Page 3241 of 4731

INFINITI FX35 2005 Service Manual GI-20
HOW TO USE THIS MANUAL
Revision: 2005 July 2005 FX
Detectable Lines and Non-Detectable Lines
In some wiring diagrams, two kinds of lines, representing wires, with different weight are used.
A

Page 3242 of 4731

INFINITI FX35 2005 Service Manual HOW TO USE THIS MANUAL GI-21
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX
Multiple Switch
The continuity of multiple switch is described in two ways as shown below.
The switch

Page 3243 of 4731

INFINITI FX35 2005 Service Manual GI-22
HOW TO USE THIS MANUAL
Revision: 2005 July 2005 FX
Reference Area
The Reference Area of the wiring diagram contains references to additional electrical reference pages at the
end of the manual.

Page 3244 of 4731

INFINITI FX35 2005 Service Manual HOW TO USE THIS MANUAL GI-23
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX
AbbreviationsAAS000E3
The following ABBREVIATIONS are used:
ABBREVIATION DESCRIPTION
A/C Air Condit

Page 3245 of 4731

INFINITI FX35 2005 Service Manual GI-24
SERVICE INFORMATION FOR ELECTRICAL INCIDENT
Revision: 2005 July 2005 FX
SERVICE INFORMATION FOR ELECTRICAL INCIDENTPFP:00000
How to Check Terminal AAS000E4
CONNECTOR AND TERMINAL PIN KIT
Use the

Page 3246 of 4731

INFINITI FX35 2005 Service Manual SERVICE INFORMATION FOR ELECTRICAL INCIDENT GI-25
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX
Some connectors do not have a notch above each terminal. To
probe each terminal,

Page 3247 of 4731

INFINITI FX35 2005 Service Manual GI-26
SERVICE INFORMATION FOR ELECTRICAL INCIDENT
Revision: 2005 July 2005 FX
4. While moving the connector, check whether the male terminal
can be easily inserted or not.
If the male terminal can b

Page 3248 of 4731

INFINITI FX35 2005 Service Manual SERVICE INFORMATION FOR ELECTRICAL INCIDENT GI-27
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX
How to Perform Efficient Diagnosis for an Electrical IncidentAAS000E5
WORK FLOW
I

SERVICE INFORMATION FOR ELECTRICAL INCIDENT GI-27
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX
How to Perform Efficient Diagnosis for an Electrical IncidentAAS000E5
WORK FLOW
INCIDENT SIMULATION TESTS
Introduction
Sometimes the symptom is not present when the vehicle is brought in for service. If possible, re-create the
conditions present at the time of the incident. Doing so may help avoid a No Trouble Found Diagnosis. The fol-
lowing section illustrates ways to simulate the conditions/environment under which the owner experiences an
electrical incident.
The section is broken into the six following topics:
Vehicle vibration
Heat sensitive
SGI838
STEP DESCRIPTION
STEP 1 Get detailed information about the conditions and the environment when the incident occurred.
The following are key pieces of information required to make a good analysis:
WHAT Vehicle Model, Engine, Transmission/Transaxle and the System (i.e. Radio).
WHEN Date, Time of Day, Weather Conditions, Frequency.
WHERE Road Conditions, Altitude and Traffic Situation.
HOW System Symptoms, Operating Conditions (Other Components Interaction).
Service History and if any After Market Accessories have been installed.
STEP 2 Operate the system, road test if necessary.
Verify the parameter of the incident.
If the problem cannot be duplicated, refer to “Incident Simulation Tests”.
STEP 3 Get the proper diagnosis materials together including:
Power Supply Routing
System Operation Descriptions
Applicable Service Manual Sections
Check for any Service Bulletins
Identify where to begin diagnosis based upon your knowledge of the system operation and the customer comments.
STEP 4 Inspect the system for mechanical binding, loose connectors or wiring damage.
Determine which circuits and components are involved and diagnose using the Power Supply Routing and Harness
Layouts.
STEP 5 Repair or replace the incident circuit or component.
STEP 6 Operate the system in all modes. Verify the system works properly under all conditions. Make sure you have not inad-
vertently created a new incident during your diagnosis or repair steps.
