INFINITI FX35 2005 Service Manual WT-28
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Inspection 1: Transmitter or Control Unit (BCM)AES000ZB
MALFUNCTION C

WT-28
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:00000
Inspection 1: Transmitter or Control Unit (BCM)AES000ZB
MALFUNCTION CODE NO. 21, 22, 23 OR 24
1. CHECK CONTROL UNIT
Drive for several minutes. Check all tire pressures with CONSULT-II “DATA MONITOR ITEM”.
Are all tire pressures displayed 0 kPa?
YES >> GO TO 2.
NO >> GO TO 3.
2. CHECK REMOTE KEYLESS ENTRY RECEIVER CONNECTOR
1. Disconnect remote keyless entry receiver harness connector M98.
2. Check terminals for damage or loose connection.
3. Reconnect harness connector.
OK or NG
OK >> Replace BCM refer to BCS-16, "Removal and Installation of BCM" , then GO TO 3.
NG >> Repair or replace remote keyless entry receiver harness connector.
3. ID REGISTRATION
Perform ID registration of all transmitters.
Is there any tire that ID can not be registered to?
YES >> Replace transmitter of the tire, then GO TO 5.
NO >> GO TO 4.
4. VEHICLE DRIVING
Drive at a speed of 40 km/h (25 MPH) or more for several minutes without stopping.
Check all tire pressures with CONSULT-II “DATA MONITOR ITEM” within 15 minutes after vehicle speed
becomes 17 km/h (11 MPH).
Does
“DATA MONITOR ITEM” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> GO TO 5.
5. ID REGISTRATION AND VEHICLE DRIVING
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for 10 minutes. Then check all tire pressures with CONSULT-II “DATA MONITOR ITEM” within 5 minutes.
Does
“DATA MONITOR ITEM” display tire pressure as normal without any warning lamp?
YES >> INSPECTION END
NO >> GO TO the inspection applicable to DTC.
Inspection 2: Transmitter - 1AES000ZC
MALFUNCTION CODE NO. 31, 32, 33, 34, 41, 42, 43, 44, 45, 46, 47 OR 48
1. ID REGISTRATION (CORRECTION OF TRANSMITTER LOCATION)
1. Perform ID registration of all transmitters.
2. Drive at a speed of 40 km/h (25 MPH) or more for 3 minutes, and then drive the vehicle at any speed for 10 minutes.
>> GO TO 2.

Page 4722 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS WT-29
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2005 July 2005 FX
2. REPLACE TRANSMITTER
1. Check low tire pressure warning condition again, replac

Page 4723 of 4731

INFINITI FX35 2005 Service Manual WT-30
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2005 July 2005 FX
Inspection 4: Vehicle Speed SignalAES000ZE
MALFUNCTION CODE NO. 52
1. CHECK SELF-DIAGNOSIS RESULTS
1. With the ignition s

Page 4724 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS WT-31
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2005 July 2005 FX
TROUBLE DIAGNOSIS FOR SYMPTOMSPFP:00007
Inspection 1: Warning Lamp Does Not Come On When Igniti

Page 4725 of 4731

INFINITI FX35 2005 Service Manual WT-32
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2005 July 2005 FX
2. CHECK POWER SUPPLY CIRCUIT (BATTERY)
Make sure voltage between BCM harness connector M4 terminals 42 (GY), 55 (R) and ground.
OK o

Page 4726 of 4731

INFINITI FX35 2005 Service Manual TROUBLE DIAGNOSIS FOR SYMPTOMS WT-33
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2005 July 2005 FX
Inspection 3: Warning Lamp Blinks When Ignition Switch Is Turned OnAES000ZH
NOTE:
If warning l

Page 4727 of 4731

INFINITI FX35 2005 Service Manual WT-34
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2005 July 2005 FX
Inspection 4: Turn Signal Lamp Blinks When Ignition Switch Is Turned OnAES000ZI
DIAGNOSTIC PROCEDURE
1. CHECK TIRE PRESSURE WARNING CHE

Page 4728 of 4731

INFINITI FX35 2005 Service Manual REMOVAL AND INSTALLATION WT-35
C
D
F
G H
I
J
K L
M A
B
WT
Revision: 2005 July 2005 FX
REMOVAL AND INSTALLATIONPFP:00000
TransmitterAES000ZK
REMOVAL
1. Deflate tire. Unscrew transmitter re
