Page 1385 of 5121

NISSAN TEANA 2008 Service Manual KEY WARNING DOES NOT OPERATE
DLK-169
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
KEY WARNING DOES NOT OPERATE
DescriptionINFOID:0000000003795016
NOTE:
Before

Page 1386 of 5121

NISSAN TEANA 2008 Service Manual DLK-170
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
OFF POSITION WARNING DOES NOT OPERATE
OFF POSITION WARNING DOES NOT OPERATE
DescriptionINFOID:0000000003795018
NOTE:
Before performing the

Page 1387 of 5121

NISSAN TEANA 2008 Service Manual P POSITION WARNING DOES NOT OPERATE
DLK-171
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
P POSITION WARNING DOES NOT OPERATE
DescriptionINFOID:0000000003795020
N

Page 1388 of 5121

NISSAN TEANA 2008 Service Manual DLK-172
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
P POSITION WARNING DOES NOT OPERATE
7.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent inci

Page 1389 of 5121

NISSAN TEANA 2008 Service Manual ACC WARNING DOES NOT OPERATE
DLK-173
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
ACC WARNING DOES NOT OPERATE
DescriptionINFOID:0000000003795022
NOTE:
Before

Page 1390 of 5121

NISSAN TEANA 2008 Service Manual DLK-174
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TAKE AWAY WARNING DOES NOT OPERATE
TAKE AWAY WARNING DOES NOT OPERATE
DOOR IS OPEN
DOOR IS OPEN : DescriptionINFOID:0000000003795024
NOTE:

Page 1391 of 5121

NISSAN TEANA 2008 Service Manual TAKE AWAY WARNING DOES NOT OPERATE
DLK-175
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
7.CHECK KEY SLOT ILLUMINATION
Check key slot illumination.
Refer to DLK-8

Page 1392 of 5121

NISSAN TEANA 2008 Service Manual DLK-176
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TAKE AWAY WARNING DOES NOT OPERATE
PUSH-BUTTON IGNITION SWITCH OPERATION : Description
INFOID:0000000003795028
NOTE:
Before performing the

DLK-176
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TAKE AWAY WARNING DOES NOT OPERATE
PUSH-BUTTON IGNITION SWITCH OPERATION : Description
INFOID:0000000003795028
NOTE:
Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
Warning functions operating condition is extremely complicated, during operating confirmations, reconfirm
the list above twice in order to ensure proper operation. Refer to DLK-31, "
WARNING FUNCTION : System
Description".
Door lock function is normal.
PUSH-BUTTON IGNITION SWITCH OPERATION : Diagnosis ProcedureINFOID:0000000003795029
1.CHECK POWER POSITION
Check if ignition switch position is changing or not.
Does ignition switch position change?
YES >> GO TO 2.
NO >> Check DTC for BCM. Refer to DLK-153, "
DTCIndex".
2.CHECK PUSH-BUTTON IGNITION SWITCH
Check push-button ignition switch.
Refer to PCS-63, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK BUZZER (COMBINATION METER)
Check buzzer (combination meter).
Refer to DLK-94, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK COMBINATION METER DISPLAY
Check combination meter display.
Refer to DLK-93, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
Refer to DLK-50, "
DTC Logic" (instrument center).
Refer to DLK-52, "
DTC Logic" (console).
Refer to DLK-54, "
DTC Logic" (trunk room).
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
INTELLIGENT KEY IS REMOVED FROM KEY SLOT
INTELLIGENT KEY IS REMOVED FROM KEY SLOT : DescriptionINFOID:0000000003795032
NOTE:
