Page 4601 of 5121

NISSAN TEANA 2008 Service Manual TM-128
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
SYSTEM SYMPTOM
12 Others No creep at all.ON vehicle1. CVT fluid level and stateTM-142
2. Line pressure testTM-146
3. Accelerator pedal position sensorTM-88
4

Page 4602 of 5121

NISSAN TEANA 2008 Service Manual SYSTEM SYMPTOM
TM-129
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
13
OthersVehicle cannot drive
in all positions.ON vehicle1. CVT fluid level and stateTM-142
2. Line pressure

Page 4603 of 5121

NISSAN TEANA 2008 Service Manual TM-130
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
SYSTEM SYMPTOM
15
OthersWith selector lever in
“R” position, driving is
not possible.ON vehicle1. CVT fluid level and stateTM-142
2. Line pressure test

Page 4604 of 5121

NISSAN TEANA 2008 Service Manual SYSTEM SYMPTOM
TM-131
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
18
OthersStrange noise in “R”
position.ON vehicle1. CVT fluid level and stateTM-142
2. Engine speed signa

Page 4605 of 5121

NISSAN TEANA 2008 Service Manual TM-132
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
SYSTEM SYMPTOM
21
OthersMaximum speed low.ON vehicle1. CVT fluid level and stateTM-142
2. Line pressure testTM-146
3. Accelerator pedal position sensorTM-88

Page 4606 of 5121

NISSAN TEANA 2008 Service Manual SYSTEM SYMPTOM
TM-133
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
25
OthersEngine stall.ON vehicle1. CVT fluid level and stateTM-142
2. Engine speed signalTM-59
3. Primary spee

Page 4607 of 5121

NISSAN TEANA 2008 Service Manual TM-134
< SYMPTOM DIAGNOSIS >[CVT: RE0F09B]
SYSTEM SYMPTOM
30
OthersEngine starts in posi-
tions other than “N” or
“P”.ON vehicle1. Ignition switch and starterPG-55
, STR-6
2. CVT positionTM-1

Page 4608 of 5121

NISSAN TEANA 2008 Service Manual PRECAUTIONS
TM-135
< PRECAUTION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOI

PRECAUTIONS
TM-135
< PRECAUTION >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003897161
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution Necessary for Steering Wheel Rotation after Battery Disconnect
INFOID:0000000003897162
NOTE:
Before removing and installing any control units, first turn the push-button ignition switch to the LOCK posi-
tion, then disconnect both battery cables.
After finishing work, confirm that all control unit connectors are connected properly, then re-connect both
battery cables.
Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If a DTC is detected, perform trouble diagnosis according to self-diagnosis results.
This vehicle is equipped with a push-button ignition switch and a steering lock unit.
If the battery is disconnected or discharged, the steering wheel will lock and cannot be turned.
If turning the steering wheel is required with the battery disconnected or discharged, follow the procedure
below before starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Turn the push-button ignition switch to ACC position.
(At this time, the steering lock will be released.)
3. Disconnect both battery cables. The steering lock will remain released with both battery cables discon-
nected and the steering wheel can be turned.
4. Perform the necessary repair operation.
5. When the repair work is completed, re-connect both battery cables. With the brake pedal released, turn
the push-button ignition switch from ACC position to ON position, then to LOCK position. (The steering
wheel will lock when the push-button ignition switch is turned to LOCK position.)
6. Perform self-diagnosis check of all control units using CONSULT-III.
