SEC-56
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2601 SHIFT POSITION
B2601 SHIFT POSITION
DescriptionINFOID:0000000003814974
BCM confirms the shift position with the following 4 signals.
Selector lever
P/N position switch
P position signal from IPDM E/R (CAN)
P position signal from TCM (CAN)
DTC LogicINFOID:0000000003814975
DTC DETECTION LOGIC
NOTE:
If DTC B2601 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B2601 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
If DTC B2601 is displayed with DTC B2603, first perform the trouble diagnosis for DTC B2603. Refer to
SEC-67, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON under the following conditions, and wait for at least 2 seconds.
- Selector lever is in the P position.
- Do not depress the brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-56, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003814976
1.CHECK CONTROL DEVICE POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect control device (detention switch) connector.
3. Check voltage between control device (detention switch) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.CHECK CONTROL DEVICE POWER SUPPLY CIRCUIT
1. Disconnect BCM connector.
2. Check continuity between control device (detention switch) harness connector and BCM harness connec-
tor.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2601 SHIFT POSITIONBCM detects when a difference between the shift
P input signal and the shift position signal re-
ceived from IPDM E/R via CAN communication
continues for 2 seconds or more Harness or connectors
(Control device circuit is open or
shorted)
Control device (detention switch)
(+)
(–)Voltage (V)
(Approx.) Control device (detention switch)
Connector Terminal
M57 8 Ground Battery voltage
