NISSAN TEANA 2008 Service Manual DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
SR-27
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
2. Firmly secure air bag module bracket (SST: KV99105300) (A) in
a vise.
3. Insert tw

Page 4242 of 5121

NISSAN TEANA 2008 Service Manual SR-28
< ON-VEHICLE REPAIR >
DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
3. Put the inflator connected with the deployment tool (SST:
KV99106400) and deployment tool adapter (SST: KV99110500

Page 4243 of 5121

NISSAN TEANA 2008 Service Manual DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
SR-29
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
5. Connect red clip of deployment tool (SST: KV99106400) (A) to
battery positive term

DISPOSAL OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
SR-29
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
5. Connect red clip of deployment tool (SST: KV99106400) (A) to
battery positive terminal and black clip to negative terminal (B).
6. The lamp on the right side of the tool, marked “deployment tool
power”, should illuminate green, not red.
7. Press the button on the deployment tool. The left side lamp on
the tool, marked “air bag connector voltage”, will illuminate and
the air bag module (1) will deploy.
CAUTION:
When deploying the front side air bag module, stand at
least 5.0 m (16.4 ft) away from the air bag module.
Front Seat Belt Pre-Tensioner (Outside of Vehicle)
1. Firmly grip pre-tensioner (1) in a vise (A) and cut off the web-
bing.
2. Connect deployment tool (SST: KV99106400) (A) and deploy-
ment tool adapter (SST: KV99110500) (B) yellow connector to
front seat belt pre-tensioner (1).
3. Connect red clip of deployment tool to battery positive terminal
and black clip to negative terminal (C).
4. The lamp on the right side of the tool, marked “deployment tool
power”, should illuminate green, not red.
5. Press the button on the deployment tool. The left side lamp on
the tool, marked “seat belt pre-tensioner connector voltage”, will
illuminate and the seat belt pre-tensioner (1) will deploy.
CAUTION:
When deploying the front seat belt pre-tensioner, stand at
least 5.0 m(16.4 ft) away from the seat belt pre-tensioner.
DISPOSING OF AIR BAG MODULE AND SEAT BELT PRE-TENSIONER
Deployed air bag module and seat belt pre-tensioner are very hot. Before disposing of air bag module and
seat belt pre-tensioner, wait at least 30 minutes, and 10 minutes, respectively. Seal them in a plastic bag
before disposal.
CAUTION:
Never apply water to a deployed air bag module or seat belt
pre-tensioner.
Wear gloves when handling a deployed air bag module or seat
belt pre-tensioner.
No poisonous gas is produced upon air bag module deploy-
ment. However, be careful not to inhale gas since it irritates
the throat and can cause choking.
Never disassemble air bag module and seat belt pre-ten-
sioner.
Air bag module and seat belt pre-tensioner cannot be reused.
Wash your hands clean after the work is complete.
JMHIA0285ZZ
JMHIA0068ZZ
JMHIA0214ZZ
SBF276H

Page 4244 of 5121

NISSAN TEANA 2008 Service Manual SRC-1
RESTRAINTS
C
D
E
F
G
I
J
K
L
M
SECTION SRC
A
B
SRC
N
O
P
CONTENTS
SRS AIRBAG CONTROL SYSTEM
BASIC INSPECTION ....................................5
DIAGNOSIS AND REPAIR WORK FLOW .........5
Wor

SRC-1
RESTRAINTS
C
D
E
F
G
I
J
K
L
M
SECTION SRC
A
B
SRC
N
O
P
CONTENTS
SRS AIRBAG CONTROL SYSTEM
BASIC INSPECTION ....................................5
DIAGNOSIS AND REPAIR WORK FLOW .........5
Work Flow .................................................................5
FUNCTION DIAGNOSIS ...............................7
SRS AIR BAG SYSTEM ......................................7
System Diagram ........................................................7
System Description ...................................................7
Component Parts Location ........................................8
Component Description .............................................8
DIAGNOSIS SYSTEM (AIRBAG) ......................10
Diagnosis Description .............................................10
Air Bag Warning Lamp Diagnosis ...........................10
CONSULT-III Function ............................................15
COMPONENT DIAGNOSIS .........................16
B1001, B1002, B1003, B1004, B1005 DIAG-
NOSIS SENSOR UNIT .......................................
16
Description ..............................................................16
DTC Logic ...............................................................16
Diagnosis Procedure ...............................................16
B1006, B1007, B1008, B1009, B1010 DIAG-
NOSIS SENSOR UNIT .......................................
18
Description ..............................................................18
DTC Logic ...............................................................18
Diagnosis Procedure ...............................................18
B1011, B1012, B1013, B1014, B1015 DIAG-
NOSIS SENSOR UNIT .......................................
20
Description ..............................................................20
DTC Logic ...............................................................20
Diagnosis Procedure ...............................................20
B1026, B1027, B1028, B1029, B1030, B1031
DIAGNOSIS SENSOR UNIT ..............................
22
Description ..............................................................22
DTC Logic ...............................................................22
Diagnosis Procedure ...............................................22
B1033, B1034 CRASH ZONE SEN ..................24
Description ...............................................................24
DTC Logic ................................................................24
Diagnosis Procedure ...............................................24
B1035, B1036 CRASH ZONE SEN ..................26
Description ...............................................................26
DTC Logic ................................................................26
Diagnosis Procedure ...............................................26
B1037, B1039, B1041 CRASH ZONE SENS1 ...28
Description ...............................................................28
DTC Logic ................................................................28
Diagnosis Procedure ...............................................28
B1042, B1043, B1044, B1045, B1046, B1047
DIAGNOSIS SENSOR UNIT .............................
30
Description ...............................................................30
DTC Logic ................................................................30
Diagnosis Procedure ...............................................30
B1049 DRIVER AIRBAG MODULE ..................32
Description ...............................................................32
DTC Logic ................................................................32
Diagnosis Procedure ...............................................32
B1050 DRIVER AIRBAG MODULE ..................34
Description ...............................................................34
DTC Logic ................................................................34
Diagnosis Procedure ...............................................34
B1051 DRIVER AIRBAG MODULE ..................36
Description ...............................................................36
DTC Logic ................................................................36
Diagnosis Procedure ...............................................36
B1052 DRIVER AIRBAG MODULE ..................38
Description ...............................................................38
DTC Logic ................................................................38
Diagnosis Procedure ...............................................38

Page 4245 of 5121

NISSAN TEANA 2008 Service Manual SRC-2
B1058, B1059, B1060, B1061, B1062, B1063
DIAGNOSIS SENSOR UNIT ..............................
40
Description ..............................................................40
DTC Logic .........

SRC-2
B1058, B1059, B1060, B1061, B1062, B1063
DIAGNOSIS SENSOR UNIT ..............................
40
Description ..............................................................40
DTC Logic ...............................................................40
Diagnosis Procedure ..............................................40
B1065 ASSIST A/B MODULE ...........................42
Description ..............................................................42
DTC Logic ...............................................................42
Diagnosis Procedure ..............................................42
B1066 ASSIST A/B MODULE ...........................44
Description ..............................................................44
DTC Logic ...............................................................44
Diagnosis Procedure ..............................................44
B1067 ASSIST A/B MODULE ...........................46
Description ..............................................................46
DTC Logic ...............................................................46
Diagnosis Procedure ..............................................46
B1068 ASSIST A/B MODULE ...........................48
Description ..............................................................48
DTC Logic ...............................................................48
Diagnosis Procedure ..............................................48
B1074, B1075, B1076, B1077, B1078, B1079
DIAGNOSIS SENSOR UNIT ..............................
50
Description ..............................................................50
DTC Logic ...............................................................50
Diagnosis Procedure ..............................................50
B1081 PRE-TEN FRONT RH ............................52
Description ..............................................................52
DTC Logic ...............................................................52
Diagnosis Procedure ..............................................52
B1082 PRE-TEN FRONT RH ............................54
Description ..............................................................54
DTC Logic ...............................................................54
Diagnosis Procedure ..............................................54
B1083 PRE-TEN FRONT RH ............................56
Description ..............................................................56
DTC Logic ...............................................................56
Diagnosis Procedure ..............................................56
B1084 PRE-TEN FRONT RH ............................58
Description ..............................................................58
DTC Logic ...............................................................58
Diagnosis Procedure ..............................................58
B1086 PRE-TEN FRONT LH .............................60
Description ..............................................................60
DTC Logic ...............................................................60
Diagnosis Procedure ..............................................60
B1087 PRE-TEN FRONT LH .............................62
Description ..............................................................62
DTC Logic ...............................................................62
Diagnosis Procedure ..............................................62
B1088 PRE-TEN FRONT LH .............................64
Description ..............................................................64
DTC Logic ...............................................................64
Diagnosis Procedure ...............................................64
B1089 PRE-TEN FRONT LH .............................66
Description ..............................................................66
DTC Logic ...............................................................66
Diagnosis Procedure ...............................................66
B1090, B1091, B1092, B1093, B1094, B1095
CONTROL UNIT ................................................
68
Description ..............................................................68
DTC Logic ...............................................................68
Diagnosis Procedure ...............................................68
B1106, B1107, B1108, B1109, B1110, B1111
DIAGNOSIS SENSOR UNIT .............................
70
Description ..............................................................70
DTC Logic ...............................................................70
Diagnosis Procedure ...............................................70
B1113, B1114 SATELLITE SENS RH ..............72
Description ..............................................................72
DTC Logic ...............................................................72
Diagnosis Procedure ...............................................72
B1115, B1116 SATELLITE SENS RH ..............74
Description ..............................................................74
DTC Logic ...............................................................74
Diagnosis Procedure ...............................................74
B1118, B1119 SATELLITE SENS LH ...............76
Description ..............................................................76
DTC Logic ...............................................................76
Diagnosis Procedure ...............................................76
B1120, B1121 SATELLITE SENS LH ...............78
Description ..............................................................78
DTC Logic ...............................................................78
Diagnosis Procedure ...............................................78
B1122, B1123, B1124, B1125, B1126, B1127
DIAGNOSIS SENSOR UNIT .............................
80
Description ..............................................................80
DTC Logic ...............................................................80
Diagnosis Procedure ...............................................80
B1129 SIDE MODULE RH ................................82
Description ..............................................................82
DTC Logic ...............................................................82
Diagnosis Procedure ...............................................82
B1130 SIDE MODULE RH ................................84
Description ..............................................................84
DTC Logic ...............................................................84
Diagnosis Procedure ...............................................84
B1131 SIDE MODULE RH ................................86
Description ..............................................................86
DTC Logic ...............................................................86

Page 4246 of 5121

NISSAN TEANA 2008 Service Manual SRC-3
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P Diagnosis Procedure ...............................................
86
B1132 SIDE MODULE RH .................................88
Description ...................

SRC-3
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P Diagnosis Procedure ...............................................
86
B1132 SIDE MODULE RH .................................88
Description ..............................................................88
DTC Logic ...............................................................88
Diagnosis Procedure ...............................................88
B1134 SIDE MODULE LH ..................................90
Description ..............................................................90
DTC Logic ...............................................................90
Diagnosis Procedure ...............................................90
B1135 SIDE MODULE LH ..................................92
Description ..............................................................92
DTC Logic ...............................................................92
Diagnosis Procedure ...............................................92
B1136 SIDE MODULE LH ..................................94
Description ..............................................................94
DTC Logic ...............................................................94
Diagnosis Procedure ...............................................94
B1137 SIDE MODULE LH ..................................96
Description ..............................................................96
DTC Logic ...............................................................96
Diagnosis Procedure ...............................................96
B1138, B1139, B1140, B1141, B1142, B1143
DIAGNOSIS SENSOR UNIT ..............................
98
Description ..............................................................98
DTC Logic ...............................................................98
Diagnosis Procedure ...............................................98
B1144 ACU .......................................................100
Description ............................................................100
DTC Logic .............................................................100
Diagnosis Procedure .............................................100
B1145 CURTAIN MODULE RH .......................102
Description ............................................................102
DTC Logic .............................................................102
Diagnosis Procedure .............................................102
B1146 CURTAIN MODULE RH .......................104
Description ............................................................104
DTC Logic .............................................................104
Diagnosis Procedure .............................................104
B1147 CURTAIN MODULE RH .......................106
Description ............................................................106
DTC Logic .............................................................106
Diagnosis Procedure .............................................106
B1148 CURTAIN MODULE RH .......................108
Description ............................................................108
DTC Logic .............................................................108
Diagnosis Procedure .............................................108
B1150 CURTAIN MODULE LH ........................110
Description ............................................................110
DTC Logic .............................................................110
Diagnosis Procedure .............................................110
B1151 CURTAIN MODULE LH .......................112
Description .............................................................112
DTC Logic ..............................................................112
Diagnosis Procedure .............................................112
B1152 CURTAIN MODULE LH .......................114
Description .............................................................114
DTC Logic ..............................................................114
Diagnosis Procedure .............................................114
B1153 CURTAIN MODULE LH .......................116
Description .............................................................116
DTC Logic ..............................................................116
Diagnosis Procedure .............................................116
B1154, B1157, B1170, B1171, B1172, B1173,
B1174, B1175 CONTROL UNIT .....................
118
Description .............................................................118
DTC Logic ..............................................................118
Diagnosis Procedure .............................................118
B1202, B1203, B1204, B1205, B1206, B1207
DIAGNOSIS SENSOR UNIT ...........................
120
Description .............................................................120
DTC Logic ..............................................................120
Diagnosis Procedure .............................................120
B1209 FRONTAL COLLISION DETECTION ..122
Description .............................................................122
DTC Logic ..............................................................122
Diagnosis Procedure .............................................122
B1210 SIDE COLLISION DETECTION ..........124
Description .............................................................124
DTC Logic ..............................................................124
Diagnosis Procedure .............................................124
B1212, B1213, B1214 RH1 SAT-SENS ..........126
Description .............................................................126
DTC Logic ..............................................................126
Diagnosis Procedure .............................................126
B1215, B1216, B1217 LH1 SAT-SENS ..........128
Description .............................................................128
DTC Logic ..............................................................128
Diagnosis Procedure .............................................128
B1218, B1219, B1220, B1221, B1222, B1223
CONTROL UNIT ..............................................
130
Description .............................................................130
DTC Logic ..............................................................130
Diagnosis Procedure .............................................130
ECU DIAGNOSIS .......................................132
DIAGNOSIS SENSOR UNIT ...........................132
DTC Index .............................................................132
Wiring Diagram - SRS AIR BAG CONTROL SYS-
TEM - .....................................................................
139
SYMPTOM DIAGNOSIS ............................145

Page 4247 of 5121

NISSAN TEANA 2008 Service Manual SRC-4
SRS AIR BAG WARNING LAMP DOES NOT
TURN OFF .......................................................
145
Diagnosis Procedure .............................................145
SRS AIR BAG WARNING

Page 4248 of 5121

NISSAN TEANA 2008 Service Manual DIAGNOSIS AND REPAIR WORK FLOW
SRC-5
< BASIC INSPECTION >
C
D
E
F
G
I
J
K
L
MA
B
SRC
N
O
P
BASIC INSPECTION
DIAGNOSIS AND REPAIR WORK FLOW
Work FlowINFOID:0000000003813929
OVERALL SEQUENCE
DETAILED FL

Load next 8 pages

Page: < prev 1-10 ... 4209-4216 4217-4224 4225-4232 4233-4240 4241-4248 4249-4256 4257-4264 4265-4272 4273-4280 ... 5128 next >

check transmission fluid oil dipstick water pump engine sensor jacking points
