Page 905 of 4731

INFINITI FX35 2005 Service Manual BL-90
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
PIIA9928E

Page 906 of 4731

INFINITI FX35 2005 Service Manual INTELLIGENT KEY SYSTEM BL-91
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FXSystem DescriptionAIS004MW
The Intelligent Key system is a system which can lock and unlock the doors (

INTELLIGENT KEY SYSTEM BL-91
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FXSystem DescriptionAIS004MW
The Intelligent Key system is a system which can lock and unlock the doors (door lock function) and start
the engine (engine start function) by carrying around the Intelligent Key, which operates based on the
results of electrical key-ID verification using two-way communications between the Intelligent Key and the
vehicle
Operation of the remote control buttons on the Intelligent Key also provides the same functions as the
remote control entry system. (Remote control entry functions)
As an ignition key warning function, when a door is locked or unlocked with entry switch or remote control-
ler button operation, the hazard lamps flash and the Intelligent Key warning buzzer sounds.
Even if the vehicle or Intelligent Key battery runs down, the door can be locked and unlocked and the
engine started with the mechanical key built into the Intelligent Key.
If an Intelligent Key was lost, a new Intelligent Key can be registered. A maximum of 4 Intelligent Keys can
be registered.
It has been made possible to diagnose the system, change the function setting and register an Intelligent
Key with the CONSULT-II.
DOOR LOCK FUNCTION
Operation Description
When the driver door, passenger door, or back door request switch is pressed, Intelligent Key unit sends a
request signal from the transmission antenna corresponding to the pressed door request switch, key-ID
verification is performed using two-way communication with Intelligent Key, and if ID is successfully veri-
fied, a door lock/unlock request signal is sent to BCM (Body Control Module) using CAN communication
to lock/unlock the door lock.
When door is locking, door is unlocked, when door is unlocking, door is locked.
When door is locked/unlocked by door request switch operation, hazard lamps flash and Intelligent Key
warning buzzer sounds.
With the locking operation of door request switch, door lock actuators of all door are locked.
PIIB4645E

Page 907 of 4731

INFINITI FX35 2005 Service Manual BL-92
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
Driver side door request switch operation
When door request switch (driver side) is pushed (unlock), driver side door lock actuator is unlocke

BL-92
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
Driver side door request switch operation
When door request switch (driver side) is pushed (unlock), driver side door lock actuator is unlocked.
(Selective door unlock function)
When door request switch (driver side) is pushed (unlock) for the second time within 5 seconds after the
first operation, door lock actuators on passenger's and other's doors are unlocked.
Unlock mode can be changed using “WORK SUPPORT” mode in “SELECTIVE UNLOCK FUNCTION”.
Refer to BL-120, "
WORK SUPPORT" .
Passenger side door request switch operation
When door request switch (passenger side) is pushed (unlock), passenger side door lock actuator is
unlocked.
When door request switch (passenger side) is pushed (unlock) for the second time with in 5 seconds after
the first operation, door lock actuators on driver's and other's doors are unlocked.
Unlock mode can be changed using “WORK SUPPORT” mode in “SELECTIVE UNLOCK FUNCTION”.
Refer to BL-120, "
WORK SUPPORT" .
Back door request switch operation
When back door request switch is pushed (unlock), back door lock actuator is unlocked.
When back door request switch is pushed (unlock) for the second time with in 5 seconds after the first
operation, door lock actuators on driver's and passenger's doors are unlocked.
Unlock mode can be changed using “WORK SUPPORT” mode in “SELECTIVE UNLOCK FUNCTION”.
Refer to BL-120, "
WORK SUPPORT" .
Operation Condition
Auto Door Lock Function
After the door request switch in the driver or passenger or back door is operated and the vehicle door is
unlocked, all the doors are automatically locked unless the mechanical key is inserted into the ignition knob,
the ignition knob is pressed, any door request switch is pressed, any one of the doors is opened, or an Intelli-
gent Key remote control button is operated within 30 seconds.
Key Reminder Function
The hazard lamps will flash and the Intelligent Key warning buzzer will sound several times when the door lock
is locked or unlocked by door request switch operation.
When ignition switch ON or any door is opened, key reminder function is not operate.
Intelligent Key Lock-in Prevention Function
When doors are locked using door lock and unlock switch or driver door lock knob while Intelligent key is in
vehicle and doors open, Intelligent Key unit sends door unlock request signal to BCM via CAN communication
to unlock all doors to prevent Intelligent Key from becoming locked in vehicle.
CAUTION:
The above function operates when the Intelligent Key is inside the vehicle. However, there are cases
that Intelligent Key cannot be detected and this function will not operate when Intelligent Key is on the
instrument panel, rear parcel shelf, or in the glove box. Also, this system sometimes does not operate
if the Intelligent Key is in the door pocket for the open door.
REMOTE CONTROL ENTRY FUNCTIONS
Door Lock Function
Operating a remote controller button on the Intelligent Key sends the Intelligent Key-ID to the Intelligent
Key unit. Intelligent Key unit conducts a verification of the received key-ID, and if the verification is
Request switch operation Operating conditions (When all the conditions below are met)
Door request switch (Driver side)
Closing all doors (door switch: OFF)
The Intelligent Key is in the antenna detection area for the door for which the door
request switch (LOCK) was operated.
Door request switch (passenger side)
Door request switch (back door)
Vehicle operation Hazard lamp Intelligent Key warning buzzer
Door unlock operation Once Once
Door lock operation Twice Twice

Page 908 of 4731

INFINITI FX35 2005 Service Manual INTELLIGENT KEY SYSTEM BL-93
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
accepted, a door lock or door unlock request signal is sent to BCM via CAN communication to lock/unlock

INTELLIGENT KEY SYSTEM BL-93
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
accepted, a door lock or door unlock request signal is sent to BCM via CAN communication to lock/unlock
the door.
When door lock/unlock is performed using Intelligent Key remote controller button operation, operation
confirmation is conducted by making hazard lamps flash and Intelligent Key warning buzzer sound.
OPERATION CONDITION
Door lock/unlock operation is necessary for all doors close.
Map Lamp And Keyhole Illumination Function
When the following conditions come:
condition of map lamp switch is DOOR position;
door switch OFF (when all the doors are closed);
Remote control button of Intelligent Key turns on interior lamp (for 30 seconds) with input of UNLOCK signal
from Intelligent Key.
Panic Alarm Function
When key switch is OFF and ignition knob is not pushed (when mechanical key is not inserted in ignition
knob), BCM turns ON and OFF horn and headlamp intermittently with input of PANIC ALARM signal from
Intelligent Key. The alarm automatically turns off after 25 seconds or when Intelligent Key unit receives any
signal from Intelligent Key.
Panic alarm operation mode can be changed using “WORK SUPPORT” mode in “PANIC ALARM DELAY”.
Refer to BL-120, "
WORK SUPPORT" .
Remote Control Power Window Down (Open) Operation
When Intelligent Key unlock switch is turned ON with ignition switch OFF, and Intelligent Key unlock switch is
detected to be on continuously for 3 seconds, the driver's door and passenger's door power windows are
simultaneously opened.
Power window is operated to open and the operation continues as long as the Intelligent Key unlock switch is
pressed.
Remote control power window down operation mode can be changed using “P/W DOWN DELAY” mode in
“WORK SUPPORT”. Refer to BL-120, "
WORK SUPPORT" .
Key Reminder Function
As an operation verification function, when doors are locked or unlocked using Intelligent Key remote control-
ler button operation, hazard lamps flash and horn sounds.
ENGINE STARTUP FUNCTION
Operation Description
When ignition knob is pressed, Intelligent Key unit sends request signal from inside key antenna, key-ID
verification is conducted with Intelligent Key using two-way communication, and if verification is success-
ful, an ignition rotation prohibition latch release signal is sent to steering lock unit. Steering lock unit
releases ignition knob rotation prohibition latch. (Ignition knob can now be turned.)
When it becomes possible to rotate the ignition knob, “KEY” warning lamp in combination meter lights up
green to notify driver that ignition knob can be turned.
NOTE:
When it becomes impossible to rotate the ignition knob, “KEY” warning lamp in combination meter lights
up red.
When key-ID verification is successful and ignition knob switch is in the ON state, Intelligent Key unit uses
CAN communication to send engine start permission signal to BCM.
When BCM receives engine start permission signal, it uses CAN communication to sent starter request
signal to IPDM E/R so that the engine will start when ignition knob is rotated to START position.
Operation Range
Engine can be started when Intelligent Key is in the vehicle. However, sometimes engine might not start when
Intelligent Key is on instrument panel, rear parcel shelf, or in glove box.
Vehicle operation Hazard lamp Horn
Door unlocking operation Once —
Door locking operation Twice Once

Page 909 of 4731

INFINITI FX35 2005 Service Manual BL-94
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
NOTE:
luggage room can enable detection of Intelligent Key by a CONSULT-II function. Refer to BL-120, "
WORK
SUPPORT" .
Active Check Functio

BL-94
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
NOTE:
luggage room can enable detection of Intelligent Key by a CONSULT-II function. Refer to BL-120, "
WORK
SUPPORT" .
Active Check Function
Confirm whether or not ignition knob can be rotated by checking the color of warning lamp in combination
meter.
WARNING AND ALARM FUNCTION
Operation Description
The warnings and alarms are as follows and are given to the user as warning information and warnings using
combinations of Intelligent Key warning buzzer (in driver door and passenger door), inside vehicle buzzer (in
combination meter), and warning lamps “KEY” and “LOCK.”
Ignition switch return forgotten warning
With the ignition in OFF or ACC position, if the driver door is opened, this warning is issued.
Selector lever return forgotten warning
With the ignition in OFF position, if the selector lever is in except “P” position, this warning is issued.
Key left in ignition warning (when mechanical key used)
With the mechanical key in the ignition knob and the ignition switch is in the OFF, ACC, or LOCK position,
if the driver door is opened, this warning is issued.
Ignition switch OFF position warning (for inside car: when door closed)
This warning is issued when the user forgets to return the ignition knob to the LOCK position.
Ignition switch OFF position warning (for outside car: when door opened/closed)
This warning is issued when the user leaves the car without returning the ignition knob to the LOCK posi-
tion.
Warning for removal of Intelligent Key to outside the car (when door open/closed)
This warning is issued if the Intelligent Key is taken outside the car while the engine is running.
Warning for removal of Intelligent Key to outside the car (from window)
This warning is issued if the Intelligent Key is taken outside the car through a window while the engine is
running.
Door lock non-operation warning
This warning is issued if the door lock (lock) operation by a door request switch is not effected.
Intelligent Key low battery warning
This warning is issued when it is detected that the battery in the Intelligent Key has been used up.
Operation Condition
Condition Operation
Ignition knob rotation possible “KEY” warning lamp in combination meter is lit up green.
Ignition rotation not possible “KEY” warning lamp in combination meter is lit up red.
Warning and alarm names Operating conditions (when all the conditions below are met)
Ignition knob return forgotten warn-
ing
The ignition switch is in the ACC, OFF, or LOCK position (knob pressed)
The driver door is opened.
Selector lever return forgotten
warning
The ignition switch is in the OFF position.
The selector lever is except “P” position.
Ignition key warning
(When mechanical key used)
The mechanical key is inserted in the ignition knob (key switch: ON)
The ignition switch is in the ACC, OFF, or LOCK position.
The driver door is opened
Ignition knob OFF position warning
(for inside car: when door closed)
The ignition switch is in the OFF or LOCK position (knob pressed)
In the above state, when the ACC switch is changed from ON to OFF and 1 second
passes. (However, this warning is not issued if the mechanical key is inserted in the igni-
tion knob, ignition knob is turned except OFF position or ignition or ignition knob is not
pushed.)

Page 910 of 4731

INFINITI FX35 2005 Service Manual INTELLIGENT KEY SYSTEM BL-95
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
Warning Procedure
Ignition knob OFF position warning
(for outside car: when door opened/
closed)
Th

INTELLIGENT KEY SYSTEM BL-95
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
Warning Procedure
Ignition knob OFF position warning
(for outside car: when door opened/
closed)
The ignition switch is in the OFF or LOCK position (knob pressed)
In the above state, when the ACC switch is changed from ON to OFF and 1 second
passes. (However, this warning is not issued if the mechanical key is inserted in the igni-
tion knob, ignition knob is turned except OFF position or ignition or ignition knob is not
pushed.)
Driver door open → closed
Warning for take out of Intelligent
Key to outside the car (when door
open/closed)
When Any of the Following Conditions Are Met
When the ignition knob is pressed in so that it can be rotated (or has been rotated), if any
of the doors has been opened, when all the doors are closed, the Intelligent Key unit
compares the key-ID with that of the Intelligent Key using the inside key antenna, if the
results of the comparison are NG (the Intelligent Key is not found)
When the ignition knob is pressed in so that it can be rotated (or has been rotated), if any
of the doors is open, the Intelligent Key unit compares the key-ID with that of the Intelli-
gent Key every 5 seconds using the inside key antenna (center console), if the results of
the comparison are NG (the Intelligent Key is not found)
NOTE:
However, this warning is not issued if the mechanical key is inserted in the ignition knob.
Warning for take out of Intelligent
Key to outside the car (from win-
dow) When the ignition knob is pressed in so that it can be rotated (or has been rotated), if the
vehicle speed is no greater than 5 km per hour, the Intelligent Key unit compares the key-ID
with that of the Intelligent Key every 30 seconds using the inside key antenna, if the results
of the comparison are NG (the Intelligent Key is not found)
Note: The factory setting for this function is OFF.
Door lock non-operation warning When any of the following conditions are met
Intelligent Key Lock-in Prevention Warning
When the Intelligent Key is inside the car and the ignition knob is not pressed, when an
attempt is made to lock a door lock with a door request switch
NOTE:
This warning is issued even if the Intelligent Key is not in the out side key antenna detec-
tion area corresponding to the door request switch was operated.
Knob Return Forgotten Warning
When the ignition knob is pressed, when an attempt is made to lock a door lock with a
door request switch
NOTE:
This warning is only issued if the Intelligent Key is in the out side key antenna detection
area corresponding to the door request switch was operated.
Door Ajar Alarm
When any of the doors is open, when an attempt is made to lock a door lock with a door
request switch
NOTE:
This warning is only issued if the Intelligent Key is in the out side key antenna detection
area corresponding to the door request switch was operated.
Intelligent Key low battery pre-
warning This warning is issued when it is detected that the battery in the Intelligent Key has been
used up.
Warning and alarm names Operating conditions (when all the conditions below are met)
Warning and alarm names
Buzzer Warning lamp
Inside car Outside car “KEY” “P” shift
Ignition switch return forgotten
warning Buzzer: Continuous — — —
Selector lever return for gotten
warning — — — Illuminate
Ignition key warning
(When mechanical key used) Buzzer: Continuous — — —

Page 911 of 4731

INFINITI FX35 2005 Service Manual BL-96
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
Ignition switch OFF position
warning (for inside car: when
door closed) Buzzer: Continuous — — —
Ignition switch OFF position
war

Page 912 of 4731

INFINITI FX35 2005 Service Manual INTELLIGENT KEY SYSTEM BL-97
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
CHANGE SETTINGS FUNCTION
The settings for each function can be changed with the CONSULT-II or Intellige

INTELLIGENT KEY SYSTEM BL-97
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
CHANGE SETTINGS FUNCTION
The settings for each function can be changed with the CONSULT-II or Intelligent Key operation.
Changing Settings With the Intelligent Key
Intelligent Key remote controller button and door request switch operations change the engine startup function
settings (startup enabled/disabled) for each Intelligent Key independently.
Settings Change Procedure
1. With the ignition switch is in the LOCK position (ignition knob not pressed), hold down both the LOCK and UNLOCK remote control buttons on the Intelligent Key at the same time for at least 10 seconds (The yard-
stick is that the Intelligent Key LED flashes 20 times.)
2. Within 5 seconds of releasing the Intelligent Key remote controller buttons, press the driver door request switch.
3. The KEY warning lamp in combination meter lights up for 3 seconds (engine starting enabled → starting
disabled: lights up red, engine starting disabled → flashes green). This completes the settings change.
Changing Settings Using CONSULT-II
The settings for the Intelligent Key system functions can be changed using CONSULT-II (WORK SUPPORT).
Refer to BL-120, "
WORK SUPPORT" .
NOTE:
Once a function setting is changed, it will remain effective even if the battery is disconnected.
Changing Settings Using Display Unit
The settings of the Intelligent Key system can be changed, using CONSULT-II, display unit, Intelligent Key and
door request switch in the center of the instrument panel. Refer to AV- 9 4 , "
Vehicle Electronic Systems" .
×: Applicable –: Not applicable
NOTE:
Once a function setting is changed, it will remain effective even if the battery is disconnected.
INTELLIGENT KEY REGISTRATION
Intelligent Key-ID registration is executed using the CONSULT-II. Up to 4 can be registered.
CAUTION:
After a new Intelligent Key-ID is registered, be sure to check the function.
When registering an additional Intelligent Key-ID, take any Intelligent Keys already registered and
Intelligent Keys for any other vehicles out of the vehicle before starting.
CONSULT-II can be used to check and delete Intelligent Key-IDs.
For future information, see the CONSULT-II Operation Manual NATS.
STEERING LOCK UNIT REGISTRATION
Steering Lock Unit ID Registration
CAUTION:
The method for registering a steering lock unit ID depends on the status of the steering lock unit
and Intelligent Key unit (new or old unit).
After registration is completed, press ignition knob with a portable unit in the vehicle so that it can
be rotated, and confirm that it cannot be rotated even when ignition switch is pressed without a
portable unit in the vehicle.
For further information, see the CONSULT-II Operation Manual NATS.
Setting item Description
Intelligent Key Lock Response-Sound The sound pattern of the Intelligent Key operation can be set as desired. (Setting value:
OFF, Beeper or Horn chirp)
Intelligent Key Unlock Response-Beep
Sound The beep sound when unlocking door with the Intelligent Key operation can be turned ON
or OFF.
Intelligent Key Engine Start Function This function can be performed to ON or OFF.
Intelligent Key Lock/Unlock Function The door handle request switch lock/unlock operation with the Intelligent Key can be can-
celed or activated.
Return All Settings to Default The all settings made by VEHICLE ELECTRONICS will return to default.

Load next 8 pages

Page: < prev 1-10 ... 873-880 881-888 889-896 897-904 905-912 913-920 921-928 929-936 937-944 ... 4736 next >

homelink fuel type power steering oil pressure airbag disable key
