2005 INFINITI FX35 Service Manual

load capacity differential fuel pressure immobilizer roof set clock

Page 3057 of 4731

INFINITI FX35 2005 Service Manual EM-222
[VK45DE]
CAMSHAFT
Revision: 2005 July 2005 FX
3. For the measured value are out of the standard, perform adjustment. Refer to EM-222, "ADJUSTMENT" .
ADJUSTMENT
NOTE:
Adjust valve clearance whi

EM-222
[VK45DE]
CAMSHAFT
Revision: 2005 July 2005 FX
3. For the measured value are out of the standard, perform adjustment. Refer to EM-222, "ADJUSTMENT" .
ADJUSTMENT
NOTE:
Adjust valve clearance while engine is cold.
1. Thoroughly wipe off engine oil around adjusting shim using rag.
2. Rotate crankshaft to position cam nose on camshaft of valve that must be adjusted upward.
3. Using small screwdriver, turn the round hole of adjusting shim in the direction of the arrow.
CAUTION:
perform (the above procedure) during camshaft do not con-
tact with adjusting shim.
4. Install lifter stopper [SST: 10115120 (J38972-2)] as follows:
a. Except exhaust side of No. 7 and 8 cylinder;
i. Place camshaft pliers (SST) around camshaft as shown in the figure.
ii. Rotate camshaft pliers so that valve lifter is pushed down. CAUTION:
Be careful not to damage cam surface, valve lifter and cylin-
der head with camshaft pliers.
iii. Place lifter stopper between camshaft and the edge of valve lifter to retain valve lifter.
CAUTION:
Lifter stopper must be placed as close to camshaft
bracket as possible.
Be careful not to damage cam surface, valve lifter and
cylinder head with lifter stopper.
iv. Remove camshaft pliers. CAUTION:
Camshaft pliers should be removed by rotating it slowly
because lifter stopper hits and damages journal portion by
rotating camshaft pliers quickly.
b. Exhaust side of No. 7 and 8 cylinder; NOTE:
Exhaust side of No. 7 and 8 cylinder does not have space for installing camshaft pliers [SST: KV10115110
(J38972-1)]. therefore, install lifter stopper [SST: KV10115120 (J38972-2)] according to the following
instructions.
i. Rotate crankshaft to press cam nose to the adjusting part of valve lifter.
ii. Place lifter stopper between camshaft and the edge of valve lifter to retain valve lifter. CAUTION:
Lifter stopper must be placed as close to camshaft bracket as possible.
Be careful not to damage cam surface, valve lifter and cylinder head with lifter stopper.
iii. Rotate crankshaft slowly 180 degrees clockwise.
PBIC0047E
PBIC2276E
PBIC1565E

Page 3058 of 4731

INFINITI FX35 2005 Service Manual CAMSHAFT EM-223
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
CAUTION:
Rotating crankshaft slowly because lifter stopper hits and damages journal portion by rotating
cr

Page 3059 of 4731

INFINITI FX35 2005 Service Manual EM-224
[VK45DE]
CAMSHAFT
Revision: 2005 July 2005 FX
Thickness of new adjusting shim can be identified by stamp
marks on the reverse side (inside the cylinder).
8. Install new adjusting shim using

Page 3060 of 4731

INFINITI FX35 2005 Service Manual OIL SEAL EM-225
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
OIL SEALPFP:00100
Removal and Installation of Valve Oil SealABS006IM
REMOVAL
1. Remove engine assembly from

Page 3061 of 4731

INFINITI FX35 2005 Service Manual EM-226
[VK45DE]
OIL SEAL
Revision: 2005 July 2005 FX
Removal and Installation of Front Oil SealABS006IN
REMOVAL
1. Remove the following parts:
Front engine undercover
Radiator; Refer to CO-41, "RADI

Page 3062 of 4731

INFINITI FX35 2005 Service Manual OIL SEAL EM-227
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
Install front oil seal so that each seal lip is oriented as shown
in the figure.
Using front oil seal dr

Page 3063 of 4731

INFINITI FX35 2005 Service Manual EM-228
[VK45DE]
OIL SEAL
Revision: 2005 July 2005 FX
Using rear oil seal drift (commercial service tool), press fit
until the height of front oil seal is level with the mounting sur-
face.
Make sur

Page 3064 of 4731

INFINITI FX35 2005 Service Manual CYLINDER HEAD EM-229
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EM
Revision: 2005 July 2005 FX
CYLINDER HEADPFP:11041
On-Vehicle ServiceABS006IP
CHECKING COMPRESSION PRESSURE
1. Warm up engine thor
