Page 4465 of 5121

NISSAN TEANA 2008 Service Manual STR-18 < ON-VEHICLE REPAIR > STARTER MOTOR 1. Inspect pinion teeth.  Replace pinion if teeth are worn or damaged. (Also check con- dition of ring gear teeth.) 2. Inspect reduction gear teeth.  Repla

Page 4466 of 5121

NISSAN TEANA 2008 Service Manual STARTER MOTOR STR-19 < ON-VEHICLE REPAIR > C D E F G H I J K L MA STR N P O Magnet is secured to yoke by bonding agent. Check magnet to see that it is secured to yoke and for any cracks. Replace malfu

Page 4467 of 5121

NISSAN TEANA 2008 Service Manual STR-20 < ON-VEHICLE REPAIR > STARTER MOTOR 5. Check depth of insulating mold from commutator surface. - Undercut to 0.5 to 0.8 mm (0.020 to 0.031 in) if the depth is 0.2 mm (0.008 in) or less. VQ35DE

Page 4468 of 5121

NISSAN TEANA 2008 Service Manual STARTER MOTOR STR-21 < ON-VEHICLE REPAIR > C D E F G H I J K L MA STR N P O DISASSEMBLY Type: M000TA0072 VQ35DE : Removal and InstallationINFOID:0000000003860440 REMOVAL 1. Remove the battery. Refer t

Page 4469 of 5121

NISSAN TEANA 2008 Service Manual STR-22 < ON-VEHICLE REPAIR > STARTER MOTOR VQ35DE : Inspection INFOID:0000000003860441 MAGNETIC SWITCH  Before starting to check, disconnect the battery cable from the negative terminal.  Disconnect

Page 4470 of 5121

NISSAN TEANA 2008 Service Manual STARTER MOTOR STR-23 < ON-VEHICLE REPAIR > C D E F G H I J K L MA STR N P O 1. Inspect pinion teeth.  Replace pinion if teeth are worn or damaged. (Also check con- dition of ring gear teeth.) 2. Insp

Page 4471 of 5121

NISSAN TEANA 2008 Service Manual STR-24 < ON-VEHICLE REPAIR > STARTER MOTOR Magnet is secured to yoke by bonding agent. Check magnet to see that it is secured to yoke and for any cracks. Replace malfunctioning parts as an assembly. C

Page 4472 of 5121

NISSAN TEANA 2008 Service Manual STARTER MOTOR STR-25 < ON-VEHICLE REPAIR > C D E F G H I J K L MA STR N P O 5. Check depth of insulating mold from commutator surface. - Undercut to 0.5 to 0.8 mm (0.020 to 0.031 in) if the depth is 0
