INFINITI FX35 2005 Service Manual AV-90
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
BIRDVIEW™
Description
Display area: Trapezoidal representation showing approximate
distances (Wn, D, and Wd).
Ten horizontal grid lines indica

Page 690 of 4731

INFINITI FX35 2005 Service Manual NAVIGATION SYSTEM AV-91
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
FUNCTION OF CENTER SWITCH
Display with Pushed “DEST” Button
Easy Mode
Expert Mode
The function of ea

Page 691 of 4731

INFINITI FX35 2005 Service Manual AV-92
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
Display with Pushed “ROUTE” Button
Easy Mode
Expert Mode
The function of each icon is as follows:
*: When destinations have been entered, rou

Page 692 of 4731

INFINITI FX35 2005 Service Manual NAVIGATION SYSTEM AV-93
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
Display with Pushed “SETTING” Button
The function of each icon is as follows:
Display Settings
How To Pe

Page 693 of 4731

INFINITI FX35 2005 Service Manual AV-94
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
Vehicle Electronic Systems
How To Perform Vehicle Electronic Systems
1. Start the engine.
2. Push “SETTING” button.
3. Select “Vehicle Electr

AV-94
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
Vehicle Electronic Systems
How To Perform Vehicle Electronic Systems
1. Start the engine.
2. Push “SETTING” button.
3. Select “Vehicle Electronic Systems”.
4. Push “Enter” switch.
Application Items
Adjust Driver Seat When Exiting Vehicle
1. Select “Adjust Driver Seat When Exiting Vehicle”.
2. Push “Enter” switch.
The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Lift Steering Column When Exiting Vehicle
1. Select “Lift Steering Column When Exiting Vehicle”.
2. Push “Enter” switch.
The indicator light alternately turns on and off each time the “Enter” switch is pressed.
Selective Door Unlock (With Intelligent Key)
1. Select “Selective Door Unlock”.
PKIB6603E
Icon Description Reference
page
Adjust Driver Seat When Exiting Vehicle The driver's seat automatically moves back and returns to the original
position. AV- 9 4
Lift Steering Column When Exiting Vehicle This function can be performed to On or Off.
AV- 9 4
Selective Door Unlock This key can switch the unlock doors of the 1st unlocking operation as
follows.
Only the driver side door (On) ⇔All the doors (Off) AV- 9 4
Keyless Remote Response-Horn
This key changes the horn chirp mode occurring when pressing the
Lock button on the Intelligent Key or keyfob. AV- 9 5
Keyless Remote Response-Lights
This key changes the hazard indicator flash mode occurring when
pressing the Lock or Unlock button on the Intelligent Key or keyfob. AV- 9 5
Auto Re-Lock TimeThe length of auto door relock time can be set.
(Setting value: OFF, 1min or 5min) AV- 9 5
Sensitivity of Automatic Headlights Sensitivity of automatic light can be set as desired.
AV- 9 5
Automatic Headlights Off Delay You can control how long it takes the automatic turn off timer to extin-
guish the headlights in AUTO position.
(Setting value: OFF, 30sec, 45sec, 60sec, 90sec, 120sec, 150sec or
180sec) AV- 9 5
Speed Dependent wiper This function can be performed to On or Off.
AV- 9 5
Intelligent Key Lock Response-Sound The sound pattern of the Intelligent Key operation can be set as desired.
(Setting value:OFF, Beeper or Horn chirp) AV- 9 5
Intelligent Key Unlock Response-Beep Sound
The beep sound when unlocking door with the intelligent key operation
can be turned On or Off. AV- 9 5
Intelligent Key Lock/Unlock FunctionThe door handle request switch lock/unlock operation with the Intelligent
Key can be canceled or activated. AV- 9 5
Return All Settings to Default The all settings made by VEHICLE ELECTRONICS will return to
default. AV- 9 5

Page 694 of 4731

INFINITI FX35 2005 Service Manual NAVIGATION SYSTEM AV-95
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
2. Push “Enter” switch.
The indicator light alternately turns on and off each time the “Enter” swi

Page 695 of 4731

INFINITI FX35 2005 Service Manual AV-96
NAVIGATION SYSTEM
Revision: 2005 July 2005 FX
System Settings
How To Perform System Settings
1. Start the engine.
2. Push “SETTING” button.
3. Select “System Settings”.
Application Ite

Page 696 of 4731

INFINITI FX35 2005 Service Manual NAVIGATION SYSTEM AV-97
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
Navigation Settings
How To Perform Navigation Settings
1. Start the engine.
2. Push “SETTING” button.
3

NAVIGATION SYSTEM AV-97
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
Navigation Settings
How To Perform Navigation Settings
1. Start the engine.
2. Push “SETTING” button.
3. Select “Navigation”.
Application Items
“VIEW” MODE
To open the map screen display with Birdview™, select “Bird-
view™”.
To open the map screen display with Plan View, select “Plan
View”.
SKIA0551E
Icon Description Reference
page
View Map display mode can be switched. AV- 9 7
Heading Heading of the map display can be customized for either north heading or the actual
driving direction of the vehicle. AV- 9 8
Nearby Display Icons
Icons of facilities can be displayed.
Facilities to be displayed can be selected from the variety selections. AV- 9 8
Save Current Location Current vehicle location can be registered in Address Book.
AV- 9 8
Adjust Current Location Current location of position marker can be adjusted. Direction of position marker
also can be calibrated when heading direction of the vehicle on the display is not
matched with the actual direction. AV- 9 8
Auto Re-route On/Off ON/OFF of Auto Re-route can be switched.
AV- 9 9
Avoid Area Setting A particular area can be avoided when routing.AV- 9 9
Clear Memory Address Book, Previous destination or Avoid area can be deleted.AV- 9 9
Edit Address Book Address Book can be edited.AV- 1 0 0
GPS Information The GPS data includes longitude, latitude and altitude (distance above sea level) of
the present vehicle position, and current date and time for the area in which the
vehicle is being driven.
Also indicated are the GPS reception conditions and the GPS satellite position. AV- 1 0 0
Quick Stop Customer Setting One facility of your selection can be added to your quick stop.
AV- 1 0 0
Set Average Speed for Estimated
Journey Time Average vehicle speed can be set to calibrate estimated journey time for the desti-
nation. AV- 1 0 0
Tracking On/Off Tracking to the present vehicle position can be displayed.
AV- 1 0 1
SKIA0554E
