NISSAN TEANA 2008 Service Manual MWI BCM (BODY CONTROL MODULE) MWI-75 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 34 (B)GroundTrunk room antenna (-)OutputIgnition switch OFFWhen Intelligent Key is in the passenger compart- ment

Page 3330 of 5121

NISSAN TEANA 2008 Service Manual MWI-76 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 39 (BR/W)GroundRear bumper anten- na (+)OutputWhen the trunk lid opener request switch is operat- ed with ignition switch OFFWhen Intelligent Key

Page 3331 of 5121

NISSAN TEANA 2008 Service Manual MWI BCM (BODY CONTROL MODULE) MWI-77 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P67 (L/R)GroundTrunk lid opener switchInputTrunk lid opener switchPressed 0 V Not pressed 11.8 V 68 (R/W)GroundRear

Page 3332 of 5121

NISSAN TEANA 2008 Service Manual MWI-78 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 73 (W/R)GroundRoom antenna 2 (+) (center console)OutputIgnition switch OFFWhen Intelligent Key is in the passenger compart- ment When Intelligent

Page 3333 of 5121

NISSAN TEANA 2008 Service Manual MWI BCM (BODY CONTROL MODULE) MWI-79 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 76 (V)GroundDriver door antenna (-)OutputWhen the driver door request switch is operat- ed with ignition switch

Page 3334 of 5121

NISSAN TEANA 2008 Service Manual MWI-80 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 79 (G)GroundRoom antenna 1 (+) (instrument panel)OutputIgnition switch OFFWhen Intelligent Key is in the passenger compart- ment When Intelligent

Page 3335 of 5121

NISSAN TEANA 2008 Service Manual MWI BCM (BODY CONTROL MODULE) MWI-81 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 87 (R/Y)GroundCombination switch INPUT 5InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4 V Fr

Page 3336 of 5121

NISSAN TEANA 2008 Service Manual MWI-82 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 88 (R/G)GroundCombination switch INPUT 3InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4 V Lighting switch HI (Wiper intermitt
