INFINITI FX35 2005 Service Manual SRS-42
CRASH ZONE SENSOR
Revision: 2005 July 2005 FX
CRASH ZONE SENSORPFP:98531
Removal and InstallationAHS000I1
REMOVAL
CAUTION:
Before servicing SRS, turn ignition switch OFF, disconnect both batte

Page 4626 of 4731

INFINITI FX35 2005 Service Manual SIDE AIR BAG (SATELLITE) SENSOR SRS-43
C
D E
F
G
I
J
K L
M A
B
SRS
Revision: 2005 July 2005 FX
SIDE AIR BAG (SATELLITE) SENSORPFP:98830
Removal and InstallationAHS000I2
REMOVAL
CAUTION:

Page 4627 of 4731

INFINITI FX35 2005 Service Manual SRS-44
FRONT SEAT BELT PRE-TENSIONER
Revision: 2005 July 2005 FX
FRONT SEAT BELT PRE-TENSIONERPFP:86884
Removal and InstallationAHS000I3
For removal and installation procedures, refer to SB-3, "Remova

Page 4628 of 4731

INFINITI FX35 2005 Service Manual DIAGNOSIS SENSOR UNIT SRS-45
C
D E
F
G
I
J
K L
M A
B
SRS
Revision: 2005 July 2005 FX
DIAGNOSIS SENSOR UNITPFP:28556
Removal and InstallationAHS000I4
REMOVAL
CAUTION:
Before servicing SRS

Page 4629 of 4731

INFINITI FX35 2005 Service Manual SRS-46
COLLISION DIAGNOSIS
Revision: 2005 July 2005 FX
COLLISION DIAGNOSISPFP:00015
For Frontal CollisionAHS000I6
To repair the SRS, perform the following steps.
When SRS (except the front side air b

SRS-46
COLLISION DIAGNOSIS
Revision: 2005 July 2005 FX
COLLISION DIAGNOSISPFP:00015
For Frontal CollisionAHS000I6
To repair the SRS, perform the following steps.
When SRS (except the front side air bag and side curtain air bag modules) is activated in a collision:
1. Replace the diagnosis sensor unit.
2. Remove the air bag modules (except the front side air bag modules and side curtain air bag modules), crash zone sensor assembly, bracket and seat belt pre-tensioner assemblies.
3. Check the SRS components using the table below:
–Replace any SRS components showing visible signs of damage (dents, cracks and deformation).
4. Install new air bag modules (except the front side air bag modules and side curtain air bag modules) crash zone sensor assembly, bracket and seat belt pre-tensioner assemblies.
5. Conduct self-diagnosis using CONSULT-II or “AIR BAG” warning lamp. Refer to SRS-17, "
SRS Operation
Check" for details. Ensure entire SRS operates properly.
When SRS is not activated in a collision:
1. Check the SRS components using the table below:
–Replace any SRS components showing visible signs of damage (dents, cracks and deformation).
2. Conduct self-diagnosis using CONSULT-II or “AIR BAG” warning lamp. Refer to SRS-17, "
SRS Operation
Check" for details. Ensure entire SRS operates properly.
When only one front air bag module is activated in a collision:
1. Replace the following components:
–Diagnosis sensor unit
–Crash zone sensor
–Activated front air bag and seat belt pre-tensioner.
2. Check the other SRS components using the table below. (Refer to “SRS is NOT activated”.)
–Replace any SRS components showing visible signs of damage (dents, cracks and deformation).
3. Conduct self-diagnosis using CONSULT-II or “AIR BAG” warning lamp. Refer to SRS-17, "
SRS Operation
Check" for details. Ensure entire SRS operates properly.
Only one front air bag may inflate a crash, depending on the crash severity and whether the front occupants
are belted or unbelted. This does not indicate improper performance of the system. Perform self-diagnosis to
make sure the entire SRS operates properly.
SRS INSPECTION (FOR FRONTAL COLLISION)
Part SRS is activated SRS is NOT activated
Driver airbag
module If the Driver airbag has deployed:
REPLACE.
Install with new fasteners. If the Driver air bag has NOT been activated:
[same text as in current manual]
Passenger front
airbag module If the Passenger front airbag has deployed:
REPLACE.
Install with new fasteners. If the Passenger front air bag has NOT been activated:
[same text as in current manual]
Crash zone
sensor If any of the front airbags or seat belt pre-
tensionsers have been activated:
REPLACE the crash zone sensor and bracket
with new fasteners. If the front airbags or seat belt pre-tensionsers have NOT
been activated:
[same text as in current manual]
Seat belt pre-ten-
sioner assemblies If the driver or passenger Seat belt pre-ten-
sioner has been activated:
REPLACE the seat belt pre-tensioner
assemblies with new fasteners. If the pre-tensioners have NOT been activated:
[same text as in current manual]
Diagnosis sensor
unit If any of the SRS components have been
activated:
REPLACE the Diagnosis sensor unit.
Install with new fasteners. If none of the SRS components have been activated:
[same text as in current manual]

Page 4630 of 4731

INFINITI FX35 2005 Service Manual COLLISION DIAGNOSIS SRS-47
C
D E
F
G
I
J
K L
M A
B
SRS
Revision: 2005 July 2005 FX
Steering wheel [same text as in current manual]
Sp

Page 4631 of 4731

INFINITI FX35 2005 Service Manual SRS-48
COLLISION DIAGNOSIS
Revision: 2005 July 2005 FX
For Side CollisionAHS000I7
WHEN THE SIDE AIR BAG IS ACTIVATED IN THE SIDE COLLISION:
1. Replace the following components:
–All parts of front s

SRS-48
COLLISION DIAGNOSIS
Revision: 2005 July 2005 FX
For Side CollisionAHS000I7
WHEN THE SIDE AIR BAG IS ACTIVATED IN THE SIDE COLLISION:
1. Replace the following components:
–All parts of front seatback (including front seatback frame) with front side air bag module (on the side on
which front side air bag is activated)
–Curtain air bag module (on the side on which side curtain air bag is activated)
–Diagnosis sensor unit
–Satellite sensor (on the side on which side air bag and side curtain air bag are activated)
2. Check the SRS components and the related parts using the following table.
–Replace any SRS components and the related parts showing visible signs of damage (dents, cracks,
deformation).
3. Conduct self-diagnosis using CONSULT-II or “AIR BAG” warning lamp. Refer to SRS-17, "
SRS Operation
Check" . Ensure entire SRS operates properly.
WHEN SRS IS NOT ACTIVATED IN THE SIDE COLLISION:
1. Check the SRS components and the related parts using the following table.
–Replace any SRS components and the related parts showing visible signs of damage (dents, cracks,
deformation).
2. Conduct self-diagnosis using CONSULT-II or “AIR BAG” warning lamp. Refer to SRS-17, "
SRS Operation
Check" . Ensure entire SRS operates properly.
SRS INSPECTION (FOR SIDE COLLISION)
Part Front side air bag and
side curtain air bag are activated Front side air bag and side curtain air bag are NOT activated
LH or RH side curtain
air bag module REPLACE the side
curtain air bag mod-
ule.
(Repair the center pil-
lar inner, etc. before
installing new one if
damaged.) 1. Check for visible signs of damage (dents, tears, deformation) of the center pillar on
the collision side.
2. If damaged—Remove the side curtain air bag module.
3. Check for visible signs of damaged (tears etc.) of the LH or RH side curtain air bag module.
4. Check harness and connectors for damage, and terminals for deformities.
5. If no damage is found, reinstall the LH or RH side curtain air bag module with new bolts.
6. If damaged—REPLACE the LH or RH side curtain air bag module with new bolts.
Front LH or RH side
air bag module REPLACE all parts of
seatback with
deployed front side
air bag module. 1. Check for visible signs of damage (dents, tears, deformation) of the seatback on
the collision side.
2. Check harness and connectors for damage, and terminals for deformities.
3. If damaged—REPLACE the front seatback assembly. Air bag must be deployed before disposal.
LH or RH side air bag
(Satellite) sensor REPLACE the side
air bag (Satellite) sen-
sor on the collision
side with new nuts.
(Repair the center pil-
lar inner, etc. before
installing new one if
damaged.) 1. Remove the LH or RH side air bag (Satellite) sensor on the collision side. Check
harness connectors for damage, terminals for deformities, and harness for binding.
2. Check for visible signs of damage (dents, cracks, deformation) of the LH or RH side air bag (Satellite) sensor.
3. Install the LH or RH side air bag (Satellite) sensor to check fit.
4. If no damage is found, reinstall the LH or RH side sir bag (Satellite) sensor with new nuts.
5. If damaged—REPLACE the LH or RH side air bag (Satellite) sensor with new nuts.
Diagnosis sensor unit REPLACE the diag- nosis sensor unit with
the new bolts. 1. Check case and bracket for dents, cracks or deformities.
2. Check connectors for damage, and terminals for deformities.
3. If no damage is found, reinstall the diagnosis sensor unit with new bolts and ground bolt.
4. If damaged—REPLACE the diagnosis sensor unit with new bolts and ground bolt.

Page 4632 of 4731

INFINITI FX35 2005 Service Manual COLLISION DIAGNOSIS SRS-49
C
D E
F
G
I
J
K L
M A
B
SRS
Revision: 2005 July 2005 FX
Seat belt pre-ten-
sioner assembly 1. Check if the seat belt can be extended smoothly.
If the seat be
