INFINITI FX35 2005 Service Manual LAN-294 [CAN] CAN SYSTEM (TYPE 6) Revision: 2005 July 2005 FX 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect LDW camera unit connector. 2. Check resistance between LDW camera unit harness connector

Page 3714 of 4731

INFINITI FX35 2005 Service Manual CAN SYSTEM (TYPE 6) LAN-295 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX ABS Actuator and Electric Unit (Control Unit) Circuit InspectionAKS00CCW 1. CHECK CONNECTOR 1. T

Page 3715 of 4731

INFINITI FX35 2005 Service Manual LAN-296 [CAN] CAN SYSTEM (TYPE 6) Revision: 2005 July 2005 FX IPDM E/R Circuit InspectionAKS00CCY 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2. Disconnect the battery cable from the negative te

Page 3716 of 4731

INFINITI FX35 2005 Service Manual CAN SYSTEM (TYPE 6) LAN-297 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX CAN Communication Circuit InspectionAKS00CCZ 1. CHECK CONNECTOR 1. Turn ignition switch OFF. 2.

Page 3717 of 4731

INFINITI FX35 2005 Service Manual LAN-298 [CAN] CAN SYSTEM (TYPE 6) Revision: 2005 July 2005 FX 2. CHECK HARNESS FOR SHORT CIRCUIT 1. Disconnect following connectors. –ECM connector –Harness connector M82 –Display unit connecto

Page 3718 of 4731

INFINITI FX35 2005 Service Manual CAN SYSTEM (TYPE 6) LAN-299 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX 4. CHECK HARNESS FOR SHORT CIRCUIT 1. Disconnect A/T assembly connector. 2. Check continuity be

Page 3719 of 4731

INFINITI FX35 2005 Service Manual LAN-300 [CAN] CAN SYSTEM (TYPE 6) Revision: 2005 July 2005 FX 8. CHECK HARNESS FOR SHORT CIRCUIT 1. Disconnect ABS actuator and electric unit (control unit) connector and harness connector E205. 2.

Page 3720 of 4731

INFINITI FX35 2005 Service Manual CAN SYSTEM (TYPE 6) LAN-301 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX 11 . CHECK HARNESS FOR SHORT CIRCUIT Check continuity between harness connector B5 terminals 3
