NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-25
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REMOTE KEYLESS ENTRY FUNCTION : System DiagramINFOID:0000000003794750
REMOTE KEYLESS

Page 1242 of 5121

NISSAN TEANA 2008 Service Manual DLK-26
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
Hazard and horn reminder does not operate if any door switch is ON (any door is OPEN).
How to Change Hazard and Horn R

Page 1243 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-27
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
REMOTE KEYLESS ENTRY FUNCTION : Component Parts LocationINFOID:0000000003841722
1. BC

Page 1244 of 5121

NISSAN TEANA 2008 Service Manual DLK-28
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
REMOTE KEYLESS ENTRY FUNCTION : Component Description
INFOID:0000000003794753
KEY REMINDER FUNCTION
KEY REMINDER FUNCT

Page 1245 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-29
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Key reminder has the following 3 functions.
*:If the door closing impact shocks the d

INTELLIGENT KEY SYSTEM
DLK-29
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Key reminder has the following 3 functions.
*:If the door closing impact shocks the door lock knob or makes contact with baggage comma the door lock knob might activate the door
locks accidentally comma but unlock operation will be perform in these cases.
CAUTION:
• The above function operates when the Intelligent Key is inside the vehicle. However, there may be
times when the Intelligent Key cannot be detected, and this function will not operate when the Intelli-
gent Key is on the instrument panel, or in the glove box. Also, this system sometimes does not oper-
ate if the Intelligent Key is in the door pocket of an open door.
Key reminder function is operated when the trunk lid is open/closed and the buzzers sound. If the
following operations are performed, the key reminder function is cleared and buzzer sounds are
stopped.
- Remote controller door lock button operation of Intelligent Key
- Remote controller door unlock button operation of Intelligent Key
- When the trunk lid is closed, the Intelligent Key is not inside the vehicle
- When any door is open
Key remainder function Operation condition Operation
Driver door closed*Right after driver side door is closed under the following conditions
Door lock operation is performed
Driver side door is opened
Driver side door is in lock stateAll doors unlock
Door is open or closedRight after all doors are closed under the following conditions
Intelligent Key is inside the vehicle
Any door is opened
All doors are locked by door lock and unlock switch or door lock knob All doors unlock
Sound Intelligent Key warn-
ing buzzer
Trunk lid is closedRight after trunk lid is closed under the following conditions
Intelligent Key is inside vehicle
All doors are closed
All doors are locked All doors unlock
Trunk lid can open with trunk
lid opener switch
Sound Intelligent Key warn-
ing buzzer

Page 1246 of 5121

NISSAN TEANA 2008 Service Manual DLK-30
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
KEY REMINDER FUNCTION : Component Parts Location
INFOID:0000000003841723
1. BCM M118, M119, M120, M121,
M122, M1232.

Page 1247 of 5121

NISSAN TEANA 2008 Service Manual INTELLIGENT KEY SYSTEM
DLK-31
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
WARNING FUNCTION
WARNING FUNCTION : System DescriptionINFOID:0000000003794756
OPERATI

Page 1248 of 5121

NISSAN TEANA 2008 Service Manual DLK-32
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Information display (combination met

DLK-32
< FUNCTION DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY SYSTEM
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Information display (combination meter), “KEY” indicator or key slot illumination when the warning conditions
are met.
OFF position warning For internal Ignition switch: ACC position.
Door switch (driver side): ON (Door is open).
For externalOFF position warning (for internal) is in active mode, driver side door is closed.
NOTE:
OFF position (for external) active only when each of the sequence has oc-
curred as per the following: P position warning → ACC warning → OFF posi-
tion warning (for internal) → OFF position warning (for internal)
P position warning Shift position: Any position except the P position.
Engine is running to stopped (ignition switch is ON to OFF).
ACC warning When P position warning is in active mode, shift position changes from the
P position.
Ignition switch: ACC position.
Ta k e a w a y w a r n i n gDoor is open to close Ignition switch: Any position except the LOCK position.
Door switch: ON to OFF (door is open to close).
Intelligent Key can not be detected inside the vehicle.
Door is open Door switch: ON (door is open).
Key ID verification every 5 seconds when registered Intelligent Key can not
be detected inside the vehicle.
Push button-ignition
switch operation Ignition switch: Any position except the LOCK position.
Press push-button ignition switch.
Intelligent Key can not be detected inside the vehicle.
Intelligent Key is removed
from key slotWhen Intelligent Key is removed from key slot, Intelligent Key can not be de-
tected inside the vehicle.
Door lock operation warn-
ingRequest switch operationWhen request switch is pushed (lock operation) under the following conditions.
All doors are closed.
All doors are unlocked.
Intelligent Key is inside vehicle.
Intelligent Key button op-
erationWhen Intelligent Key button is pushed (lock operation) under the following con-
ditions.
Door switch: ON (any door is open).
For 3 seconds after Intelligent Key is removed from key slot.
Key warning Ignition switch is in the OFF position.
Driver side door switch: ON (driver side door is open).
Intelligent Key is inserted in key slot.
Intelligent Key insert information Door switch: ON to OFF (door is open to close).
Ignition switch: OFF to ON position.
Intelligent Key is out of key slot.
Intelligent Key can not be detected inside the vehicle.
Engine start informationIgnition switch is in the
ON position Ignition switch: ON position.
Shift position: P position.
Engine is stopped.
Ignition switch is in any
position except the ON
position Ignition switch: Any position except the ON position.
Shift position: P position.
Intelligent Key is inserted in key slot or Intelligent Key can be detected inside
the vehicle.
Steering lock information When steering lock can not be released after ignition switch is turned ON.
Intelligent Key low battery warningWhen Intelligent Key is battery low, BCM is detected after ignition switch is
turned ON.
Key ID warningWhen registered Intelligent Key can not be detected inside the vehicle after ig-
nition switch is turned ON. Warning/Information functions Operation procedure
