LAN-46
< COMPONENT DIAGNOSIS >[CAN]
CAN COMMUNICATION CIRCUIT
CAN COMMUNICATION CIRCUIT
Diagnosis ProcedureINFOID:0000000003767704
1.CONNECTOR INSPECTION
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect all the unit connectors on CAN communication system.
4. Check terminals and connectors for damage, bend and loose connection.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check the harness and repair the root cause.
3.CHECK HARNESS CONTINUITY (SHORT CIRCUIT)
Check the continuity between the data link connector and the ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Check the harness and repair the root cause.
4.CHECK ECM AND IPDM E/R TERMINATION CIRCUIT
1. Remove the ECM and the IPDM E/R.
2. Check the resistance between the ECM terminals.
3. Check the resistance between the IPDM E/R terminals.
Is the measurement value within the specification?
YES >> GO TO 5.
NO >> Replace the ECM and/or the IPDM E/R.
5.CHECK SYMPTOM
Connect all the connectors. Check if the symptoms described in the “Symptom (Results from interview with
customer)” are reproduced.
Data link connector
Continuity
Connector No. Terminal No.
M4 6 14 Not existed
Data link connector
GroundContinuity
Connector No. Terminal No.
M46 Not existed
14 Not existed
ECM
Resistance (Ω)
Te r m i n a l N o .
98 97 Approx. 108 – 132
IPDM E/R
Resistance (Ω)
Te r m i n a l N o .
40 39 Approx. 108 – 132
LKIA0037E
Page 3114 of 5121
![NISSAN TEANA 2008 Service Manual LAN
CAN COMMUNICATION CIRCUIT
LAN-47
< COMPONENT DIAGNOSIS >[CAN]
C
D
E
F
G
H
I
J
K
L B A
O
P N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble dia NISSAN TEANA 2008 Service Manual LAN
CAN COMMUNICATION CIRCUIT
LAN-47
< COMPONENT DIAGNOSIS >[CAN]
C
D
E
F
G
H
I
J
K
L B A
O
P N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble dia](/manual-img/5/57391/w960_57391-3113.png)
LAN
CAN COMMUNICATION CIRCUIT
LAN-47
< COMPONENT DIAGNOSIS >[CAN]
C
D
E
F
G
H
I
J
K
L B A
O
P N
Inspection result
Reproduced>>GO TO 6.
Non-reproduced>>Start the diagnosis again. Follow the trouble diagnosis procedure when past error is
detected.
6.CHECK UNIT REPRODUCTION
Perform the reproduction test as per the following procedure for each unit.
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect one of the unit connectors of CAN communication system.
NOTE:
ECM and IPDM E/R have a termination circuit. Check other units first.
4. Connect the battery cable to the negative terminal. Check if the symptoms described in the “Symptom
(Results from interview with customer)” are reproduced.
NOTE:
Although unit-related error symptoms occur, do not confuse them with other symptoms.
Inspection result
Reproduced>>Connect the connector. Check other units as per the above procedure.
Non-reproduced>>Replace the unit whose connector was disconnected.
Page 3115 of 5121
LAN-48
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
MAIN LINE BETWEEN DLC AND BCM CIRCUIT
COMPONENT DIAGNOSIS
MAIN LINE BETWEEN
DLC AND BCM CIRCUIT
Diagnosis ProcedureINFOID:0000000004459797
INSPECTION PROCEDURE
1.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Disconnect the following harness connectors.
-ECM
-BCM
4. Check the continuity between the data link connector and the BCM harness connector.
Is the inspection result normal?
YES (Present error)>>Check CAN system type decision again.
YES (Past error)>>Error was detected in the main line between the data link connector and the BCM.
NO >> Repair the main line between the data link connector and the BCM.
Data link connector BCM harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M4 6
M122 91 Existed
14 90 Existed
Page 3116 of 5121
![NISSAN TEANA 2008 Service Manual LAN
MAIN LINE BETWEEN BCM AND ABS CIRCUITLAN-49
< COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
BCM AND ABS CIRCUIT
Diagnosis ProcedureINFOID:00000000044 NISSAN TEANA 2008 Service Manual LAN
MAIN LINE BETWEEN BCM AND ABS CIRCUITLAN-49
< COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
BCM AND ABS CIRCUIT
Diagnosis ProcedureINFOID:00000000044](/manual-img/5/57391/w960_57391-3115.png)
LAN
MAIN LINE BETWEEN BCM AND ABS CIRCUITLAN-49
< COMPONENT DIAGNOSIS > [CAN SYSTEM (TYPE 2)]
C
D
E
F
G H
I
J
K L
B A
O P
N
MAIN LINE BETWEEN
BCM AND ABS CIRCUIT
Diagnosis ProcedureINFOID:0000000004459798
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cabl e from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (connector side
and harness side).
- Harness connector M11
- Harness connector E105
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the following harness connectors.
-BCM
- Harness connectors M11 and E105
2. Check the continuity between the BC M harness connector and the harness connector.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair the main line between the BCM and the harness connector M11.
3.CHECK HARNESS CONTI NUITY (OPEN CIRCUIT)
1. Disconnect the connector of ABS actuat or and electric unit (control unit).
2. Check the continuity between the harness connector and the ABS actuator and electric unit (control unit)
harness connector.
- Models with ABS
- Models with VDC
Is the inspection result normal?
YES (Present error)>>Check CA N system type decision again.
YES (Past error)>>Error was detected in the main line between the BCM and the ABS actuator and electric
unit (control unit).
NO >> Repair the main line between the harness connec tor E105 and the ABS actuator and electric unit
(control unit).
BCM harness connector Harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
M122 91
M11 12 Existed
90 11 Existed
Harness connector ABS actuator and electric unit (control unit)
harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
E105 12
E34 26 Existed
11 1 5 E x i s t e d
Harness connector ABS actuator and electric unit (control unit)
harness connector Continuity
Connector No. Terminal No. Connector No. Terminal No.
E105 12
E36 26 Existed
11 1 5 E x i s t e d
Page 3117 of 5121
![NISSAN TEANA 2008 Service Manual LAN-50
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841869
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis NISSAN TEANA 2008 Service Manual LAN-50
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841869
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis](/manual-img/5/57391/w960_57391-3116.png)
LAN-50
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
ECM BRANCH LINE CIRCUIT
ECM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841869
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the following terminals and connectors for damage, bend and loose connection (unit side and con-
nector side).
-ECM
- Harness connector E105
- Harness connector M11
- Harness connector M77 (Models with automatic drive positioner)
- Harness connector B11 (Models with automatic drive positioner)
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ECM.
2. Check the resistance between the ECM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ECM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ECM. Refer to EC-132, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the ECM. Refer to EC-14, "ADDITIONAL SERVICE WHEN REPLACING
CONTROL UNIT : Special Repair Requirement".
YES (Past error)>>Error was detected in the ECM branch line.
NO >> Repair the power supply and the ground circuit.
ECM harness connector
Resistance (Ω)
Connector No. Terminal No.
E16 98 97 Approx. 108 – 132
Page 3118 of 5121
![NISSAN TEANA 2008 Service Manual LAN
HVAC BRANCH LINE CIRCUIT
LAN-51
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841872
1.CHECK CONNECTOR
1. NISSAN TEANA 2008 Service Manual LAN
HVAC BRANCH LINE CIRCUIT
LAN-51
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841872
1.CHECK CONNECTOR
1.](/manual-img/5/57391/w960_57391-3117.png)
LAN
HVAC BRANCH LINE CIRCUIT
LAN-51
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
HVAC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841872
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the A/C auto amp. for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of A/C auto amp.
2. Check the resistance between the A/C auto amp. harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the A/C auto amp. branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the A/C auto amp. Refer to the following.
Without color display: HAC-65, "
A/C AUTO AMP. : Diagnosis Procedure"
With color display: HAC-191, "A/C AUTO AMP. : Diagnosis Procedure"
Is the inspection result normal?
YES (Present error)>>Replace the A/C auto amp. Refer to the following.
Without color display: VTL-23, "
Exploded View"
With color display: VTL-80, "Exploded View"
YES (Past error)>>Error was detected in the A/C auto amp. branch line.
NO >> Repair the power supply and the ground circuit.
A/C auto amp. harness connector
Resistance (Ω)
Connector No. Terminal No.
M50 1 2 Approx. 54 – 66
Page 3119 of 5121
![NISSAN TEANA 2008 Service Manual LAN-52
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841873
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis NISSAN TEANA 2008 Service Manual LAN-52
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841873
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Dis](/manual-img/5/57391/w960_57391-3118.png)
LAN-52
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841873
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the combination meter branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the combination meter. Refer to MWI-42, "
COMBINATION
METER : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the combination meter. Refer to MWI-126, "Exploded View".
YES (Past error)>>Error was detected in the combination meter branch line.
NO >> Repair the power supply and the ground circuit.
Combination meter harness connector
Resistance (Ω)
Connector No. Terminal No.
M34 21 22 Approx. 54 – 66
Page 3120 of 5121
![NISSAN TEANA 2008 Service Manual LAN
BCM BRANCH LINE CIRCUIT
LAN-53
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841875
1.CHECK CONNECTOR
1. Tu NISSAN TEANA 2008 Service Manual LAN
BCM BRANCH LINE CIRCUIT
LAN-53
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841875
1.CHECK CONNECTOR
1. Tu](/manual-img/5/57391/w960_57391-3119.png)
LAN
BCM BRANCH LINE CIRCUIT
LAN-53
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 2)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
BCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000003841875
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the BCM for damage, bend and loose connection (unit side and
connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of BCM.
2. Check the resistance between the BCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the BCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the BCM. Refer to BCS-37, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the BCM. Refer to BCS-78, "Exploded View".
YES (Past error)>>Error was detected in the BCM branch line.
NO >> Repair the power supply and the ground circuit.
BCM harness connector
Resistance (Ω)
Connector No. Terminal No.
M122 91 90 Approx. 54 – 66
