PRECAUTIONS
SR-3
< PRECAUTION >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
Diagnosis sensor unit must always be installed with their arrow marks “⇐” pointing towards the front of the
vehicle for proper operation. Also check diagnosis sensor unit for cracks, deformities or rust before installa-
tion and replace as required.
The spiral cable must be aligned in the neutral position since its rotations are limited. Do not turn steering
wheel and column after removal of steering gear.
Handle air bag module carefully. Always place driver and front passenger air bag modules with the pad side
facing upward and seat mounted front side air bag module standing with the stud bolt side facing down.
Conduct self-diagnosis to check entire SRS for proper functioning after replacing any components.
After air bag inflates, the front instrument panel assembly should be replaced if damaged.
Always replace instrument panel pad following front passenger air bag deployment.
Occupant Classification SystemINFOID:0000000003751422
Replace occupant classification system control unit and passenger front seat cushion as an assembly.
With VENTILATION SEAT: Refer to SE-89, "
Exploded View".
Without VENTILATION SEAT: Refer to SE-130, "
Exploded View".
Page 4218 of 5121

SR-4
< PREPARATION >
PREPARATION
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000003838653
Tool number
Tool nameDescription
KV99105300
Air bag module bracketAnchors air bag module
KV99106400
Deployment toolDisposes of air bag module and front seat
belt pre-tensioner
KV99110500
Deployment tool adapter
Deployment tool adapter for driver
air bag module (Yellow connector)
Deployment tool adapter for front
seat belt pre-tensioner (Yellow
connector)
Deployment tool adapter for side
curtain air bag module (Yellow
connector)
Deployment tool adapter for front
passenger air bag module Connects between the deployment tool
and driver air bag module
Connects between the deployment tool
and front seat belt pre-tensioner
Connects between the deployment tool
and side curtain air bag module
Connects between the deployment tool
and front passenger air bag module
KV99108300
Deployment tool adapter for front
side air bag moduleConnects between the deployment tool and
front side air bag module
S-NT354
S-NT357
PHIA0184E
ZZA1166D
Page 4219 of 5121
PREPARATION
SR-5
< PREPARATION >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
Commercial Service ToolINFOID:0000000003838654
Tool nameDescription
Tamper resistant TORX bit Removes of driver air bag module
Remover tool Removes clip, pawl and metal clip
S-NT757
PIIB7923J
Page 4220 of 5121
SR-6
< ON-VEHICLE REPAIR >
DRIVER AIR BAG MODULE
ON-VEHICLE REPAIR
DRIVER AIR BAG MODULE
Exploded ViewINFOID:0000000003838665
Removal and InstallationINFOID:0000000003838666
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes.
Always work from the side of air bag module. Never work in front of it.
Never use air tools or electric tools for servicing.
REMOVAL
1. Remove the side lids (LH/RH).
2. Remove the driver air bag module (1) mounting TORX bolt (LH/
RH) with TORX bit (A).
1. Steering wheel 2. Side lid (LH/RH) 3. TORX bolt (LH/RH)
4. Driver air bag module
Refer to GI-4, "
Components" for symbols in the figure.
JMHIA0613GB
JMHIA0614ZZ
Page 4221 of 5121

DRIVER AIR BAG MODULE
SR-7
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
3. Pull out driver air bag module.
4. Disconnect driver air bag harness connector.
NOTE:
For installing/removing driver air bag harness connector, insert
thin screwdriver wrapped in tape into notch, lift lock and
remove connector.
Install connector with lock raised, and push lock into connec-
tor.
After installing the connector, check that the lock is pushed
securely into it.
5. Remove the driver air bag module.
CAUTION:
Always place driver air bag module with pad side facing
upward.
Never impact the driver air bag module.
Replace the driver air bag module if it has been dropped or
sustained an impact.
Never insert any foreign objects (screwdriver, etc.) into driver air bag module.
Never disassemble driver air bag module.
Never expose the driver air bag module to temperatures exceeding 90°C (194°F).
Never allow oil, grease, detergent or water to come in contact with the driver air bag module.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
Never use old TORX bolts after removal; replace with new bolts.
Fix the driver air bag harness (B) to the harness fixing hook
(A).
PHIA0953J
: Upward
JMHIA0504ZZ
JMHIA0009ZZ
JMHIA0615ZZ
Page 4222 of 5121
SR-8
< ON-VEHICLE REPAIR >
DRIVER AIR BAG MODULE
Tighten the TORX bolts after completely adjusting the centers of fixing holes on the driver air bag
module side and the steering wheel side. If the holes are misaligned, the bolt threads are damaged
and the module is not installed securely.
In the case that a malfunction is detected by the air bag warning lamp, after repair or replacement of
the malfunctioning parts, reset the memory by self-diagnosis or by CONSULT-III.
After the work is completed, check that no system malfunction is detected by air bag warning lamp.
Refer to SRC-10, "
Diagnosis Description".
Page 4223 of 5121
SPIRAL CABLE
SR-9
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
MA
B
SR
N
O
P
SPIRAL CABLE
Exploded ViewINFOID:0000000003838667
Removal and InstallationINFOID:0000000003838668
WARNING:
Before servicing, turn ignition switch OFF, disconnect battery negative terminal and wait at least 3
minutes.
Never use air tools or electric tools for servicing.
REMOVAL
1. Remove the driver air bag module. Refer to SR-6, "Removal and Installation".
2. Remove the steering wheel. Refer to ST-12, "
Removal and Installation".
3. Remove the steering column cover (upper/lower). Refer to IP-12, "
Removal and Installation".
4. Disconnect spiral cable body side harness connectors (A) and
steering angle sensor harness connectors (B).
NOTE:
Disconnect spiral cable body side harness connectors after
removing the spiral cable.
5. Remove the spiral cable fixing screws.
1. Spiral cable 2. Steering angle sensor 3. Steering column assembly
JMHIA0616ZZ
JMHIA0617ZZ
Page 4224 of 5121

SR-10
< ON-VEHICLE REPAIR >
SPIRAL CABLE
6. Remove the spiral cable (1) side pawls (LH/RH).
7. Pull the spiral cable out forward.
CAUTION:
Never disassemble the spiral cable.
Never apply lubricant to the spiral cable.
Never allow oil, grease, detergent or water to come in contact with the spiral cable.
Never impact the spiral cable.
Replace the spiral cable if it has been dropped or sustained
an impact.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
The spiral cable may snap during steering operation if the
cable is installed in an improper position.
The neutral position is set as follows.
Carefully turn the spiral cable clockwise to the end position.
Then turn it counterclockwise (about 2 and a half turns) and
stop turning at the mark (B) on which the stopper insertion
holes are in the same position.
The service part is installed in the neutral position by the
stopper and can be set without adjusting after the stopper is
removed.
Never over turn the spiral cable or go beyond the number of
turns required. (These will cause the cable to snap.)
Adjust the spiral cable locating pin (A) to the steering wheel
locating pin hole (C).
In the case that a malfunction is detected by the air bag warning lamp, after repair or replacement of
the malfunctioning parts, reset the memory by self-diagnosis or by CONSULT-III.
: Pawl
JMHIA0618ZZ
JMHIA0009ZZ
