Page 1065 of 5121

NISSAN TEANA 2008 Service Manual BRC-124
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
PARKING BRAKE SWITCH
PARKING BRAKE SWITCH
Component Function CheckINFOID:0000000003767000
1.CHECK PARKING BRAKE SWITCH OPERATION
Operate the parking brake

Page 1066 of 5121

NISSAN TEANA 2008 Service Manual PARKING BRAKE SWITCH
BRC-125
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace parking brake switch.

Page 1067 of 5121

NISSAN TEANA 2008 Service Manual BRC-126
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF SWITCH
VDC OFF SWITCH
DescriptionINFOID:0000000003767003
VDC OFF switch can deactivate (turn OFF) the VDC/TCS function by pressing the VDC OFF swit

Page 1068 of 5121

NISSAN TEANA 2008 Service Manual VDC OFF SWITCH
BRC-127
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
3.CHECK COMBINATION METER
1. Connect ABS actuator and electric unit (control unit) connector.
2. Connect VD

Page 1069 of 5121

NISSAN TEANA 2008 Service Manual BRC-128
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
ABS WARNING LAMP
ABS WARNING LAMP
DescriptionINFOID:0000000003767007
×: ON –: OFF
Component Function CheckINFOID:0000000003767008
1.CHECK ABS WARNING LA

Page 1070 of 5121

NISSAN TEANA 2008 Service Manual BRAKE WARNING LAMP
BRC-129
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000003767010
×: ON –: OFF
NOTE:
1: Brake warning lamp wil

BRAKE WARNING LAMP
BRC-129
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
BRAKE WARNING LAMP
DescriptionINFOID:0000000003767010
×: ON –: OFF
NOTE:
1: Brake warning lamp will turn on in case of parking brake operation (when switch is ON) or of brake fluid level switch operation
(when brake fluid is insufficient).
2: After starting the engine, brake warning lamp is turned off.
Component Function CheckINFOID:0000000003767011
1.BRAKE WARNING LAMP OPERATION CHECK 1
Check that the lamp illuminates for approximately 1 second after the ignition switch is turned ON.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Proceed to diagnosis procedure. Refer to BRC-129, "
Diagnosis Procedure".
2.BRAKE WARNING LAMP OPERATION CHECK 2
Check that the brake warning lamp in the combination meter turns ON/OFF correctly when operating the park-
ing brake pedal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Check parking brake switch. Refer to BRC-124, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003767012
1.CHECK PARKING BRAKE SWITCH
Check that the brake warning lamp in the combination meter turns ON/OFF correctly when operating the park-
ing brake pedal.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check parking brake switch. Refer to BRC-124, "
Diagnosis Procedure".
2.CHECK SELF-DIAGNOSIS
Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check items displayed by self-diagnosis.
3.CHECK COMBINATION METER
Check if the indication and operation of combination meter are normal. Refer to MWI-32, "
Diagnosis Descrip-
tion".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace combination meter.
Condition Brake warning lamp (Note 1)
Ignition switch OFF–
For 1 second after turning ignition switch ON× (Note 2)
1 second later after turning ignition switch ON× (Note 2)
EBD function is malfunctioning.×

Page 1071 of 5121

NISSAN TEANA 2008 Service Manual BRC-130
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
VDC OFF INDICATOR LAMP
VDC OFF INDICATOR LAMP
DescriptionINFOID:0000000003767013
×: ON –: OFF
Component Function CheckINFOID:0000000003767014
1.VDC OFF

Page 1072 of 5121

NISSAN TEANA 2008 Service Manual SLIP INDICATOR LAMP
BRC-131
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SLIP INDICATOR LAMP
DescriptionINFOID:0000000003767016
×: ON : Blink –: OFF
Component Function Che
