EC-340
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
FUEL PUMP
YES >> GO TO 13.
NO >> Repair open circuit or short to power in harness or connectors.
13.CHECK FUEL PUMP
Refer to EC-340, "
Component Inspection (Fuel Pump)".
Is the inspection result normal?
YES >> GO TO 14.
NO >> Replace fuel pump.
14.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace harness or connectors.
Component Inspection (Fuel Pump)INFOID:0000000003856846
1.CHECK FUEL PUMP
1. Turn ignition switch OFF.
2. Disconnect “fuel level sensor unit and fuel pump” harness connector.
3. Check resistance between “fuel level sensor unit and fuel pump” terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace “fuel level sensor unit and fuel pump”
Component Inspection (Condenser)INFOID:0000000003856847
1.CHECK CONDENSER
1. Turn ignition switch OFF.
2. Disconnect condenser harness connector.
3. Check resistance between condenser terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace condenser.
Terminals Resistance
1 and 3 0.2 - 5.0 Ω [at 25°C (77°F)]
Terminals Resistance
1 and 2 Above 1 MΩ [at 25°C (77°F)]
Page 1802 of 5121
![NISSAN TEANA 2008 Service Manual IGNITION SIGNAL
EC-341
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
IGNITION SIGNAL
DescriptionINFOID:0000000003856848
The ignition signal from the ECM is sent to and amplif NISSAN TEANA 2008 Service Manual IGNITION SIGNAL
EC-341
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
IGNITION SIGNAL
DescriptionINFOID:0000000003856848
The ignition signal from the ECM is sent to and amplif](/manual-img/5/57391/w960_57391-1801.png)
IGNITION SIGNAL
EC-341
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
IGNITION SIGNAL
DescriptionINFOID:0000000003856848
The ignition signal from the ECM is sent to and amplified by the power transistor. The power transistor turns
ON and OFF the ignition coil primary circuit. This ON/OFF operation induces the proper high voltage in the coil
secondary circuit.
Component Function CheckINFOID:0000000003856849
1.INSPECTION START
Turn ignition switch OFF, and restart engine.
Does the engine start?
YES-1 >> With CONSULT-III: GO TO 2.
YES-2 >> Without CONSULT-III: GO TO 3.
NO >> Go to EC-341, "
Diagnosis Procedure".
2.CHECK IGNITION SIGNAL FUNCTION
With CONSULT-III
1. Perform “POWER BALANCE” in “ACTIVE TEST” mode with CONSULT-III.
2. Check that each circuit produces a momentary engine speed drop.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-341, "
Diagnosis Procedure".
3.CHECK IGNITION SIGNAL FUNCTION
Without CONSULT-III
1. Let engine idle.
2. Read the voltage signal between ECM harness connector ground with an oscilloscope.
NOTE:
The pulse cycle changes depending on rpm at idle.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-341, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003856850
1.CHECK IGNITION COIL POWER SUPPLY CIRCUIT-I
1. Turn ignition switch OFF, wait at least 10 seconds and then turn it ON.
2. Check the voltage between ECM harness connector and ground.
ECM
Ground Voltage signal
Connector Terminal
F79
Ground 10
11
18
19
21
JMBIA0035GB
ECM
Ground Voltage
Connector Terminal
E16 105 Ground Battery voltage
Page 1803 of 5121
![NISSAN TEANA 2008 Service Manual EC-342
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refer to EC-132, "
Diagnosis Procedure".
2.CHECK IGNITION COIL POWER SUPPLY CIRCUI NISSAN TEANA 2008 Service Manual EC-342
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refer to EC-132, "
Diagnosis Procedure".
2.CHECK IGNITION COIL POWER SUPPLY CIRCUI](/manual-img/5/57391/w960_57391-1802.png)
EC-342
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
Is the inspection result normal?
YES >> GO TO 2.
NO >> Refer to EC-132, "
Diagnosis Procedure".
2.CHECK IGNITION COIL POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect condenser harness connector.
3. Turn ignition switch ON.
4. Check the voltage between condenser harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.CHECK IGNITION COIL POWER SUPPLY CIRCUIT-III
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between IPDM E/R harness connector and condenser harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> Refer to EC-132, "Diagnosis Procedure".
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
4.CHECK CONDENSER GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Check the continuity between condenser harness connector and ground.
3. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to power in harness or connectors.
5.CHECK CONDENSER
Refer to EC-345, "
Component Inspection (Condenser)"
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace condenser.
6.CHECK IGNITION COIL POWER SUPPLY CIRCUIT-V
1. Reconnect all harness connectors disconnected.
2. Disconnect ignition coil harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ignition coil harness connector and ground.
Condenser
Ground Voltage
Connector Terminal
F13 1 Ground Battery voltage
IPDM E/R Condenser
Continuity
Connector Terminal Connector Terminal
F1249F13 1Existed
Condenser
Ground Continuity
Connector Terminal
F13 2 Ground Existed
Page 1804 of 5121
![NISSAN TEANA 2008 Service Manual IGNITION SIGNAL
EC-343
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness or connectors.
7.CHECK I NISSAN TEANA 2008 Service Manual IGNITION SIGNAL
EC-343
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness or connectors.
7.CHECK I](/manual-img/5/57391/w960_57391-1803.png)
IGNITION SIGNAL
EC-343
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness or connectors.
7.CHECK IGNITION COIL GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Check the continuity between ignition coil harness connector and ground.
3. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair open circuit or short to power in harness or connectors.
8.CHECK IGNITION COIL OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect ECM harness connector.
2. Check the continuity between ignition coil harness connector and ECM harness connector.
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
9.CHECK IGNITION COIL WITH POWER TRANSISTOR
Refer to EC-344, "
Component Inspection (Ignition Coil with Power Transistor)".
Is the inspection result normal?
Ignition coil
Ground Voltage
Cylinder Connector Terminal
1F313
Ground Battery voltage 2F323
3F333
4F343
5F353
6F363
Ignition coil
Ground Continuity
Cylinder Connector Terminal
1F312
Ground Existed 2F322
3F332
4F342
5F352
6F362
Ignition coil ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F311
F711
Existed 2F321 10
3F331 9
4F341 21
5F351 19
6F361 18
Page 1805 of 5121
![NISSAN TEANA 2008 Service Manual EC-344
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
YES >> GO TO 10.
NO >> Replace malfunctioning ignition coil with power transistor.
10.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Inter NISSAN TEANA 2008 Service Manual EC-344
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
YES >> GO TO 10.
NO >> Replace malfunctioning ignition coil with power transistor.
10.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Inter](/manual-img/5/57391/w960_57391-1804.png)
EC-344
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
IGNITION SIGNAL
YES >> GO TO 10.
NO >> Replace malfunctioning ignition coil with power transistor.
10.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (Ignition Coil with Power Transistor)INFOID:0000000003856851
1.CHECK IGNITION COIL WITH POWER TRANSISTOR-I
1. Turn ignition switch OFF.
2. Disconnect ignition coil harness connector.
3. Check resistance between ignition coil terminals as per the following.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace malfunctioning ignition coil with power transistor.
2.CHECK IGNITION COIL WITH POWER TRANSISTOR-II
CAUTION:
Perform the following procedure in a place with no combustible objects and good ventilation.
1. Turn ignition switch OFF.
2. Reconnect all harness connectors disconnected.
3. Remove fuel pump fuse in IPDM E/R to release fuel pressure.
NOTE:
Do not use CONSULT-III to release fuel pressure, or fuel pressure applies again during the following pro-
cedure.
4. Start engine.
5. After engine stalls, crank it 2 or 3 times to release all fuel pressure.
6. Turn ignition switch OFF.
7. Remove all ignition coil harness connectors to avoid the electrical discharge from the ignition coils.
8. Remove ignition coil and spark plug of the cylinder to be checked.
9. Crank engine for 5 seconds or more to remove combustion gas in the cylinder.
10. Connect spark plug and harness connector to ignition coil.
11. Fix ignition coil using a rope etc. with gap of 13 - 17 mm (0.52 -
0.66 in) between the edge of the spark plug and grounded metal
portion as shown in the figure.
12. Crank engine for about 3 seconds, and check whether spark is
generated between the spark plug and the grounded metal por-
tion.
CAUTION:
Never place to the spark plug and the ignition coil within
50 cm (19.7 in) each other. Be careful not to get an electri-
cal shock while checking, because the electrical dis-
charge voltage becomes 20 kV or more.
It might damage the ignition coil if the gap of more than 17 mm (0.66 in) is made.
NOTE:
When the gap is less than 13 mm (0.52 in), a spark might be generated even if the coil is a malfunc-
tioning.
Is the inspection result normal?
Terminal No. (Polarity) Resistance Ω [at 25°C (77°F)]
1 and 2 Except 0 or ∞
1 and 3
Except 0
2 and 3
Spark should be generated.
JMBIA0066GB
Page 1806 of 5121
IGNITION SIGNAL
EC-345
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> INSPECTION END
NO >> Replace malfunctioning ignition coil with power transistor.
Component Inspection (Condenser)INFOID:0000000003856852
1.CHECK CONDENSER
1. Turn ignition switch OFF.
2. Disconnect condenser harness connector.
3. Check resistance between condenser terminals as per the following.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace condenser.
Terminals Resistance
1 and 2 Above 1 MΩ [at 25C° (77C°)]
Page 1807 of 5121
![NISSAN TEANA 2008 Service Manual EC-346
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
MALFUNCTION INDICATOR
MALFUNCTION INDICATOR
DescriptionINFOID:0000000003856853
The Malfunction Indicator MI is located on the combination meter.
The MI w NISSAN TEANA 2008 Service Manual EC-346
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
MALFUNCTION INDICATOR
MALFUNCTION INDICATOR
DescriptionINFOID:0000000003856853
The Malfunction Indicator MI is located on the combination meter.
The MI w](/manual-img/5/57391/w960_57391-1806.png)
EC-346
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
MALFUNCTION INDICATOR
MALFUNCTION INDICATOR
DescriptionINFOID:0000000003856853
The Malfunction Indicator MI is located on the combination meter.
The MI will illuminate when the ignition switch is turned ON without
the engine running. This is a bulb check.
When the engine is started, the MI should turn off. If the MI remains
illuminated, the on board diagnostic system has detected an engine
system malfunction.
For details, refer to EC-102, "
Diagnosis Description".
Component Function CheckINFOID:0000000003856854
1.CHECK MI FUNCTION
1. Turn ignition switch ON.
2. Check that MI illuminates.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-346, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003856855
1.CHECK DTC
Check that DTC U1000 or U1001 is not displayed.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble diagnosis for DTC U1000, U1001. Refer to EC-135, "
Description".
2.CHECK COMBINATION METER FUNCTION
Refer to MWI-33, "
CONSULT-III Function (METER/M&A)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace.
3.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace combination meter.
NO >> Repair or replace.
SEF217U
Page 1808 of 5121
![NISSAN TEANA 2008 Service Manual POSITIVE CRANKCASE VENTILATION
EC-347
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000003856860
This system returns blow NISSAN TEANA 2008 Service Manual POSITIVE CRANKCASE VENTILATION
EC-347
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000003856860
This system returns blow](/manual-img/5/57391/w960_57391-1807.png)
POSITIVE CRANKCASE VENTILATION
EC-347
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000003856860
This system returns blow-by gas to the intake manifold.
The positive crankcase ventilation (PCV) valve is provided to conduct crankcase blow-by gas to the intake
manifold.
During partial throttle operation of the engine, the intake manifold sucks the blow-by gas through the PCV
valve.
Normally, the capacity of the valve is sufficient to handle any blow-by and a small amount of ventilating air.
The ventilating air is drawn from the air inlet tubes into the crankcase. In this process the air passes through
the hose connecting air inlet tubes to rocker cover.
Under full-throttle condition, the manifold vacuum is insufficient to draw the blow-by flow through the valve.
The flow goes through the hose connection in the reverse direction.
On vehicles with an excessively high blow-by, the valve does not
meet the requirement. This is because some of the flow will go
through the hose connection to the air inlet tubes under all condi-
tions.
Component InspectionINFOID:0000000003856861
1.CHECK PCV VALVE
With engine running at idle, remove PCV valve from rocker cover. A
properly working valve makes a hissing noise as air passes through
it. A strong vacuum should be felt immediately when a finger is
placed over valve inlet.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace PCV valve.
SEC921C
PBIB1588E
PBIB1589E
