NISSAN TEANA 2008 Service Manual EXL-36
< FUNCTION DIAGNOSIS >[XENON TYPE]
DIAGNOSIS SYSTEM (IPDM E/R)
EXTERNAL LAMPSOff OFF
TAIL Operates the tail lamp relay.
Lo Operates the headlamp low relay.
HiOperates the headlamp low relay and

Page 2066 of 5121

NISSAN TEANA 2008 Service Manual DIAGNOSIS SYSTEM (HEADLAMP LEVELIZER)
EXL-37
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
DIAGNOSIS SYSTEM (HEADLAMP LEVELIZER)
CONSULT-III Functions (HEADLAMP LEVELIZER)INFOID:

DIAGNOSIS SYSTEM (HEADLAMP LEVELIZER)
EXL-37
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
DIAGNOSIS SYSTEM (HEADLAMP LEVELIZER)
CONSULT-III Functions (HEADLAMP LEVELIZER)INFOID:0000000003805598
Function item
WORK SUPPORT
DATA MONITOR
ACTIVE TEST
Diagnosis mode Description
ECU IDENTIFICATION Allows confirmation of auto levelizer control unit part number.
SELF DIAGNOSTIC RESULT Displays the diagnosis results judged by auto levelizer control unit.
WORK SUPPORT Performs settings on sensors.
DATA MONITOR Displays input data for headlamp auto aiming motor control unit in real time.
ACTIVE TEST Transmits a drive signal to the load to check their operation.
CONFIGURATION Writes the vehicle specification when replacing auto levelizer control unit.
Work item Setting details
SENSOR INITIALIZE Adjusts sensor lever signal output under unladen conditions.
Monitor item
[Unit]Display item
INT SEN VALUE
[%]Displays the sensor lever angle corresponding to the maximum value of sensor lever
angle that is recognized with auto levelizer control unit by ratio
ACT OUTPUT
[%]Displays the control value of aiming motor drive signal that is calculated by auto lev-
elizer control unit with the ratio corresponding to the ignition power supply
ACT MEASURED
[%]Displays the measured value of aiming motor drive signal that is output from auto lev-
elizer control unit with the ratio corresponding to ignition power supply
SPEED SIG
[km/h]Displays the vehicle speed judged from vehicle speed signal (8-pulse) that is input to
auto levelizer control unit
LIGHT SIGNAL
[V]Displays the status judged from tail lamp signal that is input to auto levelizer control
unit
INT SEN VOLT
[V]Displays the ignition power supply status that is input to auto levelizer control unit
EXT SEN VOLT
[V]NOTE:
The item is indicated, but not monitored.
EXT SEN SIG
[V]NOTE:
The item is indicated, but not monitored.
Test item Operation item Operation status
LAMP TESTMIN Moves the light axis to the highest position.
MID Moves the light axis to the initial position.
MAX Moves the light axis to the lowest position.

Page 2067 of 5121

NISSAN TEANA 2008 Service Manual EXL-38
< COMPONENT DIAGNOSIS >[XENON TYPE]
B2080 ECU TROUBLE
COMPONENT DIAGNOSIS
B2080 ECU TROUBLE
DescriptionINFOID:0000000003805599
Auto levelizer control unit is installed in rear suspension arm.

Page 2068 of 5121

NISSAN TEANA 2008 Service Manual B2081 INITIAL NOT DONE
EXL-39
< COMPONENT DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
B2081 INITIAL NOT DONE
DTC LogicINFOID:0000000003805602
DTC DETECTION LOGIC
[B2081] INITIAL NOT DONE

Page 2069 of 5121

NISSAN TEANA 2008 Service Manual EXL-40
< COMPONENT DIAGNOSIS >[XENON TYPE]
B2082 SENSOR OUT OF RANGE
B2082 SENSOR OUT OF RANGE
DTC LogicINFOID:0000000003805604
DTC DETECTION LOGIC
[B2082] SENSOR OUT OF RANGE
DTC CONFIRMATION PROCEDU

Page 2070 of 5121

NISSAN TEANA 2008 Service Manual B2083 SEN SIG NOT PLAUSIBLE
EXL-41
< COMPONENT DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
B2083 SEN SIG NOT PLAUSIBLE
DTC LogicINFOID:0000000003805606
DTC DETECTION LOGIC
[B2083] SEN SIG

Page 2071 of 5121

NISSAN TEANA 2008 Service Manual EXL-42
< COMPONENT DIAGNOSIS >[XENON TYPE]
B2084 VOLTAGE UNDER LIMIT
B2084 VOLTAGE UNDER LIMIT
DTC LogicINFOID:0000000003805608
DTC DETECTION LOGIC
[B2084] VOLTAGE UNDER LIMIT
DTC CONFIRMATION PROCEDU

Page 2072 of 5121

NISSAN TEANA 2008 Service Manual B2085 LOWBEAM SIG OPEN LINE
EXL-43
< COMPONENT DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
B2085 LOWBEAM SIG OPEN LINE
DescriptionINFOID:0000000003805610
Auto levelizer control unit inp
