Page 3641 of 5121

DIAGNOSIS SYSTEM (BCM)
PWC-11
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
The BCM records the following condition at the moment a particular DTC is detected.
Vehicle Speed
Odd Trip Meter
Vehicle Condition (BCM detected condition)
IGN Counter
IGN counter indicates the number of times that ignition switch is turned ON after DTC is detected.
The number is 0 when a malfunction is detected now.
The number increases like 1 → 2 → 3...38 → 39 after returning to the normal condition whenever ignition
switch OFF → ON.
The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
RETAINED PWR
RETAINED PWR : CONSULT-III Function (BCM - RETAINED PWR)INFOID:0000000003857783
Data monitor
CONSULT screen terms Description
SLEEP>LOCKWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “LOCK”)
SLEEP>OFFWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “OFF”.)
LOCK>ACC While turning power supply position from “LOCK” to “ACC”
ACC>ON While turning power supply position from “ACC” to “IGN”
RUN>ACCWhile turning power supply position from “RUN” to “ACC” (Vehicle is stopping and selector
lever is except P position.)
CRANK>RUNWhile turning power supply position from “CRANKING” to “RUN” (From cranking up the en-
gine to run it)
RUN>URGENT While turning power supply position from “RUN“ to “ACC” (Emergency stop operation)
ACC>OFF While turning power supply position from “ACC” to “OFF”
OFF>LOCK While turning power supply position from “OFF” to “LOCK”
OFF>ACC While turning power supply position from “OFF” to “ACC”
ON>CRANK While turning power supply position from “IGN” to “CRANKING”
OFF>SLEEPWhile turning BCM status from normal mode (Power supply position is “OFF”.) to low power
consumption mode
LOCK>SLEEPWhile turning BCM status from normal mode (Power supply position is “LOCK”.) to low pow-
er consumption mode
LOCK Power supply position is “LOCK” (Ignition switch OFF with steering is locked.)
OFF Power supply position is “OFF” (Ignition switch OFF with steering is unlocked.)
ACC Power supply position is “ACC” (Ignition switch ACC)
ON Power supply position is “IGN” (Ignition switch ON with engine stopped)
ENGINE RUN Power supply position is “RUN” (Ignition switch ON with engine running)
CRANKING Power supply position is “CRANKING” (At engine cranking)
Monitor Item Description
DOOR SW-DR Indicates [ON/OFF] condition of driver side door switch.
DOOR SW-AS Indicates [ON/OFF] condition of passenger side door switch.
Page 3642 of 5121

PWC-12
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
COMPONENT DIAGNOSIS
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000003825998
1.CHECK FUSE AND FUSIBLE LINK
1.Turn ignition switch OFF.
2.Check that the following fuse and fusible link are not blown.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is
blown.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT
1. Disconnect BCM connectors.
2. Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness.
3.CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace harness.
POWER WINDOW MAIN SWITCH
POWER WINDOW MAIN SWITCH : Diagnosis ProcedureINFOID:0000000003825999
1.CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition OFF.
2. Disconnect power window main switch connector.
3. Turn ignition switch ON.
4. Check voltage between power window main switch harness connector and ground.
Terminal No. Signal name Fuse and fusible link No.
1
Battery power supplyI (40A)
1110 (10A)
(+)
(−)Vo l ta g e
(Approx.) BCM
Connector Terminal
M118 1
Ground Battery voltage
M119 11
BCM
GroundContinuity
Connector Terminal
M119 13 Existed
Page 3643 of 5121

POWER SUPPLY AND GROUND CIRCUIT
PWC-13
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between power window main switch harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair or replace harness.
3.CHECK POWER SUPPLY CIRCUIT 2
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector and power window main switch harness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
FRONT POWER WINDOW SWITCH (PASSENGER SIDE) : Diagnosis Procedure
INFOID:0000000003826000
1.CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect front power window switch (passenger side) connector.
3. Turn ignition switch ON.
4. Check voltage between front power window switch (passenger side) harness connector and ground.
(+)
(–)Voltage (V)
(Approx.) Power window main switch
Connector Terminal
D5 10
Ground Battery voltage
D6 19
Power window main switch
GroundContinuity
Connector Terminal
D6 17 Existed
BCM Power window main switch
Continuity
Connector Terminal Connector Terminal
M1182D619
Existed
3D510
BCM
GroundContinuity
Connector Terminal
M1182
Not existed
3
Page 3644 of 5121

PWC-14
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Is the inspection result normal?
YES >> INSPECTION END.
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT 2
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector and front power window switch (passenger side) har-
ness connector.
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
REAR POWER WINDOW SWITCH
REAR POWER WINDOW SWITCH : Diagnosis ProcedureINFOID:0000000003826001
1.CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect rear power window switch connector.
3. Turn ignition switch ON.
4. Check voltage between rear power window switch harness connector and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK POWER SUPPLY CIRCUIT 2
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM harness connector and rear power window switch harness connector.
(+)
(–)Voltage (V)
(Approx.) Front power window switch (passenger side)
Connector Terminal
D45 1 Ground Battery voltage
BCM Front power window switch (passenger side)
Continuity
Connector Terminal Connector Terminal
M118 3 D45 1 Existed
BCM
GroundContinuity
Connector Terminal
M118 3 Not existed
(+)
(–)Voltage (V)
(Approx.) Rear power window switch
Connector Terminal
LH D83
1 Ground Battery voltage
RH D103
Page 3645 of 5121
POWER SUPPLY AND GROUND CIRCUIT
PWC-15
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
4. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-78, "Removal and Installation".
NO >> Repair or replace harness.
BCM Rear power window switch
Continuity
Connector Terminal Connector Terminal
M118 3LH D83
1 Existed
RH D103
BCM
GroundContinuity
Connector Terminal
M118 3 Not existed
Page 3646 of 5121

PWC-16
< COMPONENT DIAGNOSIS >
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
DescriptionINFOID:0000000003826002
Front power window motor (passenger side) will be operated if front power window switch (passenger side) is
operated.
Component Function CheckINFOID:0000000003826003
1. CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) FUNCTION
Check front power window motor (passenger side) operation with front power window switch (passenger side).
Is the inspection result normal?
YES >> Front power window switch (passenger side) is OK.
NO >> Refer to PWC-16, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003826004
1.CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE) INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect front power window switch (passenger side) connector.
3. Turn ignition switch ON.
4. Check voltage between front power window switch (passenger side) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
Check front power window switch (passenger side).
Refer to PWC-17, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace front power window switch (passenger side). Refer to PWC-86, "
Removal and Installa-
tion".
3.CHECK FRONT WINDOW SWITCH (PASSENGER SIDE) CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power window main switch connector.
3. Check continuity between power window main switch harness connector and front power window switch
(passenger side) harness connector.
4. Check continuity between power window main switch harness connector and ground.
(+)
(–) ConditionVoltage (V)
(Approx.) Front power window switch
(passenger side)
Connector Terminal
D452
GroundPower window
main switch
(passenger side)UP Battery voltage
DOWN 0
3UP 0
DOWN Battery voltage
Power window main switch Front power window switch (passenger side)
Continuity
Connector Terminal Connector Terminal
D58
D452
Existed
11 3
Page 3647 of 5121
FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
PWC-17
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
L
MA
B
PWC
N
O
P
Is the inspection result normal?
YES >> Replace power window main switch. Refer to PWC-85, "Removal and Installation".
NO >> Repair or replace harness.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000003826005
1.CHECK FRONT POWER WINDOW SWITCH (PASSENGER SIDE)
1. Turn ignition OFF.
2. Disconnect front power window switch (passenger side) connector.
3. Check front power window switch (passenger side).
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace front power window switch (passenger side). Refer to PWC-86, "
Removal and Installa-
tion".
Power window main switch
GroundContinuity
Connector Terminal
D58
Not existed
11
Front power window
switch (passenger side)Te r m i n a lFront power window
switch conditionContinuity
D4515
UP
Existed 34
34
NEUTRAL
25
14
DOWN
25
Page 3648 of 5121

PWC-18
< COMPONENT DIAGNOSIS >
REAR POWER WINDOW SWITCH
REAR POWER WINDOW SWITCH
DescriptionINFOID:0000000003826006
Rear power window motor will be operated if rear power window switch is operated.
Component Function CheckINFOID:0000000003826007
1. CHECK REAR POWER WINDOW SWITCH FUNCTION
Check rear power window motor operation with rear power window switch.
Is the inspection result normal?
YES >> Rear power window switch is OK.
NO >> Refer to PWC-18, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003826008
1.CHECK REAR POWER WINDOW SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect rear power window switch connector.
3. Turn ignition switch ON.
4. Check voltage between rear power window switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK REAR POWER WINDOW SWITCH
Check rear power window switch.
Refer to PWC-19, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace rear power window switch. Refer to PWC-87, "
Removal and Installation".
3.CHECK REAR POWER WINDOW SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect power window main switch connector.
3. Check continuity between power window main switch harness connector and rear power window switch
harness connector.
(+)
(–) ConditionVoltage (V)
(Approx.) Rear power window switch
Connector Terminal
LH D832
GroundPower window main
switch: Rear LHUP Battery voltage
DOWN 0
3UP 0
DOWN Battery voltage
RH D1032
Power window main
switch: Rear RHUP Battery voltage
DOWN 0
3UP 0
DOWN Battery voltage
