INFINITI FX35 2005 Service Manual LAN-6 [CAN] PRECAUTIONS Revision: 2005 July 2005 FX Precautions For Harness RepairAKS0058J CAN SYSTEM Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.3

Page 3426 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSES WORK FLOW LAN-7 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX TROUBLE DIAGNOSES WORK FLOWPFP:00004 When Displaying CAN Communication System ErrorsAKS00CB

Page 3427 of 4731

INFINITI FX35 2005 Service Manual LAN-8 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: 2005 July 2005 FX TROUBLE DIAGNOSIS FLOW CHART Depending on the control unit which performs CAN communication, “U1010” may be indicated as the res

Page 3428 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSES WORK FLOW LAN-9 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX Diagnosis ProcedureAKS00CBO SELECTING CAN SYSTEM TYPE (HOW TO USE SPECIFICATION TABLE) Dete

Page 3429 of 4731

INFINITI FX35 2005 Service Manual LAN-10 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: 2005 July 2005 FX ACQUISITION OF DATA BY CONSULT-II Attach the data acquired by CONSULT-II on the check sheet determined according to CAN system type

Page 3430 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSES WORK FLOW LAN-11 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX HOW TO USE CHECK SHEET TABLE 1. Unit names displayed on CONSULT-II 2. “No indication”

Page 3431 of 4731

INFINITI FX35 2005 Service Manual LAN-12 [CAN] TROUBLE DIAGNOSES WORK FLOW Revision: 2005 July 2005 FX Example of Filling in Check Sheet When Initial Conditions Are Reproduced 1. Put a check mark to “No indication” if some of unit

Page 3432 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSES WORK FLOW LAN-13 [CAN] C D E F G H I J L M A B LAN Revision: 2005 July 2005 FX 4. Display unit reads the CAN diagnosis monitor check sheet (B) AV- 8 5 , "CAN Communica
