ACCELERATOR CONTROL SYSTEM
Revision: 2005 July 2005 FX

Page 10 of 4731

INFINITI FX35 2005 Service Manual ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION ACS
A
B
ACS
Revision: 2005 July 2005 FX
AUTO CRUISE CONTROL SYSTEM
ASCD
AUTOMATIC SPEED CONTROL DEVICE (

ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
D E
F
G H
I
J
L
M
SECTION ACS
A
B
ACS
Revision: 2005 July 2005 FX
AUTO CRUISE CONTROL SYSTEM
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description .......................................................... ..... 3
ICC
PRECAUTIONS ..................................................... ..... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 4
Precautions for ICC System Service ................... ..... 4
PREPARATION ...................................................... ..... 5
Special Service Tools .......................................... ..... 5
DESCRIPTION ....................................................... ..... 6
Outline ................................................................. ..... 6
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. ..... 6
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ..... 6
BRAKE ASSIST (WITH PREVIEW FUNCTION) ..... 6
System Diagram .................................................. ..... 6
Components Description ..................................... ..... 7
CAN Communication ........................................... ..... 7
CAN COMMUNICATION UNIT ........................ ..... 7
Switch Operation ................................................. ..... 8
ICC System Display ............................................ ..... 8
ACTION TEST ....................................................... ..... 9
ICC System Running Test ................................... ..... 9
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. ..... 9
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ... 10
LASER BEAM AIMING ADJUSTMENT ................ ... 12
Outline ................................................................. ... 12
Preparation .......................................................... ... 12
Outline of Adjustment Procedure ........................ ... 12
Setting the ICC Target Board .............................. ... 12
ADJUSTING HEIGHT OF THE TARGET ......... ... 12
ADJUSTING THE RIGHT-LEFT POSITION OF
THE TARGET ................................................... ... 13 SETTING THE TARGET ..................................
... 13
Aiming Adjustment ............................................... ... 14
CHECK AFTER THE ADJUSTMENT ............... ... 17
ELECTRICAL UNITS LOCATION ......................... ... 18
Component Parts and Harness Connector Location ... 18
WIRING DIAGRAM ................................................ ... 19
Schematic ............................................................ ... 19
Wiring Diagram — ICC — ................................... ... 20
TERMINALS AND REFERENCE VALUE .............. ... 27
Terminals and Reference Value for ICC Unit ....... ... 27
Terminals and Reference Value for ICC Sensor .. ... 28
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION ....................................................................... ... 29
Work Flow ............................................................ ... 29
CONSULT-II Function .......................................... ... 30
DESCRIPTION ................................................. ... 30
CONSULT-II BASIC OPERATION .................... ... 30
WORK SUPPORT ............................................ ... 31
SELF-DIAGNOSTIC RESULTS ........................ ... 32
DATA MONITOR .............................................. ... 32
ACTIVE TEST .................................................. ... 34
Self-Diagnostic Function ...................................... ... 36
WITH CONSULT-II ........................................... ... 36
WITHOUT CONSULT-II .................................... ... 36
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ................................................ ... 38
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ..................................................................... ... 41
Diagnostic Trouble Code (DTC) Chart ................ ... 41
DTC 11 CONTROL UNIT .................................... ... 42
DTC 20 CAN COMM CIRCUIT ............................ ... 43
DTC 31 POWER SUPPLY CIR, DTC 34 POWER
SUPPLY CIR 2 .................................................... ... 43
DTC 41 VHCL SPEED SE CIRC ......................... ... 44
DTC 43 ABS/TCS/VDC CIRC ............................. ... 45
DTC 45 BRAKE SW/STOP L SW ........................ ... 45
DTC 46 OPERATION SW CIRC .......................... ... 47
DTC 61 PRESS SEN CIRCUIT ........................... ... 48
DTC 62 BOOSTER SOL/V CIRCUIT .................. ... 50
DTC 63 RELEASE SW CIRCUIT ........................ ... 51

Page 11 of 4731

INFINITI FX35 2005 Service Manual ACS-2Revision: 2005 July 2005 FX
DTC 65 PRESSURE CONTROL .........................
... 52
DTC 74 LASER BEAM OFF CNTR ..................... ... 53
DTC 90 STOP LAMP RLY FIX .....................

ACS-2Revision: 2005 July 2005 FX
DTC 65 PRESSURE CONTROL .........................
... 52
DTC 74 LASER BEAM OFF CNTR ..................... ... 53
DTC 90 STOP LAMP RLY FIX ............................ ... 53
DTC 92 ECM CIRCUIT ........................................ ... 59
DTC 96 NP RANGE ............................................ ... 60
DTC 97 AT CIRCUIT ........................................... ... 61
DTC 98 GEAR POSITION ................................... ... 61
DTC 102 RADAR STAIN ..................................... ... 62
DTC 103 LASER SENSOR FAIL ......................... ... 63
DTC 104 LASER AIMING INCMP ....................... ... 63
DTC 107 LASER COMM FAIL ............................. ... 63
DTC 109 LASER HIGH TEMP ............................ ... 64
TROUBLE DIAGNOSIS FOR SYMPTOMS ........... ... 65
Symptom Chart .................................................... ... 65
Symptom 1: MAIN Switch Does Not Turn ON*
1 ,
MAIN Switch Does Not Turn OFF*
2 ..................... ... 66
Symptom 2: ICC System Cannot Be Set (MAIN
Switch Turns ON/OFF) ........................................ ... 66
Symptom 3: ICC System Cannot Be Operated by
CANCEL Switch, RESUME/ACCELERATE Switch
or DISTANCE Switch ........................................... ... 67 Symptom 4: ICC System Is Not Cancelled When
the Gear Is in Other Than “D” .............................. ... 68
Symptom 5: Chime Does Not Sound ................... ... 68
Symptom 6: Driving Force Is Hunting .................. ... 69
Symptom 7: ICC System Frequently Cannot Detect
the Vehicle Ahead/ Detection Zone Is Short ........ ... 69
Symptom 8: The System Does Not Detect the Vehi-
cle Ahead at All .................................................... ... 70
ELECTRICAL COMPONENT INSPECTION .......... ... 71
ICC Steering Switch ............................................. ... 71
ICC Brake Switch and Stop Lamp Switch ............ ... 71
Boost Solenoid ..................................................... ... 71
Release Switch .................................................... ... 72
REMOVAL AND INSTALLATION ........................... ... 73
ICC Unit ............................................................... ... 73
REMOVAL ......................................................... ... 73
INSTALLATION ................................................. ... 73
ICC Sensor .......................................................... ... 73
REMOVAL ......................................................... ... 73
INSTALLATION ................................................. ... 74
ICC Steering Switch ............................................. ... 74

Page 12 of 4731

INFINITI FX35 2005 Service Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) ACS-3
[ASCD]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
[ASCD]AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
DescriptionAKS007XN
Regardi

Page 13 of 4731

INFINITI FX35 2005 Service Manual ACS-4
[ICC]
PRECAUTIONS
Revision: 2005 July 2005 FX
[ICC]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
AKS00FCX
The Supplem

ACS-4
[ICC]
PRECAUTIONS
Revision: 2005 July 2005 FX
[ICC]PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
AKS00FCX
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceAKS00C88
Do not look straight into the laser beam discharger when adjusting laser beam aiming.
Turn the MAIN switch OFF in conditions similar to driving, such like Free rollers or a chassis dynamome-
ter.
Do not use the ICC sensor removing from vehicle, disassemble, or remodel the sensor.
Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.

Page 14 of 4731

INFINITI FX35 2005 Service Manual PREPARATION ACS-5
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
PREPARATIONPFP:00002
Special Service ToolsAKS00C8A
The actual shapes of Kent-Moore tools may differ from th

Page 15 of 4731

INFINITI FX35 2005 Service Manual ACS-6
[ICC]
DESCRIPTION
Revision: 2005 July 2005 FX
DESCRIPTIONPFP:00000
OutlineAKS00C8B
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead

ACS-6
[ICC]
DESCRIPTION
Revision: 2005 July 2005 FX
DESCRIPTIONPFP:00000
OutlineAKS00C8B
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function).
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Vehicle-to-vehicle distance control mode, the driver can maintain the same speed as other vehicles without
the constant need to adjust the set speed as you would with a normal cruise control system.
The system is intended to enhance the operation of the vehicle when following the vehicle traveling in the
same lane and direction.
If the distance sensor detects a slower moving vehicle ahead, the system will reduce speed so that the vehicle
ahead can be followed at the selected distance.
The system automatically controls the throttle and applies the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 390 ft (120 m) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise control mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the Brake Assist is activated and generates a
greater braking force than that of a conventional brake booster even with light pedal force.
When the Preview Function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver depress
the brake pedal and improves brake response by reducing its free play.
Refer to Owner's Manual for BRAKE ASSIST (WITH PREVIEW FUNCTION) operating instructions.
System DiagramAKS00C8C
PKIB4142E

Page 16 of 4731

INFINITI FX35 2005 Service Manual DESCRIPTION ACS-7
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
Components DescriptionAKS00C8D
CAN CommunicationAKS00C8E
CAN (Controller Area Network) is a serial communic

DESCRIPTION ACS-7
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2005 July 2005 FX
Components DescriptionAKS00C8D
CAN CommunicationAKS00C8E
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-30, "CAN Communication Unit" .
Component Vehicle-to-
vehicle
distance
control mode Conventional
(fixed speed) cruise
control mode Brake assist
(with pre-
view func- tion) Description
ICC unit ××× Operates electric throttle control actuator and brake
booster based on that sensor signals and CAN commu-
nication data, then controls vehicle distance.
ICC sensor ×× Irradiates laser beam, and receives reflected laser
beam to measure distance from preceding vehicle.
ECM ××× Transmits throttle position signal and ICC steering
switch signal to ICC unit through CAN communication.
ABS actuator and electric
unit (control unit) ×××
Transmits wheel speed sensor signal to ICC unit
through CAN communication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure, based on command from
ICC unit.
BCM × Transmit front wiper request signal to ICC unit through
CAN communication.
TCM ×× Transmits gear position signal and output shaft revolu-
tion signal to ICC unit through CAN communication.
Unified meter and A/C amp. ××× Receives ICC system display signal, ICC warning lamp
signal and buzzer output signal from ICC unit through
CAN communication.
ICC brake switch, stop
lamp switch ××× Transmit operating signal to ICC unit when touching
brake pedal. ICC unit cancels cruise system at driver's
brake operation.
Parking brake switch ×× The cruise system is cancelled when applied.

Load next 8 pages

Page: < prev 1-8 9-16 17-24 25-32 33-40 41-48 ... 4736 next >

android auto height adjustment hood release trunk change language dimensions
