OIL SEAL
1. Remove the following parts:
Road wheel and tire (RH)
Splash guard (RH): Refer to EXT-22, "
FENDER PROTECTOR : Exploded View".
Drive belt: Refer to EM-12, "
Removal and Installation".
Crankshaft pulley: Refer to EM-52, "
Exploded View".
2. Remove front oil seal using a suitable tool.
CAUTION:
Be careful not to damage front timing chain case and crank-
shaft.
INSTALLATION
1. Apply new engine oil to both oil seal lip and dust seal lip of new front oil seal.
2. Install front oil seal.
Install front oil seal so that each seal lip is oriented as shown in
the figure.
Using a suitable drift, press-fit until the height of front oil seal is
level with the mounting surface.
- Suitable drift: outer diameter 60 mm (2.36 in), inner diameter
50 mm (1.97 in).
Check the garter spring is in position and seal lips not inverted.
CAUTION:
Be careful not to damage front timing chain case and
crankshaft.
Press-fit straight and avoid causing burrs or tilting oil
seal.
3. Install in the reverse order of removal after this step.
REAR OIL SEAL
REAR OIL SEAL : Removal and InstallationINFOID:0000000003802288
REMOVAL
1. Remove transaxle assembly. Refer to TM-332, "Exploded View" (VQ25DE) or TM-168, "Exploded View"
(VQ35DE).
2. Remove drive plate. Refer to EM-107, "
Exploded View".
3. Remove oil pan (upper). Refer to EM-38, "
Exploded View".
SEM829E
A: Oil seal lip
B : Dust seal lip
: Engine inside
: Engine outside
JPBIA0054ZZ
SEM829E
Page 1970 of 5121
OIL SEAL
EM-95
< DISASSEMBLY AND ASSEMBLY >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
4. Use a seal cutter (SST) to cut away liquid gasket and remove
rear oil seal retainer.
CAUTION:
Be careful not to damage mating surfaces.
NOTE:
Regard both rear oil seal and retainer a an assembly.
INSTALLATION
1. Remove old liquid gasket on mating surfaces of cylinder block and oil pan (upper) using scraper.
2. Apply new engine oil to both oil seal lip and dust seal lip of new oil seal retainer.
3. Apply a continuous bead of liquid gasket with the tube presser
(commercial service tool) to rear oil seal retainer as shown in the
figure.
Use Genuine Liquid Gasket or equivalent.
CAUTION:
Attaching should be done within 5 minutes after coating.
4. Install rear oil seal retainer to cylinder block. Refer to EM-107, "
Exploded View".
Check the garter spring is in position and seal lips not inverted.
5. Install in the reverse order of removal after this step.
SEM830E
PBIC2649E
Page 1971 of 5121
EM-96
< DISASSEMBLY AND ASSEMBLY >
CYLINDER HEAD
CYLINDER HEAD
Exploded ViewINFOID:0000000003802289
REMOVAL
DISASSEMBLY
1. Oil level gauge 2. Cylinder head (bank 2) 3. Cylinder head bolt
4. Cylinder head (bank 1) 5. Cylinder head gasket (bank 1) 6. Cylinder head gasket (bank 2)
A. Refer to EM-97
Refer to GI-4, "Components" for symbols in the figure.
JPBIA1748ZZ
Page 1972 of 5121

CYLINDER HEAD
EM-97
< DISASSEMBLY AND ASSEMBLY >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Removal and InstallationINFOID:0000000003802290
REMOVAL
1. Remove the following parts:
Oil level gauge
Intake manifold collector: Refer to EM-28, "
Exploded View".
Rocker cover: Refer to EM-49, "
Exploded View".
Fuel tube and fuel injector assembly: Refer to EM-44, "
Exploded View".
Intake manifold: Refer to EM-32, "
Exploded View".
Exhaust manifold: Refer to EM-34, "
Exploded View".
Water inlet and thermostat assembly: Refer to CO-23, "
Exploded View".
Water outlet, water connector, water bypass pipe and heater pipe: Refer to CO-25, "
Exploded View".
Timing chain and rear timing chain case: Refer to EM-52, "
Exploded View" and EM-79, "Exploded
View".
Camshaft: Refer to EM-84, "
Exploded View".
1. Valve lifter 2. Valve collet 3. Valve spring retainer
4. Valve spring 5. Valve oil seal 6. Valve spring seat
7. Valve guide (EXH) 8. Spark plug 9. Spark plug tube
10. Cylinder head (bank 1) 11. Valve seat (EXH) 12. Valve (EXH)
13. Valve (INT) 14. Valve seat (INT) 15. Valve guide (INT)
16. Cylinder head (bank 2)
: Apply high strength thread locking sealant or equivalent.
Refer to GI-4, "
Components" for symbols not described on the above.
JPBIA1728GB
Page 1973 of 5121
EM-98
< DISASSEMBLY AND ASSEMBLY >
CYLINDER HEAD
2. Remove cylinder head bolts in reverse order as shown in the fig-
ure with cylinder head bolt wrench (commercial service tool) and
power tool to remove cylinder heads (bank 1 and bank 2).
3. Remove cylinder head gaskets.
INSTALLATION
1. Install new cylinder head gaskets.
2. Turn crankshaft until No. 1 piston is set at TDC.
Crankshaft key should line up with the bank 1 cylinder center
line as shown in the figure.
A: Bank 1
B: Bank 2
: Engine front
JPBIA0172ZZ
1 : Crankshaft key
: Bank 1 side
JPBIA1752ZZ
Page 1974 of 5121

CYLINDER HEAD
EM-99
< DISASSEMBLY AND ASSEMBLY >
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
3. Install cylinder head follow the steps below to tighten cylinder
head bolts in numerical order as shown in the figure with cylin-
der head bolts wrench (commercial service tool).
CAUTION:
If cylinder head bolts reused, check their outer diameters
before installation. Refer to EM-104, "
Inspection".
Before installing cylinder head, inspect cylinder head dis-
tortion. Refer to EM-104, "
Inspection".
a. Apply new engine oil to threads and seat surfaces of cylinder
head bolts.
b. Tighten all cylinder head bolts.
c. Completely loosen all cylinder head bolts.
CAUTION:
In step “c”, loosen bolts in reverse order of that indicated in the figure.
d. Tighten all cylinder head bolts.
e. Turn all cylinder head bolts 103 degrees clockwise (angle tightening).
CAUTION:
Check the tightening angle by using the angle wrench [SST:
KV10112100 (BT8653-A)] (A). Avoid judgment by visual
inspection without.
Check tightening angle indicated on the angle wrench indica-
tor plate.
f. Turn all cylinder head bolts 103 degrees clockwise again (angle
tightening).
4. After installing cylinder head, measure distance between front
end faces of cylinder block and cylinder head (bank 1 and bank
2).
If measured value is out of the standard, reinstall cylinder
head.
5. Install in the reverse order of removal after this step.
A: Bank 1
B: Bank 2
: Engine front
: 98.1 N·m (10 kg-m, 72 ft-lb)
: 0 N·m (0 kg-m, 0 ft-lb)
: 39.2 N·m (4.0 kg-m, 29 ft-lb)
JPBIA0172ZZ
JPBIA0175ZZ
Standard : 14.1 - 14.9 mm (0.555 - 0.587 in)
EMQ0662D
Page 1975 of 5121

EM-100
< DISASSEMBLY AND ASSEMBLY >
CYLINDER HEAD
Disassembly and Assembly
INFOID:0000000003802291
DISASSEMBLY
1. Remove spark plug with spark plug wrench (commercial service tool).
2. Remove valve lifter.
Identify installation positions, and store them without mixing them up.
3. Remove valve collet.
Compress valve spring with the valve spring compressor [SST:
