Page 4569 of 5121
![NISSAN TEANA 2008 Service Manual TM-96
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1745 LINE PRESSURE CONTROL
P1745 LINE PRESSURE CONTROL
DescriptionINFOID:0000000003849037
The pressure control solenoid valve A (line pressure solenoid val NISSAN TEANA 2008 Service Manual TM-96
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1745 LINE PRESSURE CONTROL
P1745 LINE PRESSURE CONTROL
DescriptionINFOID:0000000003849037
The pressure control solenoid valve A (line pressure solenoid val](/manual-img/5/57391/w960_57391-4568.png)
TM-96
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1745 LINE PRESSURE CONTROL
P1745 LINE PRESSURE CONTROL
DescriptionINFOID:0000000003849037
The pressure control solenoid valve A (line pressure solenoid valve) regulates the oil pump discharge pres-
sure to suit the driving condition in response to the signal sent from the TCM.
DTC LogicINFOID:0000000003849038
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of CVT fluid temperature sensor is within the range below.
Is
“P1745 L/PRESS CONTROL” detected?
YES >> Go to TM-96, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003849039
1.CHECK DTC
With CONSULT-III
1. Start engine.
2. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
Is
“P1745 L/PRESS CONTROL” detected?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1745 L/PRESS CONTROL TCM detects the unexpected line pressure. TCM
ATF TEMP SEN : 1.0 – 2.0 V
If out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage (cool
down the fluid)
Page 4570 of 5121
![NISSAN TEANA 2008 Service Manual P1777 STEP MOTOR
TM-97
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1777 STEP MOTOR
DescriptionINFOID:0000000003849040
The step motor changes the step by turning 4 coils ON/O NISSAN TEANA 2008 Service Manual P1777 STEP MOTOR
TM-97
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1777 STEP MOTOR
DescriptionINFOID:0000000003849040
The step motor changes the step by turning 4 coils ON/O](/manual-img/5/57391/w960_57391-4569.png)
P1777 STEP MOTOR
TM-97
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
P1777 STEP MOTOR
DescriptionINFOID:0000000003849040
The step motor changes the step by turning 4 coils ON/OFF according to the signal from TCM. As a result, the
flow of line pressure to primary pulley is changed and pulley ratio is controlled.
DTC LogicINFOID:0000000003849041
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC CONFIRMATION PROCEDURE” has been previously performed, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Start engine.
2. Drive vehicle for at least 5 consecutive seconds.
3. Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P1777 STEP MOTR CIRC” detected?
YES >> Go to TM-97, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003849042
1.CHECK STEP MOTOR CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect TCM connector.
3. Check resistance between TCM vehicle side harness connector terminals.
4. Check resistance between TCM vehicle side harness connector terminals and ground.
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1777 STEP MOTR CIRCEach coil of the step motor is not energized
properly due to an open or a short. Harness or connectors
(Step motor circuit is open or shorted.)
Step motor
TCM vehicle side harness connector
Resistance (Approx.)
Connector Terminal
F2327 28
30.0 Ω
29 30
TCM vehicle side harness connector
GroundResistance (Approx.)
Connector Terminal
F2327
15.0 Ω 28
29
30
Page 4571 of 5121
![NISSAN TEANA 2008 Service Manual TM-98
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1777 STEP MOTOR
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT (STEP MOTOR) (PART 1)
1. Disconnec NISSAN TEANA 2008 Service Manual TM-98
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1777 STEP MOTOR
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT (STEP MOTOR) (PART 1)
1. Disconnec](/manual-img/5/57391/w960_57391-4570.png)
TM-98
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1777 STEP MOTOR
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 2.
2.CHECK HARNESS BETWEEN TCM AND CVT UNIT (STEP MOTOR) (PART 1)
1. Disconnect CVT unit connector.
2. Check continuity between TCM vehicle side harness connector terminals and CVT unit vehicle side har-
ness connector terminals.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK HARNESS BETWEEN TCM AND CVT UNIT (STEP MOTOR) (PART 2)
Check continuity between TCM vehicle side harness connector terminals and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK STEP MOTOR
Check step motor. Refer to TM-98, "
Component Inspection (Step Motor)".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
5.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
Component Inspection (Step Motor)INFOID:0000000003849043
1.CHECK STEP MOTOR
1. Check resistance between CVT unit connector terminals.
TCM vehicle side harness connector CVT unit vehicle side harness connector
Continuity
Connector Terminal Connector Terminal
F2327
F249
Existed 28 8
29 7
30 6
TCM vehicle side harness connector
GroundContinuity
Connector Terminal
F2327
Not existed 28
29
30
CVT unit connector
Resistance (Approx.)
Connector Terminals
F2467
30.0 Ω
89
Page 4572 of 5121
P1777 STEP MOTOR
TM-99
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
2. Check resistance between CVT unit connector terminals and ground.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace transaxle assembly. Refer to TM-168, "
Exploded View".
CVT unit connector
GroundResistance (Approx.)
Connector terminal
F246
15.0 Ω 7
8
9
Page 4573 of 5121
![NISSAN TEANA 2008 Service Manual TM-100
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1778 STEP MOTOR - FUNCTION
P1778 STEP MOTOR - FUNCTION
DescriptionINFOID:0000000003849044
The step motor changes the step by turning 4 coils ON/OFF acco NISSAN TEANA 2008 Service Manual TM-100
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1778 STEP MOTOR - FUNCTION
P1778 STEP MOTOR - FUNCTION
DescriptionINFOID:0000000003849044
The step motor changes the step by turning 4 coils ON/OFF acco](/manual-img/5/57391/w960_57391-4572.png)
TM-100
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
P1778 STEP MOTOR - FUNCTION
P1778 STEP MOTOR - FUNCTION
DescriptionINFOID:0000000003849044
The step motor changes the step by turning 4 coils ON/OFF according to the signal from TCM. As a result,
the flow of line pressure to primary pulley is changed and pulley ratio is controlled.
This diagnosis item is detected when the electrical system is OK, but the mechanical system is NG.
This diagnosis item is detected when the state of the changing of the speed mechanism in the unit does not
operate normally.
DTC LogicINFOID:0000000003849045
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
Before starting “DTC CONFIRMATION PROCEDURE”, confirm “Hi” or “Mid” or “Low” fixation by
“PRI SPEED” and “VEHICLE SPEED” on “Data Monitor”.
If hi-geared fixation occurred, go to TM-100, "
Diagnosis Procedure".
NOTE:
Immediately after performing any “DTC CONFIRMATION PROCEDURE”, always turn ignition switch OFF.
Then wait at least 10 seconds before performing the next test.
1.CHECK DTC DETECTION
With CONSULT-III
1. Turn ignition switch ON.
2. Select “Data Monitor” mode for “TRANSMISSION”.
3. Make sure that output voltage of CVT fluid temperature sensor is within the range below.
4. Start engine and maintain the following conditions for at least 30 consecutive seconds.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P1778 STEP MOTR/FNC” detected?
YES >> Go to TM-100, "Diagnosis Procedure".
NO >> Check intermittent incident. Refer to GI-35, "
Intermittent Incident".
Diagnosis ProcedureINFOID:0000000003849046
1.CHECK STEP MOTOR SYSTEM
Check step motor system. Refer to TM-97, "
Description".
Is the inspection result normal?
DTCItem
(CONSULT-III screen term)Malfunction is detected when... Possible cause
P1778 STEP MOTR/FNCThere is a big difference between the num-
ber of steps for the stepping motor and for
the actual gear ratio.Ste p m ot or
ATF TEMP SEN : 1.0 – 2.0 V
If it is out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage
(cool down the fluid)
Start test from 0 km/h (0 MPH)
Constant acceleration : Keep 30 sec or more
VEHICLE SPEED : 10 km/h (6 MPH) or more
ACC PEDAL OPEN : More than 1.0/8
RANGE : “D” position
ENG SPEED : 450 rpm or more
Page 4574 of 5121
P1778 STEP MOTOR - FUNCTION
TM-101
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK INPUT SPEED SENSOR (PRIMARY SPEED SENSOR) SYSTEM
Check input speed sensor (primary speed sensor) system. Refer to TM-52, "
Description".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK OUTPUT SPEED SENSOR (SECONDARY SPEED SENSOR) SYSTEM
Check output speed sensor (secondary speed sensor) system. Refer to TM-55, "
Description".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.DETECT MALFUNCTIONING ITEMS
Check TCM connector pin terminals for damage or loose connection with harness connector.
Is the inspection result normal?
YES >> Replace TCM. Refer to TM-153, "Exploded View".
NO >> Repair or replace damaged parts.
Page 4575 of 5121
![NISSAN TEANA 2008 Service Manual TM-102
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT POSITION INDICATOR CIRCUIT
SHIFT POSITION INDICATOR CIRCUIT
DescriptionINFOID:0000000003849047
TCM sends position indicator signals to combination NISSAN TEANA 2008 Service Manual TM-102
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT POSITION INDICATOR CIRCUIT
SHIFT POSITION INDICATOR CIRCUIT
DescriptionINFOID:0000000003849047
TCM sends position indicator signals to combination](/manual-img/5/57391/w960_57391-4574.png)
TM-102
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
SHIFT POSITION INDICATOR CIRCUIT
SHIFT POSITION INDICATOR CIRCUIT
DescriptionINFOID:0000000003849047
TCM sends position indicator signals to combination meter via CAN communication line.
The selector lever position is indicated on the shift position indicator.
Component Function CheckINFOID:0000000003849048
1.CHECK SHIFT POSITION INDICATOR
CAUTION:
Always drive vehicle at a safe speed.
1. Start engine.
2. Check that correct selector lever position (“P”, “R”, “N”, “D”, “L”) is displayed as selector lever is moved
into each position.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to TM-102, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000003849049
1.CHECK INPUT SIGNALS
With CONSULT-III
1. Start engine.
2. Select “RANGE” on “Data Monitor” and read out the value.
3. Check that correct selector lever position (“P”, “R”, “N”, “D”, “L”) is displayed as selector lever is moved
into each position.
Is the inspection result normal?
YES >> INSPECTION END
NO-1 (CVT position indicator does not indicate “L” when selector lever is moved into “L”.)>>Check the fol-
lowing.
Check sport mode switch. Refer to TM-108, "
Description".
Check CVT main system (Fail-safe function actuated).
- Perform “Self-Diagnostic Results” mode for “TRANSMISSION”.
NO-2 (The actual gear position changes, but the shift position indicator is not indicated.)>>Perform “Self-
Diagnostic Results” mode for “TRANSMISSION”.
NO-3 (The actual gear position and the indication on the shift position indicator do not coincide.)>>Perform
“Self-Diagnostic Results” mode for “TRANSMISSION”.
NO-4 (Only a specific position or positions is/are not indicated on the shift position indicator.)>>Check the
combination meter. Refer to MWI-33, "
CONSULT-III Function (METER/M&A)".
Page 4576 of 5121
SHIFT LOCK SYSTEM
TM-103
< COMPONENT DIAGNOSIS >[CVT: RE0F09B]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
SHIFT LOCK SYSTEM
DescriptionINFOID:0000000003862436
Wiring Diagram - CVT SHIFT LOCK SYSTEM -INFOID:0000000003862437
Component Function
Shift lock solenoidIt operates according to the signal from the stop lamp switch and
moves the lock lever.
Lock leverIt moves according to the operation of the shift lock solenoid and
performs the release of the shift lock.
Detent rodIt links with the selector button and restricts the selector lever
movement.
Park position switch It detects that the selector lever is in P position.
Shift lock release button It moves the lock lever forcibly.
