Page 401 of 4731

INFINITI FX35 2005 Service Manual AT-318 REPAIR FOR COMPONENT PARTS Revision: 2005 July 2005 FX Mid Sun Gear, Rear Sun Gear, High and Low Reverse Clutch HubACS0081P COMPONENTS DISASSEMBLY 1. Remove needle bearing and bearing race fro

Page 402 of 4731

INFINITI FX35 2005 Service Manual REPAIR FOR COMPONENT PARTS AT-319 D E F G H I J K L M A B AT Revision: 2005 July 2005 FX 3. Remove high and low reverse clutch hub from mid sun gear assembly. a. Remove needle bearing fr

Page 403 of 4731

INFINITI FX35 2005 Service Manual AT-320 REPAIR FOR COMPONENT PARTS Revision: 2005 July 2005 FX b. Remove 1st one-way clutch from rear sun gear. 5. Remove seal rings from mid sun gear. INSPECTION High and Low Reverse Clutch Hub Snap

Page 404 of 4731

INFINITI FX35 2005 Service Manual REPAIR FOR COMPONENT PARTS AT-321 D E F G H I J K L M A B AT Revision: 2005 July 2005 FX ASSEMBLY 1. Install seal rings to mid sun gear. CAUTION: Do not reuse seal rings. Apply petroleu

Page 405 of 4731

INFINITI FX35 2005 Service Manual AT-322 REPAIR FOR COMPONENT PARTS Revision: 2005 July 2005 FX 5. Install needle bearing to high and low reverse clutch hub. CAUTION: Apply petroleum jelly to needle bearing. 6. Install high and low

Page 406 of 4731

INFINITI FX35 2005 Service Manual REPAIR FOR COMPONENT PARTS AT-323 D E F G H I J K L M A B AT Revision: 2005 July 2005 FX High and Low Reverse ClutchACS0081Q COMPONENTS VQ35DE models VK45DE models SCIA5223E 1. High and l

Page 407 of 4731

INFINITI FX35 2005 Service Manual AT-324 REPAIR FOR COMPONENT PARTS Revision: 2005 July 2005 FX DISASSEMBLY 1. Remove bearing race from high and low reverse clutch drum. 2. Using a flat-bladed screwdriver, remove snap ring from high

Page 408 of 4731

INFINITI FX35 2005 Service Manual REPAIR FOR COMPONENT PARTS AT-325 D E F G H I J K L M A B AT Revision: 2005 July 2005 FX 3. Install bearing race to high and low reverse clutch drum. CAUTION: Apply petroleum jelly to be
