INFINITI FX35 2005 Service Manual TF-56
TRANSFER ASSEMBLY
Revision: 2005 July 2005 FX
16. Apply liquid gasket to mating surface of rear case.
Use Genuine Anaerobic Liquid Gasket or equivalent.
Refer to GI-48, "
Recommended Chemic

Page 4690 of 4731

INFINITI FX35 2005 Service Manual TRANSFER ASSEMBLY TF-57
C E F
G H
I
J
K L
M A
B
TF
Revision: 2005 July 2005 FX
20. Install rear oil seal to rear case, using a drift.
CAUTION:
Do not reuse rear oil seal.
Apply ATF to r

Page 4691 of 4731

INFINITI FX35 2005 Service Manual TF-58
TRANSFER ASSEMBLY
Revision: 2005 July 2005 FX
Use Genuine Silicone RTV or equivalent. Refer to GI-48, "Recommended Chemical Products and
Sealants" .
CAUTION:
Remove old sealant and oil adheri

Page 4692 of 4731

INFINITI FX35 2005 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) TF-59
C E F
G H
I
J
K L
M A
B
TF
Revision: 2005 July 2005 FX
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsADS000S9
Applied mod

Page 4693 of 4731

INFINITI FX35 2005 Service Manual TF-60
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2005 July 2005 FX

Page 4694 of 4731

INFINITI FX35 2005 Service Manual WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G H
I
J
K L
M
SECTION WT
A
B
WT
Revision: 2005 July 2005 FX
ROAD WHEELS & TIRES
PREPARATION ..........................................

WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G H
I
J
K L
M
SECTION WT
A
B
WT
Revision: 2005 July 2005 FX
ROAD WHEELS & TIRES
PREPARATION ........................................................... 2
Special Service Tools .......................................... ..... 2
Commercial Service Tools ................................... ..... 2
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ........................................... ..... 3
NVH Troubleshooting Chart ................................ ..... 3
ROAD WHEEL ....................................................... ..... 4
Inspection ............................................................ ..... 4
ALUMINUM WHEEL ........................................ ..... 4
STEEL WHEEL ................................................ ..... 4
ROAD WHEEL TIRE ASSEMBLY ......................... ..... 5
Balancing Wheels (Bonding Weight Type) .......... ..... 5
REMOVAL ........................................................ ..... 5
WHEEL BALANCE ADJUSTMENT ................. ..... 5
Tire Rotation ........................................................ ..... 6
LOW TIRE PRESSURE WARNING SYSTEM ....... ..... 7
System Components ........................................... ..... 7
System Description ............................................. ..... 7
TRANSMITTER ................................................ ..... 7
REMOTE KEYLESS ENTRY RECEIVER ........ ..... 7
BCM (BODY CONTROL MODULE) ................. ..... 8
LOW TIRE PRESSURE WARNING LAMP ...... ..... 8
DISPLAY UNIT ................................................. ..... 8
CAN COMMUNICATION ....................................... ..... 9
System Description ............................................. ..... 9
TROUBLE DIAGNOSES ....................................... ... 10
Schematic ........................................................... ... 10
Wiring Diagram ................................................... .... 11
Control Unit Input/Output Signal Standard .......... ... 14
ID Registration Procedure ................................... ... 16
ID REGISTRATION WITH ACTIVATION TOOL ... 16
ID REGISTRATION WITHOUT ACTIVATION
TOOL ............................................................... ... 17
Transmitter Wake Up Operation .......................... ... 18
WITH ACTIVATION TOOL ............................... ... 18
Self-Diagnosis ..................................................... ... 19
DESCRIPTION ................................................. ... 19
FUNCTION ....................................................... ... 19
LOW TIRE PRESSURE WARNING LAMP DIAG-
NOSTIC CHART .............................................. ... 19 CONSULT-II ......................................................
... 20
WORK SUPPORT MODE ................................ ... 21
SELF-DIAGNOSTIC RESULTS MODE ............ ... 21
DATA MONITOR MODE ................................... ... 22
ACTIVE TEST MODE ...................................... ... 22
How to Perform Trouble Diagnosis for Quick and
Accurate Repair ................................................... ... 25
INTRODUCTION .............................................. ... 25
WORK FLOW ................................................... ... 25
Preliminary Check ............................................... ... 26
Malfunction Code/Symptom Chart ....................... ... 27
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ..................................................................... ... 28
Inspection 1: Transmitter or Control Unit (BCM) .. ... 28
MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 28
Inspection 2: Transmitter - 1 ................................ ... 28
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................ ... 28
Inspection 3: Transmitter - 2 ................................ ... 29
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 29
Inspection 4: Vehicle Speed Signal ..................... ... 30
MALFUNCTION CODE NO. 52 ........................ ... 30
TROUBLE DIAGNOSIS FOR SYMPTOMS ........... ... 31
Inspection 1: Warning Lamp Does Not Come On
When Ignition Switch Is Turned On ..................... ... 31
Inspection 2: Warning Lamp Stays On When Ignition
Switch Is Turned On ............................................ ... 31
Inspection 3: Warning Lamp Blinks When Ignition
Switch Is Turned On ............................................ ... 33
Inspection 4: Turn Signal Lamp Blinks When Ignition
Switch Is Turned On ............................................ ... 34
Inspection 5: ID Registration Can Not Be Completed ... 34
REMOVAL AND INSTALLATION .......................... ... 35
Transmitter .......................................................... ... 35
REMOVAL ........................................................ ... 35
INSTALLATION ................................................ ... 35
SERVICE DATA ..................................................... ... 37
Road Wheel ......................................................... ... 37
Tire ...................................................................... ... 37
Tightening Torque ................................................ ... 37
