Page 897 of 4731
BL-82
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2005 July 2005 FX
Check IPDM E/R OperationAIS004MO
1. CHECK IPDM E/R INPUT VOLTAGE
Check voltage between IPDM E/R connector E9 terminal 51 and
ground.
OK or NG
OK >> Replace IPDM E/R.
NG >> GO TO 2.
2. CHECK IPDM E/R HARNESS
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and horn relay connector.
3. Check continuity between IPDM E/R connector E9 terminal 51 and horn relay connector E10 terminal 1.
OK or NG
OK >> Check harness connection.
NG >> Repair or replace harness. 51 (SB) – Ground : Battery voltage
PIIA6403E
51 (SB) – 1 (SB) : Continuity should exist.
PIIA6404E
Page 898 of 4731

REMOTE KEYLESS ENTRY SYSTEM BL-83
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
Check Hazard Warning Lamp FunctionAIS004MP
1. CHECK HAZARD WARNING LAMP
Do hazard warning lamp flash with hazard switch?
YES or NO
YES >> Hazard warning lamp circuit is OK.
NO >> Check hazard circuit. Refer to LT- 9 1 , "
TURN SIGNAL AND HAZARD WARNING LAMPS" .
Check Horn FunctionAIS004MQ
First perform the “SELF-DIAG RESULTS” in “BCM” with CONSULT-II, then perform the trouble diagnosis of
malfunction system indicated “SELF-DIAG RESULTS” of “BCM”. Refer to BCS-15, "
CAN Communication
Inspection Using CONSULT-II (Self-Diagnosis)" .
1. CHECK HORN FUNCTION
Does horn sound with horn switch?
YES or NO
YES >> Horn circuit is OK.
NO >> Check horn circuit. Refer to WW-59, "
HORN" .
Check Headlamp FunctionAIS004MR
First perform the “SELF-DIAG RESULTS” in “BCM” with CONSULT-II, then perform the trouble diagnosis of
malfunction system indicated “SELF-DIAG RESULTS” of “BCM”. Refer to BCS-15, "
CAN Communication
Inspection Using CONSULT-II (Self-Diagnosis)" .
1. CHECK HEADLAMP FUNCTION
Does headlamp come on when turning lighting switch “ON”?
YES or NO
YES >> Headlamp operation circuit is OK.
NO >> Check headlamp system. Refer to LT- 7 , "
HEADLAMP - XENON TYPE -" .
Check Map Lamp and Ignition Keyhole Illumination FunctionAIS004MS
1. CHECK MAP LAMP AND IGNITION KEYHOLE ILLUMINATION FUNCTION
When map lamp switch is in “DOOR” position, open the front door (LH or RH).
OK or NG
OK >> Replace BCM.
NG >> Check ignition illumination circuit. Refer to LT- 1 5 9 , "
INTERIOR ROOM LAMP" .
Map lamp and ignition keyhole illumination should illuminate.
Page 899 of 4731

BL-84
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2005 July 2005 FX
ID Code Entry ProcedureAIS004MT
KEY FOB ID SET UP WITH CONSULT-II
NOTE:
If a key fob is lost, the ID code of the lost key fob must be erased to prevent unauthorized use. A
specific ID code can be erased with CONSULT-II. However, when the ID code of a lost key fob is not
known, all controller ID codes should be erased. After all ID codes are erased, the ID codes of all
remaining and/or new key fobs must be re-registered.
When registering an additional key fob, the existing ID codes in memory may or may not be
erased. If four ID codes are stored in memory, when an additional code is registered, only the old-
est code is erased. If less than five ID codes are stored in memory, when an additional ID code is
registered, the new ID code is added and no ID codes are erased.
Entry of maximum five ID codes is allowed. When more than four ID codes are entered, the oldest
ID code will be erased.
Even if same ID code that is already in the memory is input, the same ID code can be entered. The
code is counted as an additional code.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Turn ignition switch “OFF”.
2. Connect “CONSULT-II” and “CONSULT-II CONVERTER” to the data link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “BCM”. If “BCM” is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
PBIB1503E
BCIA0029E
BCIA0030E
Page 900 of 4731
REMOTE KEYLESS ENTRY SYSTEM BL-85
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
6. Touch “MULTI REMOTE ENT”.
7. Touch “WORK SUPPORT”.
8. The items are shown on the figure can be set up.
“REMO CONT ID CONFIR”
Use this mode to confirm if a key fob ID code is registered or
not.
“REMO CONT ID REGIST”
Use this mode to register a key fob ID code.
NOTE:
Register the ID code when key fob or BCM is replaced, or
when additional key fob is required.
“REMO CONT ID ERASUR”
Use this mode to erase a key fob ID code.
LIIA0194E
BCIA0031E
LIIA0207E
Page 901 of 4731
BL-86
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2005 July 2005 FX
KEY FOB ID SET UP WITHOUT CONSULT-II
PIIA2839E
Page 902 of 4731

REMOTE KEYLESS ENTRY SYSTEM BL-87
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
NOTE:
If a key fob is lost, the ID code of the lost key fob must be erased to prevent unauthorized use. A specific
ID code can be erased with CONSULT-II. However, when the ID code of a lost key fob is not known, all
controller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining and/or
new key fobs must be re-registered.
To erase all ID codes in memory, register one ID code (key fob) five times. After all ID codes are erased,
the ID codes of all remaining and/or new key fobs must be re-registered.
When registering an additional key fob, the existing ID codes in memory may or may not be erased. If five
ID codes are stored in memory, when an additional code is registered, only the oldest code is erased. If
less than five ID codes are stored in memory, when an additional ID code is registered, the new ID code is
added and no ID codes are erased.
If you need to activate more than two additional new key fobs, repeat the procedure “Additional ID code
entry” for each new key fob.
Entry of maximum five ID codes is allowed. When more than five ID codes are entered, the oldest ID code
will be erased.
Even if same ID code that is already in the memory is input, the same ID code can be entered. The code
is counted as an additional code.
Removal and Installation of Remote keyless Entry receiverAIS006A2
REMOVAL
1. Remove the instrument passenger lower panel. Refer to IP-18, "INSTRUMENT PASSENGER LOWER
PA N E L" .
2. Disconnect remote keyless entry receiver harness connector, remove screw and remote keyless entry receiver.
INSTALLATION
Install in the reverse order of removal.
PIIB4073E
Page 903 of 4731
BL-88
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2005 July 2005 FX
Key Fob Battery ReplacementAIS004MU
PIIA4706E
Page 904 of 4731
INTELLIGENT KEY SYSTEM BL-89
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
INTELLIGENT KEY SYSTEMPFP:285e2
Component Parts and Harness Connector LocationAIS004MV
PIIA9927E
