INFINITI FX35 2005 Service Manual EC-776
[VK45DE]
BASIC SERVICE PROCEDURE
Revision: 2005 July 2005 FX
5. Turn off headlamps heater blower, rear window defogger.
6. Keep front wheels pointed straight ahead.
OVERALL SEQUENCE
PBIB2001E

Page 2170 of 4731

INFINITI FX35 2005 Service Manual BASIC SERVICE PROCEDURE EC-777
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
DETAILED PROCEDURE
1. INSPECTION START
1. Check service records for any recent repairs that

Page 2171 of 4731

INFINITI FX35 2005 Service Manual EC-778
[VK45DE]
BASIC SERVICE PROCEDURE
Revision: 2005 July 2005 FX
3. CHECK TARGET IDLE SPEED
With CONSULT-II
1. Run engine at about 2,000 rpm for about 2 minutes under no load.
2. Rev engine (2,0

Page 2172 of 4731

INFINITI FX35 2005 Service Manual BASIC SERVICE PROCEDURE EC-779
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
6. PERFORM IDLE AIR VOLUME LEARNING
Perform EC-787, "
Idle Air Volume Learning" .
Is Idl

Page 2173 of 4731

INFINITI FX35 2005 Service Manual EC-780
[VK45DE]
BASIC SERVICE PROCEDURE
Revision: 2005 July 2005 FX
10. CHECK IGNITION TIMING
1. Run engine at idle.
2. Check ignition timing with a timing light. Refer to EC-774
.
OK or NG
OK (

Page 2174 of 4731

INFINITI FX35 2005 Service Manual BASIC SERVICE PROCEDURE EC-781
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
15. CHECK IGNITION TIMING AGAIN
1. Run engine at idle.
2. Check ignition timing with a tim

Page 2175 of 4731

INFINITI FX35 2005 Service Manual EC-782
[VK45DE]
BASIC SERVICE PROCEDURE
Revision: 2005 July 2005 FX
19. CHECK HEATED OXYGEN SENSOR 1 (BANK 1) SIGNAL
With CONSULT-II
1. Run engine at about 2,000 rpm for about 2 minutes under no lo

Page 2176 of 4731

INFINITI FX35 2005 Service Manual BASIC SERVICE PROCEDURE EC-783
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
22. CHECK HEATED OXYGEN SENSOR 1 (BANK 2) SIGNAL
Without CONSULT-II
1. Switch the monitor

BASIC SERVICE PROCEDURE EC-783
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
22. CHECK HEATED OXYGEN SENSOR 1 (BANK 2) SIGNAL
Without CONSULT-II
1. Switch the monitored sensor from bank 1 to bank 2. Refer to EC-762, "
How to Switch Monitored Sensor
From Bank 1 to Bank 2 or Vice Versa" .
2. Running engine at 2,000 rpm under no load (The engine is warmed up to normal operating temperature.), check that the MIL comes on more than 5 times during 10 seconds.
OK or NG
OK >> INSPECTION END
NG (MIL does not come on)>>GO TO 24.
NG (MIL comes on less than 5 times)>>GO TO 31.
23. CHECK HEATED OXYGEN SENSOR 1 (BANK 1) HARNESS
1. Turn ignition switch OFF and disconnect battery ground cable.
2. Disconnect ECM harness connector.
3. Disconnect heated oxygen sensor 1 (bank 1) harness connector.
4. Check harness continuity between ECM terminal 16 and heated oxygen sensor 1 (bank 1) terminal 1. Refer to Wiring Diagram, EC-937, "
BANK 1" .
5. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 25.
NG >> 1. Repair or replace harness between ECM and heated oxygen sensor 1 (bank 1).
2. GO TO 4.
24. CHECK HEATED OXYGEN SENSOR 1 (BANK 2) HARNESS
1. Turn ignition switch OFF and disconnect battery ground cable.
2. Disconnect ECM harness connector.
3. Disconnect heated oxygen sensor 1 (bank 2) harness connector.
4. Check harness continuity between ECM terminal 35 and heated oxygen sensor 1 (bank 2) terminal 1. Refer to Wiring Diagram, EC-939, "
BANK 2" .
5. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 25.
NG >> 1. Repair or replace harness between ECM and heated oxygen sensor 1 (bank 2).
2. GO TO 4.
25. PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
1. Reconnect ECM harness connector and heated oxygen sensor 1 harness connector.
2. Perform EC-786, "
Accelerator Pedal Released Position Learning" .
>> GO TO 26.
26. PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Perform EC-786, "
Throttle Valve Closed Position Learning" .
>> GO TO 27.
Continuity should exist.
Continuity should exist.
