NISSAN TEANA 2008 Service Manual SEC-16
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
NISSAN VEHICLE IMMOBILIZER SYSTEM-NATS
Component Description
INFOID:0000000003814909
1. Inside key antenna (instrument cen-
ter) M1052. Inside key

Page 4026 of 5121

NISSAN TEANA 2008 Service Manual VEHICLE SECURITY SYSTEM
SEC-17
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
VEHICLE SECURITY SYSTEM
System DiagramINFOID:0000000003814910
System DescriptionINFOID:00

Page 4027 of 5121

NISSAN TEANA 2008 Service Manual SEC-18
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM
CANCELING THE SET VEHICLE SECURITY SYSTEM
When one of the following operations is performed, the armed phase is canceled.

Page 4028 of 5121

NISSAN TEANA 2008 Service Manual VEHICLE SECURITY SYSTEM
SEC-19
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Component DescriptionINFOID:0000000003814913
1. BCM M118, M119, M121, M122, M123 2. TCM F

Page 4029 of 5121

NISSAN TEANA 2008 Service Manual SEC-20
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
VEHICLE SECURITY SYSTEM
Trunk room lamp switchDLK-76
Hood switchSEC-113
Component Reference

Page 4030 of 5121

NISSAN TEANA 2008 Service Manual DIAGNOSIS SYSTEM (BCM)
SEC-21
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT-III Function (BCM - COMMON ITEM)I

Page 4031 of 5121

NISSAN TEANA 2008 Service Manual SEC-22
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
The BCM records the following condition at the moment a particular DTC is detected.
Vehicle Speed
Odo/Trip Meter
Vehi

SEC-22
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
The BCM records the following condition at the moment a particular DTC is detected.
Vehicle Speed
Odo/Trip Meter
Vehicle Condition (BCM detected condition)
IGN Counter
IGN counter indicates the number of times that ignition switch is turned ON after DTC is detected.
The number is 0 when a malfunction is detected now.
The number increases like 1 → 2 → 3...38 → 39 after returning to the normal condition whenever ignition
switch OFF → ON.
The number is fixed to 39 until the self-diagnosis results are erased if it is over 39.
INTELLIGENT KEY
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)INFOID:0000000003814915
BCM CONSULT-III FUNCTION
CONSULT-III performs the following functions via CAN communication with BCM.
WORK SUPPORT
CONSULT screen terms Description
SLEEP>LOCKWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “LOCK”.)
SLEEP>OFFWhile turning BCM status from low power consumption mode to normal mode (Power supply
position is “OFF”.)
LOCK>ACC While turning power supply position from “LOCK” to “ACC”
ACC>ON While turning power supply position from “ACC” to “IGN”
RUN>ACCWhile turning power supply position from “RUN” to “ACC” (Vehicle is stopping and selector
lever is except P position.)
CRANK>RUNWhile turning power supply position from “CRANKING” to “RUN” (From cranking up the en-
gine to run it)
RUN>URGENT While turning power supply position from “RUN“ to “ACC” (Emergency stop operation)
ACC>OFF While turning power supply position from “ACC” to “OFF”
OFF>LOCK While turning power supply position from “OFF” to “LOCK”
OFF>ACC While turning power supply position from “OFF” to “ACC”
ON>CRANK While turning power supply position from “IGN” to “CRANKING”
OFF>SLEEPWhile turning BCM status from normal mode (Power supply position is “OFF”.) to low power
consumption mode
LOCK>SLEEPWhile turning BCM status from normal mode (Power supply position is “LOCK”.) to low pow-
er consumption mode
LOCK Power supply position is “LOCK” (Ignition switch OFF with steering is locked.)
OFF Power supply position is “OFF” (Ignition switch OFF with steering is unlocked.)
ACC Power supply position is “ACC” (Ignition switch ACC)
ON Power supply position is “IGN” (Ignition switch ON with engine stopped)
ENGINE RUN Power supply position is “RUN” (Ignition switch ON with engine running)
CRANKING Power supply position is “CRANKING” (At engine cranking)
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
SELF-DIAG RESULTS Displays the diagnosis results judged by BCM.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.

Page 4032 of 5121

NISSAN TEANA 2008 Service Manual DIAGNOSIS SYSTEM (BCM)
SEC-23
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
SELF-DIAG RESULT
Refer to SEC-176, "DTCIndex".
DATA MONITOR
Monitor item Description
REMO

DIAGNOSIS SYSTEM (BCM)
SEC-23
< FUNCTION DIAGNOSIS >[INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
SELF-DIAG RESULT
Refer to SEC-176, "DTCIndex".
DATA MONITOR
Monitor item Description
REMO CONT ID CONFIR It can be checked whether Intelligent Key ID code is registered or not in this mode.
AUTO LOCK SETAuto door lock time can be changed in this mode.
MODE 1: 1 minute
MODE 2: 5 minutes
MODE 3: 30 seconds
MODE 4: 2 minutes
LOCK/UNLOCK BY I-KEYDoor lock/unlock function by door request switch (driver side and passenger side) mode can be
changed to operate (WITH) or not operate (WITHOUT) in this mode.
ENGINE START BY I-KEYEngine start function mode can be changed to operate (WITH) or not operate (WITHOUT) in this
mode.
TRUNK/GLASS HATCH OPENBuzzer reminder function mode by trunk lid opener request switch can be changed to operate
(WITH) or not operate (WITHOUT) in this mode.
PANIC ALARM SETNOTE:
This item is displayed, but cannot be used.
PW DOWN SETNOTE:
This item is displayed, but cannot be used.
TRUNK OPEN DELAYTrunk button pressing on Intelligent Key button can be selected as per the following in this mode.
MODE 1: Press and hold
MODE 2: Press twice
MODE 3: Press and hold, or press twice
LO-BATT OF KEY FOB WARNIntelligent Key low battery warning mode can be changed to operate (WITH) or not operate (WITH-
OUT) in this mode.
ANTI KEY LOCK IN FUNCTIKey reminder function mode can be changed to operate (WITH) or not operate (WITHOUT) in this
mode.
HAZARD ANSWER BACKHazard reminder function mode can be selected from the following in this mode.
LOCK ONLY: Door lock operation only
UNLOCK ONLY: Door unlock operation only
LOCK/UNLOCK: Lock/unlock operation
OFF: Non-operational
ANS BACK I-KEY LOCKBuzzer reminder function (lock operation) mode by door request switch (driver side and passenger
side) can be selected from the following is this mode.
Horn chirp: Sound horn
Buzzer: Sound Intelligent Key warning buzzer
OFF: Non-operational
ANS BACK I-KEY UNLOCKBuzzer reminder function (unlock operation) mode by door request switch can be changed to op-
erate (ON) or not operate (OFF) in this mode.
SHORT CRANKING OUTPUTStarter motor can operate during the times below.
70 msec
100 msec
200 msec
INSIDE ANT DIAGNOSIS This function allows inside key antenna self-diagnosis.
HORN WITH KEYLESS LOCKHorn reminder function mode by Intelligent Key button can be changed to operate (ON) or not op-
erate (OFF) in this mode.
Monitor Item Condition
REQ SW -DR Indicates [ON/OFF] condition of door request switch (driver side).
REQ SW -AS Indicates [ON/OFF] condition of door request switch (passenger side).
REQ SW -BD/TR Indicates [ON/OFF] condition of trunk lid opener request switch.
PUSH SW Indicates [ON/OFF] condition of push-button ignition switch.
IGN RLY2 -F/B Indicates [ON/OFF] condition of ignition relay 2.
