Page 1193 of 4731

INFINITI FX35 2005 Service Manual BRC-52
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
Inspection 12: When “ST ANG SEN SIGNAL” Appears on Self-diagnosis Results
Display
AFS0021V
DTC C1144
INSPECTION PROCEDURE
1. CH

Page 1194 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSIS BRC-53
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Inspection 14: CAN Communication CircuitAFS001T5
DTC U1000, C1156
INSPECTION PROCEDURE
1. CH

Page 1195 of 4731

INFINITI FX35 2005 Service Manual BRC-54
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
Symptom 2: Unexpected Pedal ReactionAFS001T8
1. CHECK BRAKE PEDAL STROKE
Check brake pedal stroke.
Is the stroke too long?
YES >>B

Page 1196 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSIS BRC-55
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Symptom 4: The ABS Function Does Not OperateAFS001TA
CAUTION:
The ABS does not operate when

TROUBLE DIAGNOSIS BRC-55
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
Symptom 4: The ABS Function Does Not OperateAFS001TA
CAUTION:
The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
1. CHECK ABS WARNING LAMP DISPLAY
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> GO TO symptom 1 “Step 2”. Refer to BRC-53, "Symptom 1: Excessive ABS Function Operation
Frequency" .
NG >> Perform self-diagnosis. Refer to BRC-27, "
SELF-DIAGNOSIS" .
Symptom 5: Pedal Vibration or ABS Operation Sound OccursAFS001TB
CAUTION:
Under the following conditions, when brake pedal is lightly depressed (just place a foot on it), ABS is
activated and vibration is felt. However, this is normal.
When shifting gears
When driving on slippery road
During cornering at high speed
When passing over bumps or grooves
When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]
1. SYMPTOM CHECK 1
Check if pedal vibration or operation sound occurs when engine is started.
OK or NG
OK >> Perform self-diagnosis. Refer to BRC-27, "SELF-DIAGNOSIS" .
NG >> GO TO 2.
2. SYMPTOM CHECK 2
Check symptom when electrical component (headlamps, etc.) switches are operated.
Does the symptom occur when the electrical component (head lamp, etc.) switches are operated?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to ABS actuator and electric unit (control unit) (or its wiring), and if there is, move it farther away.
NO >> GO TO symptom 1 “Step 2”. Refer to BRC-53, "
Symptom 1: Excessive ABS Function Operation
Frequency" .
Symptom 6: Vehicle Jerks During VDC/TCS/ABS ControlAFS001TC
1. CHECK ENGINE SPEED SIGNAL
Perform CONSULT-II “DATA MONITOR” to check engine speed.
Is engine speed at idle 400 rpm or higher?
YES >> GO TO 3.
NO >> GO TO 2.
2. ABS WARNING LAMP DISPLAY CHECK
Make sure warning lamp turns off approximately 2 seconds after the ignition switch is turned ON or when driv-
ing.
OK or NG
OK >> System is normal.
NG >> GO TO 3.

Page 1197 of 4731

INFINITI FX35 2005 Service Manual BRC-56
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
3. CHECK ECM SELF-DIAGNOSTIC RESULTS
Perform ECM self-diagnosis.
Are self-diagnosis items displayed?
YES >> Check the corresponding

Page 1198 of 4731

INFINITI FX35 2005 Service Manual WHEEL SENSORS BRC-57
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
WHEEL SENSORSPFP:47910
Removal and InstallationAFS001Z3
REMOVAL
1. Disconnect wheel sensor conne

Page 1199 of 4731

INFINITI FX35 2005 Service Manual BRC-58
[VDC/TCS/ABS]
WHEEL SENSORS
Revision: 2005 July 2005 FX
When installing rear sensor, attach harness at rear suspension member securely. Besides, har-
ness must not be twisted when installed.

Page 1200 of 4731

INFINITI FX35 2005 Service Manual SENSOR ROTOR BRC-59
[VDC/TCS/ABS]
C
D E
G H
I
J
K L
M A
B
BRC
Revision: 2005 July 2005 FX
SENSOR ROTORPFP:47970
Removal and InstallationAFS001Z4
REMOVAL
Front
Sensor rotor cannot be disa
