TM-168
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
TRANSAXLE ASSEMBLY
REMOVAL AND INSTALLATION
TRANSAXLE ASSEMBLY
Exploded ViewINFOID:0000000003849108
Removal and InstallationINFOID:0000000003849109
WARNING:
Never remove the reservoir tank cap when the engine is hot. Serious burns could occur from high
pressure engine coolant escaping from the reservoir tank.
REMOVAL
1. Remove the engine, the transaxle assembly and front suspension member. Refer to EM-67, "Exploded
View".
2. Lift with hoist and separate engine, transaxle assembly from front suspension member. Refer to EM-67,
"Exploded View".
1. CVT fluid level gauge 2. CVT fluid charging pipe 3. O-ring
4. Transaxle assembly
A. For tightening torque, refer to TM-168, "
Removal and Installation".
Refer to GI-4, "
Components" for symbols in the figure.
JPDIA0799GB
Page 4642 of 5121
![NISSAN TEANA 2008 Service Manual TRANSAXLE ASSEMBLY
TM-169
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Remove air breather hose. Refer to TM-164, "Exploded View".
4. Disconnect secondary speed sensor NISSAN TEANA 2008 Service Manual TRANSAXLE ASSEMBLY
TM-169
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Remove air breather hose. Refer to TM-164, "Exploded View".
4. Disconnect secondary speed sensor](/manual-img/5/57391/w960_57391-4641.png)
TRANSAXLE ASSEMBLY
TM-169
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
3. Remove air breather hose. Refer to TM-164, "Exploded View".
4. Disconnect secondary speed sensor connector. Refer to TM-161, "
Exploded View".
5. Disconnect CVT unit connector.
6. Disconnect air fuel ratio sensor 1 (bank 2). Refer to EM-34, "
Exploded View".
7. Remove crankshaft position sensor (POS). Refer to EM-38, "
Exploded View".
8. Remove CVT fluid charging pipe from transaxle assembly.
9. Remove transaxle assembly fixing bolts with power tool.
10. Remove transaxle assembly from engine assembly with a hoist.
11. Remove fluid cooler hose from transaxle assembly.
INSTALLATION
Note the following, and install in the reverse order of removal.
CAUTION:
Check fitting of dowel pins ( ) when installing transaxle
assembly to engine assembly.
When installing transaxle assembly to the engine assembly, attach
the fixing bolts in accordance with the following.
JPDIA0598ZZ
JPDIA0602ZZ
JPDIA0600ZZ
Insertion direction Transaxle assembly to engine assemblyEngine assembly to tran-
saxle assembly
Bolt position A B C D
Number of bolts 1 2 2 4
Bolt length mm (in) 55 (2.17) 39 (1.54) 108 (4.25) 40 (1.57)
Tightening torque
N·m (kg-m, ft-lb)74.5 (7.6, 55) 50 (4.3, 31)
Page 4643 of 5121
![NISSAN TEANA 2008 Service Manual TM-170
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
TRANSAXLE ASSEMBLY
When using the drive plate location guide (commercial service tool:
31197CA000) (A), set it to the stud bolts which is used to in NISSAN TEANA 2008 Service Manual TM-170
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
TRANSAXLE ASSEMBLY
When using the drive plate location guide (commercial service tool:
31197CA000) (A), set it to the stud bolts which is used to in](/manual-img/5/57391/w960_57391-4642.png)
TM-170
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
TRANSAXLE ASSEMBLY
When using the drive plate location guide (commercial service tool:
31197CA000) (A), set it to the stud bolts which is used to install it
to the torque converter.
When not using drive plate location guide, rotate torque converter
so that the stud bolt (B) for mounting the drive plate location guide
of torque converter aligns with the mounting position of service
hole.
Rotate crankshaft so that the hole (A) for inserting drive plate loca-
tion guide of drive plate aligns with the service hole (B).
NOTE:
When not using drive plate location guide, insert stud bolt of torque
converter into the hole (C) of drive plate, aligning the drive plate
hole position and torque converter.
CAUTION:
Be careful not to strike the drive plate when installing the
torque converter stud bolt.
Align the position of tightening nuts ( ) for drive plate with those
of the torque converter, and temporarily tighten the nuts. Then,
tighten the bolts to the specified torque.
CAUTION:
When turning crankshaft, turn it clockwise as viewed from the
front of the engine.
When tightening the nuts for the torque converter after fixing
the crankshaft pulley bolts, confirm the tightening torque of
the crankshaft pulley mounting bolts. Refer to EM-79,
"Exploded View".
Rotate crankshaft several turns and check that transaxle rotates freely without binding after con-
verter is installed to drive plate.
Never reuse O-ring.
Apply petroleum jelly to O-ring.
InspectionINFOID:0000000003849110
INSPECTION BEFORE INSTALLATION
After inserting a torque converter to transaxle assembly, check that
distance (A) is within the reference value limit.
INSPECTION AFTER INSTALLATION
Check the following items.
JPDIA0607ZZ
JPDIA0603ZZ
: 51 N·m (5.2 kg-m,38 ft-lb)
SCIA1861E
B: Scale
C : Straightedge
Distance A : Refer to TM-175, "Torque Converter".
JPDIA0620ZZ
Page 4644 of 5121
TRANSAXLE ASSEMBLY
TM-171
< REMOVAL AND INSTALLATION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
CVT fluid leakage and CVT fluid level. Refer to TM-142, "Inspection".
CVT position. Refer to TM-152, "
Inspection and Adjustment".
Page 4645 of 5121
TM-172
< DISASSEMBLY AND ASSEMBLY >[CVT: RE0F09B]
TORQUE CONVERTER
DISASSEMBLY AND ASSEMBLY
TORQUE CONVERTER
Exploded ViewINFOID:0000000003849111
DisassemblyINFOID:0000000003849112
1. Remove transaxle assembly. Refer to TM-168, "Exploded View".
2. Remove torque converter from transaxle assembly.
AssemblyINFOID:0000000003849113
Note the following, and install in the reverse order of removal.
Attach the pawl (A) of the torque converter to the inner gear hole
(B) on the oil pump side.
CAUTION:
Rotate the torque converter for installing torque converter.
1. Torque converter 2. Transaxle assembly
JPDIA0691ZZ
JPDIA0692ZZ
Page 4646 of 5121
TORQUE CONVERTER
TM-173
< DISASSEMBLY AND ASSEMBLY >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
InspectionINFOID:0000000003849114
INSPECTION AFTER INSTALLATION
After inserting a torque converter to transaxle assembly, check dis-
tance (A) is within the reference value limit.
B: Scale
C : Straightedge
Distance A : Refer to TM-175, "Torque Converter".
JPDIA0620ZZ
Page 4647 of 5121
![NISSAN TEANA 2008 Service Manual TM-174
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINF NISSAN TEANA 2008 Service Manual TM-174
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINF](/manual-img/5/57391/w960_57391-4646.png)
TM-174
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000003849115
*: Refer to MA-11, "Fluids and Lubricants".
Vehicle Speed When Shifting GearsINFOID:0000000003849116
Numerical value data are reference values.
(rpm)
CAUTION:
Lock-up clutch is engaged when vehicle speed is approximately 18 km/h (11 MPH) to 90 km/h (56 MPH).
Stall SpeedINFOID:0000000003849117
Line PressureINFOID:0000000003849118
kPa (bar, kg/cm2, psi)
Applied modelVQ35DE
2WD
CVT modelRE0F09B
CVT assembly model code number 1XE0A
Transmission gear ratioD range Variable
Reverse 1.766
Final drive 5.173
Recommended fluid Genuine NISSAN CVT Fluid NS-2*
Fluid capacity 10.2 liter (9 Imp qt)
CAUTION:
Use only Genuine NISSAN CVT Fluid NS-2. Do not mix with other fluid.
Using CVT fluid other than Genuine NISSAN CVT Fluid NS-2 will deteriorate in driveability and CVT durability, and may dam-
age the CVT, which is not covered by the warranty.
Throttle position Shift patternEngine speed
At 40 km/h (25 MPH) At 60 km/h (37 MPH)
8/8“D” position 2,900 – 4,100 3,900 – 5,600
Sport mode 2,900 – 4,100 3,900 – 5,600
“L” position 2,900 – 4,100 3,900 – 5,600
2/8“D” position 1,100 – 3,100 1,200 – 3,700
Sport mode 2,200 – 3,000 2,800 – 3,600
“L” position 2,900 – 3,800 3,900 – 4,800
Stall speed 2,700 – 3,500 rpm
Engine speedLine pressure
“R”, “D” and “L” positions
At idle 700 (7.00, 7.13, 101.5)
At stall 5,700 (57.00, 58.14, 826.5)
Page 4648 of 5121
![NISSAN TEANA 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
TM-175
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Solenoid ValvesINFOID:0000000003849119
CVT Fluid Temperature SensorI NISSAN TEANA 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
TM-175
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Solenoid ValvesINFOID:0000000003849119
CVT Fluid Temperature SensorI](/manual-img/5/57391/w960_57391-4647.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
TM-175
< SERVICE DATA AND SPECIFICATIONS (SDS) [CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Solenoid ValvesINFOID:0000000003849119
CVT Fluid Temperature SensorINFOID:0000000003849120
Primary Speed SensorINFOID:0000000003849121
Secondary Speed SensorINFOID:0000000003849122
Step MotorINFOID:0000000003849123
Torque ConverterINFOID:0000000003849124
Name Resistance (Approx.)
Pressure control solenoid valve B (secondary pressure solenoid valve)
3.0 – 9.0 Ω Pressure control solenoid valve A (line pressure solenoid valve)
Torque converter clutch solenoid valve
Lock-up select solenoid valve6.0 – 19.0 Ω
Name ConditionCONSULT-III “Data Monitor”
(Approx.)Resistance (Approx.)
CVT fluid temperature sensorWhen CVT fluid temperature is 20°C (68°F) 1.9 – 2.2 V 6.5 kΩ
When CVT fluid temperature is 80°C (176°F) 0.8 – 1.1 V 0.9 kΩ
Name Condition Data (Approx.)
Primary speed sensorWhen driving at 20 km/h (12 MPH) in “L” position, use the
CONSULT-III pulse frequency measuring function.680 Hz
Name Condition Data (Approx.)
Secondary speed sensorWhen driving at 20 km/h (12 MPH) in “D” position, use the
CONSULT-III pulse frequency measuring function.400 Hz
Name Resistance (Approx.)
Ste p mo tor A15.0 Ω
Ste p mo tor B15.0 Ω
Ste p mo tor C15.0 Ω
Ste p mo tor D15.0 Ω
Distance between end of converter housing and torque converter 14.0 mm (0.55 in)
