2005 INFINITI FX35 Service Manual

trailer fuel cap release fuel consumption low oil pressure differential refuelling

Load previous 8 pages

Page 3025 of 4731

INFINITI FX35 2005 Service Manual EM-190
[VK45DE]
SPARK PLUG (PLATINUM-TIPPED TYPE)
Revision: 2005 July 2005 FX
SPARK PLUG (PLATINUM-TIPPED TYPE)PFP:22401
ComponentsABS00DFS
Removal and InstallationABS006IG
REMOVAL
1. Remove engine c

Page 3026 of 4731

INFINITI FX35 2005 Service Manual SPARK PLUG (PLATINUM-TIPPED TYPE) EM-191
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
CAUTION:
Do not drop or shock spark plug.
Do not use wire brush for cleaning.
I

Page 3027 of 4731

INFINITI FX35 2005 Service Manual EM-192
[VK45DE]
FUEL INJECTOR AND FUEL TUBE
Revision: 2005 July 2005 FX
FUEL INJECTOR AND FUEL TUBEPFP:16600
ComponentsABS00DFT
CAUTION:
Do not remove or disassemble parts unless instructed as shown

Page 3028 of 4731

INFINITI FX35 2005 Service Manual FUEL INJECTOR AND FUEL TUBE EM-193
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
3. Disconnect fuel feed hose on engine side as follows: (Excepting
to confirm whether o

Page 3029 of 4731

INFINITI FX35 2005 Service Manual EM-194
[VK45DE]
FUEL INJECTOR AND FUEL TUBE
Revision: 2005 July 2005 FX
To keep clean the connecting portion and to avoid dam-
age and foreign materials, cover them completely with
plastic bags or s

Page 3030 of 4731

INFINITI FX35 2005 Service Manual FUEL INJECTOR AND FUEL TUBE EM-195
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
When handling new O-rings, be careful of the following caution:
CAUTION:
Handle O-rin

FUEL INJECTOR AND FUEL TUBE EM-195
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
When handling new O-rings, be careful of the following caution:
CAUTION:
Handle O-ring with bare hands. Do not wear gloves.
Lubricate O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of foreign material.
When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not
to twist or stretch O-ring. If O-ring was stretched while it was being attached, do not insert it
quickly into fuel tube.
Insert new O-ring straight into fuel tube. Do not decenter or twist it.
Insert fuel damper (RH) and fuel feed damper straight into fuel tube (RH).
Tighten mounting bolts evenly in turn.
After tightening mounting bolts, make sure that there is no gap between flange and fuel tube (RH).
2. Install new O-rings to fuel injector paying attention to the following caution. CAUTION:
Upper and lower O-ring are different. Be careful not to confuse them.
Handle O-ring with bare hands. Never wear gloves.
Lubricate O-ring with new engine oil.
Do not clean O-ring with solvent.
Make sure that O-ring and its mating part are free of foreign material.
When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched while it was being attached, do not insert it
quickly into fuel tube.
Insert O-ring straight into fuel injector. Do not decenter or twist it.
3. Install fuel injector to fuel tube as follows:
a. Insert clip into clip mounting groove on fuel injector.
Insert clip so that protrusion “A” of fuel injector matches cutout
“A” of clip.
CAUTION:
Do not reuse clip. Replace it with a new one.
Be careful to keep clip from interfering with O-ring. If
interference occurs, replace O-ring.
b. Insert fuel injector into fuel tube with clip attached.
Insert it while matching it to the axial center.
Insert fuel injector so that protrusion “B” of fuel tube matches
cutout “B” of clip.
Make sure that fuel tube flange is securely fixed in flange fix-
ing groove on clip.
c. Make sure that installation is complete by checking that fuel injector does not rotate or come off.
Make sure that protrusions of fuel injectors are aligned with
cutouts of clips after installation.
4. Install spacers on intake manifold (lower).
5. Install fuel tube and fuel injector assembly to intake manifold. CAUTION:
Be careful not to let tip of injector nozzle come in contact with other parts. Fuel tube side : Black
Nozzle side : Green
PBIC2545E

Page 3031 of 4731

INFINITI FX35 2005 Service Manual EM-196
[VK45DE]
FUEL INJECTOR AND FUEL TUBE
Revision: 2005 July 2005 FX
Tighten mounting bolts in two steps in numerical order as
shown in the figure.
6. Connect fuel feed hose on engine side as th

EM-196
[VK45DE]
FUEL INJECTOR AND FUEL TUBE
Revision: 2005 July 2005 FX
Tighten mounting bolts in two steps in numerical order as
shown in the figure.
6. Connect fuel feed hose on engine side as the following: (Excepting to confirm whether or not there is quick connector cap, perform same procedure for the side of centralized under-floor piping as well.)
a. Make sure no foreign substances are deposited in and around fuel tube and quick connector, and no dam- age on them.
b. Thinly apply new engine oil around fuel tube from tip end to spool end.
c. Align center to insert quick connector straightly into fuel tube.
Insert fuel tube into quick connector until top spool is com-
pletely inside quick connector, and 2nd level spool exposes
right below quick connector.
CAUTION:
Hold “A” position as shown in the figure when inserting
fuel tube into quick connector.
Carefully align center to avoid inclined insertion to pre-
vent damage to O-ring inside quick connector.
Insert until you hear a “click” sound and actually feel the
engagement.
To avoid misidentification of engagement with a similar
sound, be sure to perform the next step.
d. Pull quick connector by hand holding “A” position. Make sure it is completely engaged (connected) so that it does not come out from fuel tube.
e. Install quick connector cap on quick connector connection. (on engine side only).
CAUTION:
If cap cannot be installed smoothly, quick connector may
have not been installed correctly. Check connection again.
f. Install fuel feed hose to hose clamps.
7. Install in the reverse order of removal after this step.
INSPECTION AFTER INSTALLATION
Check on Fuel Leakage
1. Turn ignition switch “ON” (with engine stopped). With fuel pressure applied to fuel piping, check for fuel leakage at connection points.
NOTE:
Use mirrors for checking at points out of clear sight.
2. Start engine. With engine speed increased, check again for fuel leakage at connection points. CAUTION:
Do not touch engine immediately after stopped, as engine becomes extremely hot. 1st step : 10.1 N·m (1.0 kg-m, 7 ft-lb)
2nd step : 23.5 N·m (2.4 kg-m, 17 ft-lb)
PBIC2338E
KBIA0272E
SBIA0354E

Page 3032 of 4731

INFINITI FX35 2005 Service Manual ROCKER COVER EM-197
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
ROCKER COVERPFP:13264
ComponentsABS00DFU
Removal and InstallationABS006II
REMOVAL
1. Remove engine cove
