Page 4081 of 5121

NISSAN TEANA 2008 Service Manual SEC-72
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2608 STARTER RELAY
B2608 STARTER RELAY
DescriptionINFOID:0000000003814996
Located in IPDM E/R, the starter relay runs the starter motor. The sta

Page 4082 of 5121

NISSAN TEANA 2008 Service Manual B2608 STARTER RELAY
SEC-73
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
4. Check continuity between IPDM E/R harness connector and ground.
Is the inspection result

Page 4083 of 5121

NISSAN TEANA 2008 Service Manual SEC-74
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2609 STEERING STATUS
B2609 STEERING STATUS
DescriptionINFOID:0000000003814999
There are 2 switches in the steering lock unit (steering lock/unlo

SEC-74
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2609 STEERING STATUS
B2609 STEERING STATUS
DescriptionINFOID:0000000003814999
There are 2 switches in the steering lock unit (steering lock/unlock switch 1 and 2). BCM compares those 2
switches conditions to judge the present steering status.
DTC LogicINFOID:0000000003815000
DTC DETECTION LOGIC
NOTE:
If DTC B2609 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-28, "
BCM : DTC Logic".
If DTC B2609 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-30, "
BCM : DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE 1
1. Turn ignition switch ON under the following conditions and wait for at least 1 second.
- Selector lever is in the P or N position.
- Do not depress brake pedal.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-74, "Diagnosis Procedure".
NO >> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE 2
1. Turn ignition switch ON.
2. Turn ignition switch OFF.
3. Press driver side door switch and wait for at least 1 second.
4. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Go to SEC-74, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003815001
1.INSPECTION START
Check the case in which DTC is detected.
Case1: It is detected after ignition switch is changed from OFF to ON
Case2: It is detected after ignition switch is changed from ON to OFF and door switch is pressed
In which case is DTC detected?
Case1 >> GO TO 2.
Case2 >> GO TO 6.
2.CHECK BCM OUTPUT SIGNAL
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2609 STEERING STATUSBCM detects the malfunction of steering lock unit
switches for 1 second. Harness or connectors
[Steering lock unit circuit (BCM
side) is open or shorted]
Harness or connectors
[Steering lock unit circuit (IPDM E/
R side) is open or shorted]
Steering lock unit
IPDM E/R
BCM

Page 4084 of 5121

NISSAN TEANA 2008 Service Manual B2609 STEERING STATUS
SEC-75
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
1. Turn ignition switch OFF.
2. Disconnect steering lock unit connector and IPDM E/R conne

Page 4085 of 5121

NISSAN TEANA 2008 Service Manual SEC-76
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B2609 STEERING STATUS
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-34, "Removal and Installation".
NO >> Repair or repl

Page 4086 of 5121

NISSAN TEANA 2008 Service Manual B2609 STEERING STATUS
SEC-77
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
3. Check continuity between steering lock unit harness connector and ground.
Is the inspec

Page 4087 of 5121

NISSAN TEANA 2008 Service Manual SEC-78
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
B260B STEERING LOCK UNIT
B260B STEERING LOCK UNIT
DescriptionINFOID:0000000003815002
The steering lock unit performs the check by itself accordin

Page 4088 of 5121

NISSAN TEANA 2008 Service Manual B260C STEERING LOCK UNIT
SEC-79
< COMPONENT DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B260C STEERING LOCK UNIT
DescriptionINFOID:0000000003815005
The steering lock unit perf
