Page 3353 of 4731

INFINITI FX35 2005 Service Manual GW-76 FRONT DOOR GLASS AND REGULATOR Revision: 2005 July 2005 FX FRONT DOOR GLASS AND REGULATORPFP:80300 Removal and InstallationAIS003A6 DOOR GLASS Removal 1. Remove the front door finisher. Refer t

Page 3354 of 4731

INFINITI FX35 2005 Service Manual FRONT DOOR GLASS AND REGULATOR GW-77 C D E F G H J K L M A B GW Revision: 2005 July 2005 FX 6. While holding the door glass, raise it at the rear end to pull the glass out of the sash to

Page 3355 of 4731

INFINITI FX35 2005 Service Manual GW-78 FRONT DOOR GLASS AND REGULATOR Revision: 2005 July 2005 FX Inspection after Removal Check the regulator assembly for the following. If a malfunction is detected, replace or grease it. Wire wea

Page 3356 of 4731

INFINITI FX35 2005 Service Manual FRONT DOOR GLASS AND REGULATOR GW-79 C D E F G H J K L M A B GW Revision: 2005 July 2005 FX Lower the glass slightly [approx. 10 to 20 mm (0.39 to 0.79 in)] and make sure the clearance t

Page 3357 of 4731

INFINITI FX35 2005 Service Manual GW-80 REAR DOOR GLASS AND REGULATOR Revision: 2005 July 2005 FX REAR DOOR GLASS AND REGULATORPFP:82300 Removal and InstallationAIS003A7 DOOR GLASS Removal 1. Remove the rear door finisher. Refer to

Page 3358 of 4731

INFINITI FX35 2005 Service Manual REAR DOOR GLASS AND REGULATOR GW-81 C D E F G H J K L M A B GW Revision: 2005 July 2005 FX 7. Operate the power window switch to raise/lower the door win- dow until the glass mounting bo

Page 3359 of 4731

INFINITI FX35 2005 Service Manual GW-82 REAR DOOR GLASS AND REGULATOR Revision: 2005 July 2005 FX 10. Remove the power window motor mounting bolts and nuts, and remove the regulator from the panel. 11. Disconnect the connector for t

Page 3360 of 4731

INFINITI FX35 2005 Service Manual REAR DOOR GLASS AND REGULATOR GW-83 C D E F G H J K L M A B GW Revision: 2005 July 2005 FX FITTING INSPECTION Make sure the glass is securely fit into the glass run groove. Lower the gl
