HOOD
DLK-193
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Front grille: Refer to EXT-18, "Removal and Installation".
INSTALLATION
Install in the reverse order of removal.
CAUTION:
After installing, perform hood fitting adjustment. Refer to DLK-193, "
HOOD ASSEMBLY : Adjust-
ment".
After installing, perform front washer nozzle and tube inspection and adjustment. Refer to WW-102,
"Inspection and Adjustment".
HOOD ASSEMBLY : AdjustmentINFOID:0000000003813385
Check the clearance and the surface height between hood and each part visually and by touching. (Fitting
standard dimension in the table below should be satisfied.
If the clearance and the surface height are out of specification, adjust them according to the procedures
shown below.
Unit: mm (in)
1. Remove hood lock and adjust the height by rotating hood bumper rubber (side, lower) until hood becomes
1 to1.5 mm (0.039 to 0.059 in) lower than fender.
2. Temporarily tighten hood lock assembly, and position by engaging it with hood striker. Check hood lock
and striker for looseness and adjust the clearance and evenness with striker to satisfy the specification.
3. Adjust A and B shown in the figure to the following value with hood's own weight by dropping it from
approximately 200 mm (7.874 in) height or by pressing hood lightly [approximately 29 N (3.0 kg, 6.5 lb)].
4. After adjustment, tighten lock bolts to the specified torque.
HOOD HINGE
Portion StandardDifference
(RH/LH, MAX)
Hood – Front bumper
fasciaA – A D Clearance3.7 – 8.3
(0.146 – 0.315)2.0
(0.079)
Hood – Front combina-
tion lampB – B E Clearance2.4 – 6.8
(0.094 – 0.268)2.5
(0.098)
Hood – Front fender C – CF Clearance3.1 – 6.1
(0.122 – 0.240)2.0
(0.079)
G Surface height−1.5 – 1.5
(−0.059 – 0.059)—
1. Hood striker 2. Primary latch 3. Secondary striker
4. Secondary latch
A : 20.0 mm (0.787 in)
B : 6.8 mm (0.268 in)
JMKIA2399ZZ
Page 1410 of 5121
![NISSAN TEANA 2008 Service Manual DLK-194
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
HOOD
HOOD HINGE : Exploded View
INFOID:0000000003819555
HOOD HINGE : Removal and InstallationINFOID:0000000003813387
REMOVAL
1. Remove hood a NISSAN TEANA 2008 Service Manual DLK-194
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
HOOD
HOOD HINGE : Exploded View
INFOID:0000000003819555
HOOD HINGE : Removal and InstallationINFOID:0000000003813387
REMOVAL
1. Remove hood a](/manual-img/5/57391/w960_57391-1409.png)
DLK-194
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
HOOD
HOOD HINGE : Exploded View
INFOID:0000000003819555
HOOD HINGE : Removal and InstallationINFOID:0000000003813387
REMOVAL
1. Remove hood assembly. Refer to DLK-192, "HOOD ASSEMBLY : Removal and Installation".
2. Remove front fender. Refer to DLK-199, "
Removal and Installation".
3. Remove hood hinge mounting bolts, and then remove hood hinge.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
After installation, apply touch-up paint (the body color) onto the head of the hinge mounting bolts
and nuts.
After installation, perform hood fitting adjustment. Refer to DLK-193, "
HOOD ASSEMBLY : Adjust-
ment".
HOOD SUPPORT ROD
1. Hood insulator 2. Hood hinge (RH/LH) 3. Hood seal (front) (RH/LH)
4. Radiator core seal 5. Grommet 6. Hood support rod
7. Clamp 8. Hood assembly 9. Hood bumper rubber (lower) (RH/
LH)
10. Hood bumper rubber (side) (RH/LH)
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2380ZZ
Page 1411 of 5121
HOOD
DLK-195
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HOOD SUPPORT ROD : Exploded ViewINFOID:0000000003819556
HOOD SUPPORT ROD : Removal and InstallationINFOID:0000000003813389
REMOVAL
1. Support hood assembly with a proper material to prevent it from falling.
WARNING:
Bodily injury may occur if no supporting rod is holding the hood open when removing the hood
support rod.
2. Pull hood support rod from grommet and remove.
INSTALLATION
Install in the reverse order of removal.
1. Hood insulator 2. Hood hinge (RH/LH) 3. Hood seal (front) (RH/LH)
4. Radiator core seal 5. Grommet 6. Hood support rod
7. Clamp 8. Hood assembly 9. Hood bumper rubber (lower) (RH/
LH)
10. Hood bumper rubber (side) (RH/LH)
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA2380ZZ
Page 1412 of 5121
![NISSAN TEANA 2008 Service Manual DLK-196
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
RADIATOR CORE SUPPORT
RADIATOR CORE SUPPORT
Exploded ViewINFOID:0000000003795070
Removal and InstallationINFOID:0000000003795071
REMOVAL
1. U NISSAN TEANA 2008 Service Manual DLK-196
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
RADIATOR CORE SUPPORT
RADIATOR CORE SUPPORT
Exploded ViewINFOID:0000000003795070
Removal and InstallationINFOID:0000000003795071
REMOVAL
1. U](/manual-img/5/57391/w960_57391-1411.png)
DLK-196
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
RADIATOR CORE SUPPORT
RADIATOR CORE SUPPORT
Exploded ViewINFOID:0000000003795070
Removal and InstallationINFOID:0000000003795071
REMOVAL
1. Use refrigerant collecting equipment to discharge the refrigerant. Refer to HA-24, "Collection and
Charge".
2. Remove front under cover. Refer to EXT-28, "
Removal and Installation".
3. Drain engine coolant from radiator. Refer to CO-8, "
Draining".
4. Remove front bumper fascia, energy absorber and bumper reinforcement. Refer to EXT-12, "
Removal
and Installation".
5. Remove mounting clips and remove air duct cover.
6. Remove hood lock opener and hood lock. Refer to DLK-220, "
Removal and Installation".
7. Disconnect connector of horn (HIGH/LOW), and then remove horn (HIGH/LOW). Refer to HRN-6,
"Removal and Installation".
8. Disconnect connector of gas sensor, and then remove gas sensor (with intelligent air conditioner system).
Refer to VTL-82, "
WITH INTELLIGENT AIR CONDITIONER SYSTEM : Removal and Installation".
9. Remove bumper retainer assembly. Refer to EXT-12, "
Removal and Installation".
10. Remove air guide (RH/LH).
11. Remove front combination lamp (RH/LH). Refer to EXL-181, "
Removal and Installation" (XENON TYPE)
or EXL-343, "
Removal and Installation" (HALOGEN TYPE).
12. Disconnect connector of ambient sensor. Refer to VTL-24, "
Removal and Installation" (WITHOUT 7 INCH
DISPLAY) or VTL-81, "
Removal and Installation" (WITH 7 INCH DISPLAY).
1. Radiator upper hose bracket 2. Hood switch bracket 3. Air duct cover
4. Air guide (RH/LH) 5. Radiator core support
: Pawl
JMKIA2382ZZ
Page 1413 of 5121
![NISSAN TEANA 2008 Service Manual RADIATOR CORE SUPPORT
DLK-197
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
13. Disconnect connector of refrigerant pressure sensor. Refer to HA-50, "Exploded Vie NISSAN TEANA 2008 Service Manual RADIATOR CORE SUPPORT
DLK-197
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
13. Disconnect connector of refrigerant pressure sensor. Refer to HA-50, "Exploded Vie](/manual-img/5/57391/w960_57391-1412.png)
RADIATOR CORE SUPPORT
DLK-197
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
13. Disconnect connector of refrigerant pressure sensor. Refer to HA-50, "Exploded View".
14. Remove mounting bolt, and then remove engine coolant reservoir tank. Refer to CO-13, "
Exploded View".
15. Remove mounting bolts, and then disconnect condenser pipe assembly. Refer to HA-48, "
Exploded
View".
16. Remove condenser. Refer to HA-46, "
Removal and Installation".
17. Remove mounting nut of radiator upper hose from radiator core support, and then remove radiator upper
hose and hood switch bracket. Refer to CO-25, "
Exploded View".
18. Disconnect radiator upper hose from radiator pipe (upper). Refer to CO-25, "
Exploded View".
19. Disconnect radiator lower hose (3). Refer to CO-25, "
Exploded View".
20. Disconnect CVT fluid cooler hose on radiator side. Refer to TM-165, "
Exploded View" (CVT: RE0F09B) or
TM-329, "
Exploded View" (CVT: RE0F10A).
21. Remove power steering oil cooler pipe from radiator core sup-
port at point shown by arrows in the figure.
22. Disconnect connectors of the following parts.
Cooling fan (RH/LH). Refer to CO-16, "
Exploded View".
Crash zone sensor. Refer to SR-18, "
Removal and Installation".
23. Remove radiator upper clip. Refer to CO-13, "
Exploded View".
24. Remove all harness clips from radiator core support.
CAUTION:
Never damage radiator.
25. Support hood assembly with a proper material to prevent it from falling.
WARNING:
Bodily injury may occur if no supporting rod is holding the hood open when removing the hood
stay.
26. Remove hood support rod. Refer to DLK-195, "
HOOD SUPPORT ROD : Removal and Installation".
27. Remove mounting bolts, and then remove radiator core support.
CAUTION:
Operate with two workers, because of its heavy weight.
Never damage power steering oil cooler pipe.
28. Remove the following parts after removing radiator core support.
Radiator lower hose, radiator upper hose, radiator pipe. Refer to CO-25, "
Exploded View".
Radiator. Refer to CO-13, "
Exploded View".
Cooling fan (RH/LH). Refer to CO-16, "
Exploded View".
Crash zone sensor. Refer to SR-18, "
Exploded View".
Power steering oil cooler pipe clip. Refer to ST-34, "
Exploded View".
INSTALLATION
Install in the reverse order of removal.
JMKIA2395ZZ
: harness clip
JMKIA2396ZZ
Page 1414 of 5121
DLK-198
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
RADIATOR CORE SUPPORT
CAUTION:
After installation, inspection and replenish the following.
- Engine coolant. Refer to CO-8, "
Inspection", CO-9, "Refilling".
- CVT fluid. Refer to TM-142, "
Inspection", TM-143, "Changing" (CVT: RE0F09B) or TM-304, "Inspec-
tion", TM-305, "Changing" (CVT: RE0F10A).
After installation, adjust the following parts.
- Front combination lamp. EXL-174, "
Aiming Adjustment Procedure (Low Beam)", EXL-175, "Aiming
Adjustment Procedure (High Beam)" (XENON TYPE) or EXL-337, "Aiming Adjustment Procedure
(Low Beam)", EXL-338, "Aiming Adjustment Procedure (High Beam)" (HALOGEN TYPE).
Page 1415 of 5121
FRONT FENDER
DLK-199
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
FRONT FENDER
Exploded ViewINFOID:0000000003813392
Removal and InstallationINFOID:0000000003813393
CAUTION:
Use a shop cloth to protect the body from being damaged during removal and installation.
REMOVAL
1. Remove clips (A) of hood seal assembly (side) (1).
2. Remove fender protector. Refer to EXT-22, "
FENDER PROTECTOR : Removal and Installation".
3. Remove front bumper fascia. Refer to EXT-12, "
Removal and Installation".
4. Remove front combination lamp. Refer to EXL-181, "
Removal and Installation" (XENON TYPE) or EXL-
343, "Removal and Installation" (HALOGEN TYPE).
5. Remove front fender cover.
6. Remove center mud guard. Refer to EXT-26, "
Removal and Installation".
1. Front fender cover 2. Hood seal assembly (side) 3. Front fender
: Pawl
JMKIA2383ZZ
JMKIA2397ZZ
Page 1416 of 5121
DLK-200
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
FRONT FENDER
7. Remove mounting bolts and remove front fender.
CAUTION:
A viscous urethane foam is installed on the back surface of front fender. When removing the front
fender, peel of the urethane foam bit at a time, and carefully to remove it.
INSTALLATION
Install in the reverse order of removal.
CAUTION:
After installation, check front fender adjustment. Refer to DLK-193, "
HOOD ASSEMBLY : Adjust-
ment" and DLK-203, "DOOR ASSEMBLY : Adjustment".
After installation, apply the touch-up paint (the body color) onto the head of front fender mounting
bolts.
Adjust the following part.
- Front combination lamp: Refer to EXL-174, "
Aiming Adjustment Procedure (Low Beam)", EXL-175,
"Aiming Adjustment Procedure (High Beam)" (XENON TYPE) or EXL-337, "Aiming Adjustment Pro-
cedure (Low Beam)", EXL-338, "Aiming Adjustment Procedure (High Beam)" (HALOGEN TYPE).
