque converter clutch so-
lenoid valveOutputWhen vehicle drive
in “D” positionWhen CVT performs lock-up 6.0 V
When CVT does not perform
lock-up1.0 V
39
(W/B)GroundPressure control solenoid
valve B (Secondary pres-
sure solenoid valve)Output
“N” positions idle Release your foot from the ac-
celerator pedal.5.0 – 7.0
V
Press the accelerator pedal all
the way down.3.0 – 4.0
V
40
(R/Y)GroundPressure control solenoid
valve A (Line pressure so-
lenoid valve)Output Release your foot from the ac-
celerator pedal.5.0 – 7.0
V
Press the accelerator pedal all
the way down.1.0 – 3.0
V
42
(B)Ground Ground Output Always 0 V
45
(L/R)GroundPower supply
(memory back-up)Input AlwaysBattery
voltage
46
(Y)Ground Power supply OutputIgnition switch ON —Battery
voltage
Ignition switch OFF — 0 V
47
(L/R)GroundPower supply
(memory back-up)Input AlwaysBattery
voltage
48
(Y)Ground Power supply OutputIgnition switch ON —Battery
voltage
Ignition switch OFF — 0 V Te r m i n a l N o .
(Wire color)Description
ConditionVa l u e
(Approx.)
+ - Signal name Input/Output
Page 4589 of 5121
TM-116
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
Wiring Diagram - CVT CONTROL SYSTEM -
INFOID:0000000003849060
JCDWM0243GB
Page 4590 of 5121
TCM
TM-117
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
JCDWM0244GB
Page 4591 of 5121
TM-118
< ECU DIAGNOSIS >[CVT: RE0F09B]
TCM
JCDWM0245GB
Page 4592 of 5121
TCM
TM-119
< ECU DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
JCDWM0246GB
