NISSAN TEANA 2008 Service Manual TM-248
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0868 SECONDARY PRESSURE DOWN
2.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve B (second

TM-248
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P0868 SECONDARY PRESSURE DOWN
2.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve B (secondary pressure solenoid valve). Refer to TM-248, "
Component
Inspection [Pressure Control Solenoid Valve B (Secondary Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
Check pressure control solenoid valve A (line pressure solenoid valve). Refer to TM-248, "
Component Inspec-
tion [Pressure Control Solenoid Valve A (Line Pressure Solenoid Valve)]".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK TRANSMISSION FLUID PRESSURE SENSOR A (SECONDARY PRESSURE SENSOR) SYS-
TEM
Check transmission fluid pressure sensor A (secondary pressure sensor) system. Refer to TM-242, "
Descrip-
tion".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts.
5.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection [Pressure Control Solenoid Valve A (Line Pressure Solenoid
Va l v e ) ]
INFOID:0000000003806447
1.CHECK PRESSURE CONTROL SOLENOID VALVE A (LINE PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
Component Inspection [Pressure Control Solenoid Valve B (Secondary Pressure So-
lenoid Valve)]
INFOID:0000000003806448
1.CHECK PRESSURE CONTROL SOLENOID VALVE B (SECONDARY PRESSURE SOLENOID VALVE)
Check resistance between CVT unit harness connector terminal and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace the transaxle assembly. Refer to TM-332, "
Exploded View".
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 2 3.0 – 9.0 Ω
CVT unit harness connector
GroundResistance (Approx.)
Connector Terminal
F24 3 3.0 – 9.0 Ω

Page 4722 of 5121

NISSAN TEANA 2008 Service Manual P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
TM-249
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
DescriptionINFOID:0000000

Page 4723 of 5121

NISSAN TEANA 2008 Service Manual TM-250
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 2.
2.CHECK TCM GROUND CIRCUIT
1. Turn ignitio

Page 4724 of 5121

NISSAN TEANA 2008 Service Manual P1701 TRANSMISSION CONTROL MODULE (POWER SUPPLY)
TM-251
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
4. Disconnect fuse block J/B connector.
5. Check continuity between TCM ve

Page 4725 of 5121

NISSAN TEANA 2008 Service Manual TM-252
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P1705 THROTTLE POSITION SENSOR
P1705 THROTTLE POSITION SENSOR
DescriptionINFOID:0000000003806452
The electric throttle control actuator consists of throttl

TM-252
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P1705 THROTTLE POSITION SENSOR
P1705 THROTTLE POSITION SENSOR
DescriptionINFOID:0000000003806452
The electric throttle control actuator consists of throttle control motor, accelerator pedal position sensor, throt-
tle position sensor, etc. The actuator sends a signal to the ECM, and ECM sends the signal to TCM via CAN
communication.
DTC LogicINFOID:0000000003806453
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF.Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Depress accelerator pedal fully and release it, then wait for 5 seconds.
3. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“P1705 TP SEN/CIRC A/T” detected?
YES >> Go to TM-252, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806454
1.CHECK DTC WITH ECM
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” mode for “ENGINE”.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check the DTC Detected Item. Refer to EC-113, "
CONSULT-III Function".
2.CHECK DTC WITH TCM
With CONSULT-III
Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“P1705 TP SEN /CIRC A/T” detected?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> GO TO 3.
3.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> Repair or replace damaged parts.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1705 TP SEN/CIRC A/TTCM does not receive the prop-
er accelerator pedal position
signals (input by CAN commu-
nication) from ECM.ECM
Harness or connectors
(CAN communication line is
open or shorted.)

Page 4726 of 5121

NISSAN TEANA 2008 Service Manual P1722 ESTM VEHICLE SPEED SIGNAL
TM-253
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1722 ESTM VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000003806455
The vehicle speed signal

P1722 ESTM VEHICLE SPEED SIGNAL
TM-253
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1722 ESTM VEHICLE SPEED SIGNAL
DescriptionINFOID:0000000003806455
The vehicle speed signal is transmitted from ABS actuator and electric unit (control unit) to TCM via CAN com-
munication line.
DTC LogicINFOID:0000000003806456
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds.
Is
“P1722 ESTM VEH SPD SIG” detected?
YES >> Go to TM-253, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806457
1.CHECK DTC WITH ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” mode for “ABS”.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check DTC detected item. Refer to BRC-48, "
DTC No. Index" (ABS), BRC-140, "DTC No. Index"
(VDC/TCS/ABS).
2.CHECK DTC WITH TCM
With CONSULT-III
Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“P1722 ESTM VEH SPD SIG” detected?
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1722 ESTM VEH SPD SIG CAN communication with the
ABS actuator and the electric
unit (control unit) is malfunc-
tioning.
There is a big difference be-
tween the vehicle speed sig-
nal from the ABS actuator
and the electric unit (control
unit), and the vehicle speed
sensor signal. Harness or connectors
(Sensor circuit is open or
shorted.)
ABS actuator and electric
unit (control unit)
ACC PEDAL OPEN : 1.0/8 or less
VEHICLE SPEED : 30 km/h (19 MPH) or more

Page 4727 of 5121

NISSAN TEANA 2008 Service Manual TM-254
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
P1722 ESTM VEHICLE SPEED SIGNAL
YES >> Replace TCM. Refer to TM-315, "Exploded View".
NO >> GO TO 3.
3.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin

Page 4728 of 5121

NISSAN TEANA 2008 Service Manual P1723 CVT SPEED SENSOR FUNCTION
TM-255
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1723 CVT SPEED SENSOR FUNCTION
DescriptionINFOID:0000000003806458
The vehicle speed sensor

P1723 CVT SPEED SENSOR FUNCTION
TM-255
< COMPONENT DIAGNOSIS >[CVT: RE0F10A]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1723 CVT SPEED SENSOR FUNCTION
DescriptionINFOID:0000000003806458
The vehicle speed sensor CVT [output speed sensor (secondary speed sensor)] detects the revolution of
parking gear and generates a pulse signal. The pulse signal is sent to the TCM, which converts it into vehicle
speed.
The input speed sensor (primary speed sensor) detects the primary pulley revolution speed and sends the sig-
nal to the TCM.
DTC LogicINFOID:0000000003806459
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch
OFF. Then wait at least 10 seconds before performing the next test.
Perform the following procedure to confirm the malfunction is eliminated after the repair.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds.
Is
“P1723 CVT SPD SEN/FNCTN” detected?
YES >> Go to TM-255, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003806460
1.CHECK STEP MOTOR FUNCTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Self Diagnostic Results” mode for “TRANSMISSION”.
Is
“P1778 STEP MOTR/FNC” detected?
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1723 CVT SPD SEN/FNCTNA rotation sensor error is de-
tected when the gear does not
change in accordance with the
position of the stepping motor.
CAUTION:
One of the “P0720 VEH SPD
SEN/CIR AT”, the “P0715 IN-
PUT SPD SEN/CIRC” or the
“P0725 ENGINE SPEED SIG“
is displayed with the DTC at
the same time. Harness or connectors
(Sensor circuit is open or
shorted.)
Output speed sensor (sec-
ondary speed sensor)
Input speed sensor (primary
speed sensor)
Engine speed signal system
VEHICLE SPEED : 10 km/h (6 MPH) or more
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
ENG SPEED : 450 rpm or more
Driving location : Driving the vehicle uphill (increased engine load) will help maintain the
driving conditions required for this test.
