![NISSAN TEANA 2008 Service Manual EC-132
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000003856508
1.CHECK GROUND CONNECTION-I
1. Turn ignition s NISSAN TEANA 2008 Service Manual EC-132
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000003856508
1.CHECK GROUND CONNECTION-I
1. Turn ignition s](/manual-img/5/57391/w960_57391-1592.png)
EC-132
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000003856508
1.CHECK GROUND CONNECTION-I
1. Turn ignition switch OFF.
2. Check ground connection E38. Refer to Ground Inspection in GI-37, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ECM GROUND CIRCUIT FOR OPEN AND SHORT-I
1. Disconnect ECM harness connector.
2. Check the continuity between ECM harness connector and ground.
3. Also check harness for short to power.
is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors F121, E7
Harness for open or short between ECM and ground
>> Repair open circuit, short to power in harness or connectors.
4.CHECK ECM POWER SUPPLY CIRCUIT-I
1. Reconnect ECM harness connector.
2. Turn ignition switch OFF and then ON.
3. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
IPDM E/R connector E10
10A fuse (No. 44)
Harness for open or short between ECM and fuse
ECM
Ground Continuity
Connector Terminal
F712
Ground Existed 16
E16107
108
111
11 2
ECM
Ground Voltage
Connector Terminal
E16 93 Ground Battery voltage
Page 1594 of 5121
![NISSAN TEANA 2008 Service Manual POWER SUPPLY AND GROUND CIRCUIT
EC-133
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHE NISSAN TEANA 2008 Service Manual POWER SUPPLY AND GROUND CIRCUIT
EC-133
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHE](/manual-img/5/57391/w960_57391-1593.png)
POWER SUPPLY AND GROUND CIRCUIT
EC-133
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> Repair open circuit, short to ground or short to power in harness or connectors.
6.CHECK ECM POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 9.
7.CHECK ECM POWER SUPPLY CIRCUIT-III
1. Turn ignition switch ON.
2. Check the voltage between IPDM E/R harness connector and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Replace IPDM E/R.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
9.CHECK ECM POWER SUPPLY CIRCUIT-IV
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 10.
10.CHECK ECM POWER SUPPLY CIRCUIT-V
1. Disconnect ECM harness connector.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between ECM harness connector and IPDM E/R harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
ECM
Ground Voltage
Connector Terminal
E16 105 GroundAfter turning ignition switch OFF, battery
voltage will exist for a few seconds, then
drop to approximately 0 V.
IPDM E/R
Ground Voltage
Connector Terminal
F1249
Ground Battery voltage
53
ECM
Ground Voltage
Connector Terminal
F7 24 Ground Battery voltage
ECM IPDM E/R
Continuity
Connector Terminal Connector Terminal
F7 24 F12 69 Existed
Page 1595 of 5121
![NISSAN TEANA 2008 Service Manual EC-134
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 11.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
11 .CHECK 15A FUS NISSAN TEANA 2008 Service Manual EC-134
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 11.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
11 .CHECK 15A FUS](/manual-img/5/57391/w960_57391-1594.png)
EC-134
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 11.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
11 .CHECK 15A FUSE
1. Disconnect 15A fuse (No. 50) from IPDM E/R.
2. Check 15A fuse.
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace 15A fuse.
12.CHECK ECM POWER SUPPLY CIRCUIT-VI
1. Disconnect ECM harness connector.
2. Disconnect IPDM E/R harness connector.
3. Check the continuity between ECM harness connector and IPDM E/R harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 13.
NO >> Repair open circuit, short to ground or short to power in harness or connectors.
13.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace harness or connectors.
ECM IPDM E/R
Continuity
Connector Terminal Connector Terminal
E16 105 E10 10 Existed
Page 1596 of 5121
![NISSAN TEANA 2008 Service Manual U1000, U1001 CAN COMM CIRCUIT
EC-135
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
U1000, U1001 CAN COMM CIRCUIT
DescriptionINFOID:0000000003856509
CAN (Controller Area Netwo NISSAN TEANA 2008 Service Manual U1000, U1001 CAN COMM CIRCUIT
EC-135
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
U1000, U1001 CAN COMM CIRCUIT
DescriptionINFOID:0000000003856509
CAN (Controller Area Netwo](/manual-img/5/57391/w960_57391-1595.png)
U1000, U1001 CAN COMM CIRCUIT
EC-135
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
U1000, U1001 CAN COMM CIRCUIT
DescriptionINFOID:0000000003856509
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
DTC LogicINFOID:0000000003856510
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON and wait at least 3 seconds.
2. Check DTC.
Is DTC detected?
YES >>EC-135, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856511
Go to LAN-14, "Trouble Diagnosis Flow Chart".
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
U1000
CAN communication
lineWhen ECM is not transmitting or receiving CAN com-
munication signal of OBD (emission related diagno-
sis) for 2 seconds or more. Harness or connectors
(CAN communication line is open or
shorted)
U1001When ECM is not transmitting or receiving CAN com-
munication signal other than OBD (emission related
diagnosis) for 2 seconds or more.
Page 1597 of 5121
![NISSAN TEANA 2008 Service Manual EC-136
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000003856512
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P0021 is displayed with DTC NISSAN TEANA 2008 Service Manual EC-136
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000003856512
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P0021 is displayed with DTC](/manual-img/5/57391/w960_57391-1596.png)
EC-136
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
P0011, P0021 IVT CONTROL
DTC LogicINFOID:0000000003856512
DTC DETECTION LOGIC
NOTE:
If DTC P0011 or P0021 is displayed with DTC P0075, P0081, first perform the trouble diagnosis for DTC
P0075, P0081. Refer to EC-146, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is between 10 V and 16 V at
idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE-I
With CONSULT-III
1. Turn ignition switch ON and select “DATA MONITOR” mode with CONSULT-III.
2. Start engine and warm it up to the normal operating temperature.
3. Maintain the following conditions for at least 6 consecutive seconds. Hold the accelerator pedal as steady
as possible.
CAUTION:
Always drive at a safe speed.
4. Stop vehicle with engine running and let engine idle for 10 seconds.
5. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-137, "Diagnosis Procedure"
NO >> GO TO 3.
3.PERFORM DTC CONFIRMATION PROCEDURE-II
With CONSULT-III
1. Maintain the following conditions for at least 20 consecutive seconds.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
P0011Intake valve timing
control performance
(bank 1)
There is a gap between angle of target and
phase-control angle degree. Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)
Intake valve timing control solenoid valve
Accumulation of debris to the signal pick-up
portion of the camshaft
Timing chain installation
Foreign matter caught in the oil groove for in-
take valve timing control P0021Intake valve timing
control performance
(bank 2)
VHCL SPEED SE 100 - 120 km/h (63 - 75 mph)
ENG SPEED 1,200 - 2,000 rpm
COOLAN TEMP/S More than 60°C (140°F)
B/FUEL SCHDL More than 7.3 msec
Selector lever D position
Page 1598 of 5121
![NISSAN TEANA 2008 Service Manual P0011, P0021 IVT CONTROL
EC-137
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “W NISSAN TEANA 2008 Service Manual P0011, P0021 IVT CONTROL
EC-137
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “W](/manual-img/5/57391/w960_57391-1597.png)
P0011, P0021 IVT CONTROL
EC-137
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
CAUTION:
Always drive at a safe speed.
2. Check 1st trip DTC.
With GST
Follow the procedure “With CONSULT-III” above.
Is 1st trip DTC detected?
YES >> Go to EC-137, "Diagnosis Procedure"
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003856513
1.CHECK OIL PRESSURE WARNING LAMP
1. Start engine.
2. Check oil pressure warning lamp and confirm it is not illumi-
nated.
Is oil pressure warming lamp illuminated?
YES >> Go to LU-7, "Inspection".
NO >> GO TO 2.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE
Refer to EC-138, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Replace malfunctioning intake valve timing control solenoid valve.
3.CHECK CRANKSHAFT POSITION SENSOR (POS)
Refer to EC-221, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace crankshaft position sensor (POS).
4.CHECK CAMSHAFT POSITION SENSOR (PHASE)
Refer to EC-224, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning camshaft position sensor (PHASE).
5.CHECK CAMSHAFT (INTAKE)
Check the following.
ENG SPEED 1,200 - 3,175 rpm (A constant rotation is maintained.)
COOLAN TEMP/S More than 70°C (158°F)
Selector lever 1st or 2nd position
Driving location uphillDriving vehicle uphill
(Increased engine load will help maintain the driving conditions re-
quired for this test.)
PBIA8559J
Page 1599 of 5121
![NISSAN TEANA 2008 Service Manual EC-138
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
Accumulation of debris on the signal plate of camshaft rear end
Chipping signal plate of camshaft rear end
Is the inspection NISSAN TEANA 2008 Service Manual EC-138
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
Accumulation of debris on the signal plate of camshaft rear end
Chipping signal plate of camshaft rear end
Is the inspection](/manual-img/5/57391/w960_57391-1598.png)
EC-138
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
P0011, P0021 IVT CONTROL
Accumulation of debris on the signal plate of camshaft rear end
Chipping signal plate of camshaft rear end
Is the inspection result normal?
YES >> GO TO 6.
NO >> Remove debris and clean the signal plate of camshaft
rear end or replace camshaft.
6.CHECK TIMING CHAIN INSTALLATION
Check service records for any recent repairs that may cause timing chain misaligned.
Are there any service records that may cause timing chain misaligned?
YES >> Check timing chain installation. Refer to EM-53, "Removal and Installation".
NO >> GO TO 7.
7.CHECK LUBRICATION CIRCUIT
Refer to EM-53, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Clean lubrication line.
8.CHECK INTERMITTENT INCIDENT
Refer to GI-35, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000003856514
1.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-I
1. Disconnect intake valve timing control solenoid valve harness connector.
2. Check resistance between intake valve timing control solenoid valve terminals as per the following.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace malfunctioning intake valve timing control solenoid valve.
2.CHECK INTAKE VALVE TIMING CONTROL SOLENOID VALVE-II
1. Remove intake valve timing control solenoid valve.
2. Provide 12 V DC between intake valve timing control solenoid
valve terminals 1 and 2, and then interrupt it. Check that the
plunger moves as shown in the figure.
CAUTION:
Never apply 12 V DC continuously for 5 seconds or more.
Doing so may result in damage to the coil in intake valve
timing control solenoid valve.
NOTE:
Always replace O-ring when intake valve timing control
solenoid valve is removed.
Is the inspection result normal?
YES >> INSPECTION END
JMBIA0058ZZ
Terminals Resistance
1 and 2 7.0 - 7.5 Ω [at 20°C (68°F)]
1 or 2 and ground∞ Ω
(Continuity should not exist)
JMBIA0079ZZ
Page 1600 of 5121
P0011, P0021 IVT CONTROL
EC-139
< COMPONENT DIAGNOSIS >[VQ25DE, VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Replace malfunctioning intake valve timing control solenoid valve.
