Page 1897 of 5121

EM-22
< ON-VEHICLE MAINTENANCE >
COMPRESSION PRESSURE
COMPRESSION PRESSURE
InspectionINFOID:0000000003802245
1. Warm up engine thoroughly. Then, stop it.
2. Release fuel pressure. Refer to EC-411, "
Inspection".
3. Disconnect fuel pump fuse to avoid fuel injection during measurement. Refer to EC-20,
"ComponentPartsLocation".
4. Remove engine cover. Refer to EM-24, "
Exploded View".
5. Remove ignition coil and spark plug from each cylinder. Refer to EM-49, "
Exploded View".
6. Connect engine tachometer (not required in use of CONSULT-III).
7. Install compression gauge with an adapter (commercial service
tool) onto spark plug hole.
Use the adapter whose picking up end inserted to spark plug
hole is smaller than 20 mm (0.79 in) in diameter. Otherwise, it
may be caught by cylinder head during removal.
8. With accelerator pedal fully depressed, turn ignition switch to “START” for cranking. When the gauge
pointer stabilizes, read the compression pressure and the engine rpm. Perform these steps to check each
cylinder.
CAUTION:
Always use a fully charged battery to obtain the specified engine speed.
If the engine speed is out of the specified range, check battery liquid for proper gravity. Check the
engine speed again with normal battery gravity.
If compression pressure is below minimum value, check valve clearances and parts associated with
combustion chamber (valve, valve seat, piston, piston ring, cylinder bore, cylinder head, cylinder head
gasket). After the checking, measure compression pressure again.
If some cylinder has low compression pressure, pour small amount of engine oil into the spark plug hole
of the cylinder to recheck it for compression.
- If the added engine oil improves the compression, piston rings may be worn out or damaged. Check pis-
ton rings and replace if necessary.
- If the compression pressure remains at low level despite the addition of engine oil, valves may be mal-
functioning. Check valves for damage. Replace valve or valve seat accordingly.
If two adjacent cylinders have respectively low compression pressure and their compression remains
low even after the addition of engine oil, cylinder head gaskets are leaking. In such a case, replace cyl-
inder head gaskets.
9. After inspection is completed, install removed parts.
PBIC0900E
a: φ20 mm (0.79 in)
JPBIA0171ZZ
Compression pressure : Refer to EM-135, "GeneralSpecification".
Page 1898 of 5121
COMPRESSION PRESSURE
EM-23
< ON-VEHICLE MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
10. Start the engine, and check that the engine runs smoothly.
11. Perform trouble diagnosis. If DTC appears, erase it. Refer to EC-124, "
Description".
Page 1899 of 5121
EM-24
< ON-VEHICLE REPAIR >
ENGINE COVER
ON-VEHICLE REPAIR
ENGINE COVER
Exploded ViewINFOID:0000000003802246
Removal and InstallationINFOID:0000000003802247
REMOVAL
1. Remove air duct (inlet). Refer to EM-26, "Exploded View".
2. Remove engine cover mounting bolts (A), (B).
3. Draw and pull out engine cover from engine cover mounting bolts (C), (D).
CAUTION:
Pull engine cover from mounting bolt (D) holding with hand the position (E) as shown in the fig-
ure.
Never damage or scratch engine cover when installing or removing.
4. Remove engine mounting bolts (C), (D), if necessary.
INSTALLATION
Install in the reverse order of removal.
1. Engine cover
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA1712GB
JPBIA1718ZZ
Page 1900 of 5121
DRIVE BELT AUTO TENSIONER AND IDLER PULLEY
EM-25
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
DRIVE BELT AUTO TENSIONER AND IDLER PULLEY
Exploded ViewINFOID:0000000003802248
Removal and InstallationINFOID:0000000003802249
Removal
1. Remove drive belt. Refer to EM-12, "Removal and Installation".
Keep auto-tensioner pulley arm locked after drive belt is removed.
2. Remove auto-tensioner and idler pulley.
Keep auto-tensioner pulley arm locked to install or remove auto-tensioner.
Installation
Installation is the reverse order of removal.
CAUTION:
If there is damage greater than peeled paint, replace drive belt auto-tensioner.
1. Drive belt auto-tensioner 2. Idler pulley 3. Idler pulley
4. Bracket
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA1626GB
Page 1901 of 5121

EM-26
< ON-VEHICLE REPAIR >
AIR CLEANER AND AIR DUCT
AIR CLEANER AND AIR DUCT
Exploded ViewINFOID:0000000003802250
Removal and InstallationINFOID:0000000003802251
REMOVAL
1. Remove air duct (inlet).
2. Disconnect harness connector from mass air flow sensor.
3. Disconnect PCV hose.
4. Remove air cleaner cases (upper and lower) with mass air flow sensor and air duct assembly disconnect-
ing their joints.
Add mating marks as necessary for easier installation.
5. Remove mass air flow sensor from air cleaner case (upper), as necessary.
CAUTION:
Handle mass air flow sensor with following cares.
Never shock mass air flow sensor.
Never disassemble mass air flow sensor.
1. Mass air flow sensor 2. Air cleaner case (upper) 3. Air cleaner filter
4. Clamp 5. Air duct assembly 6. Clamp
7. PCV hose 8. Air duct (inlet) 9. Grommet
10. Collar 11. Grommet 12. Grommet
13. Bracket 14. Bracket 15. Collar
16. Grommet 17. Air cleaner case (lower)
A. To electric throttle control actuator B. To rocker cover (bank 2) C. VQ25DE
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA2193GB
Page 1902 of 5121
AIR CLEANER AND AIR DUCT
EM-27
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Never touch mass air flow sensor.
INSTALLATION
Note the following, and install in the reverse order of removal.
Align marks. Attach each joint. Screw clamps firmly.
InspectionINFOID:0000000003802252
INSPECTION AFTER REMOVAL
Inspect air duct assembly for crack or tear.
If anything found, replace air duct assembly.
Page 1903 of 5121
EM-28
< ON-VEHICLE REPAIR >
INTAKE MANIFOLD COLLECTOR
INTAKE MANIFOLD COLLECTOR
Exploded ViewINFOID:0000000003802253
VQ25DE
VQ35DE
1. Vacuum hose 2. Clamp 3. Clamp
4. PCV hose 5. Intake manifold collector 6. Gasket
7. Vacuum hose 8. VIAS control solenoid valve 9. Vacuum hose
10. Bracket 11.Electronic controlled engine mount
control solenoid valve12. Vacuum hose
13. Vacuum hose 14. Vacuum gallery 15. Vacuum hose
16.EVAP canister purge control solenoid
valve17. Clamp 18. EVAP hose
19. Service port 20. Bracket 21. EVAP hose
22. EVAP hose 23. EVAP pipe 24. EVAP hose
25. Clamp 26. Water hose 27. Water hose
28. Bracket 29. Electric throttle control actuator 30. Gasket
A. To brake booster B. To rocker cover (bank 1) C. To vacuum tube (rear)
D. To vacuum pipe E. To heater pipe F. To water outlet
: Engine front
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA2194GB
Page 1904 of 5121

INTAKE MANIFOLD COLLECTOR
EM-29
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Removal and InstallationINFOID:0000000003802254
REMOVAL
WARNING:
To avoid the danger of being scalded, never drain engine coolant when the engine is hot.
1. Remove engine cover. Refer to EM-24, "
Exploded View".
CAUTION:
Be careful not to damage or scratch engine cover.
1. Vacuum hose 2. Clamp 3. Clamp
4. PCV hose 5. Intake manifold collector 6. Gasket
7. Vacuum hose 8. Bracket 9.Electronic controlled engine mount
control solenoid valve
10. Vacuum hose 11. Vacuum hose 12. Vacuum hose
13. Vacuum gallery 14. Vacuum hose 15. Vacuum hose
16. VIAS control solenoid valve 2 17. VIAS control solenoid valve 1 18.EVAP canister purge control solenoid
valve
19. Clamp 20. EVAP hose 21. Service port
22. Bracket 23. EVAP hose 24. EVAP hose
25. EVAP pipe 26. EVAP hose 27. Clamp
28. Water hose 29. Water hose 30. Bracket
31. Electric throttle control actuator 32. Gasket
A. To brake booster B. To rocker cover (bank 1) C. To vacuum tube (rear)
D. To vacuum pipe E. To heater pipe F. To water outlet
: Engine front
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA1713GB
