Page 2985 of 4731

INFINITI FX35 2005 Service Manual EM-150 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2005 July 2005 FX SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00100 Standard and LimitABS004XK GENERAL SPECIFICATIONS Cylinder arrangement

Page 2986 of 4731

INFINITI FX35 2005 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-151 [VQ35DE] C D E F G H I J K L M A EM Revision: 2005 July 2005 FX DRIVE BELT *: If belt tension gauge cannot be installed at check points shown,

Page 2987 of 4731

INFINITI FX35 2005 Service Manual EM-152 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2005 July 2005 FX CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) * 1 : Cam wear limit *2 : Total indicator reading Valve Lifter Unit: mm

Page 2988 of 4731

INFINITI FX35 2005 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-153 [VQ35DE] C D E F G H I J K L M A EM Revision: 2005 July 2005 FX Available Valve Lifter Unit: mm (in) Identification (stamped) mark Thickness

Page 2989 of 4731

INFINITI FX35 2005 Service Manual EM-154 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2005 July 2005 FX CYLINDER HEAD Unit: mm (in) Valve Dimensions Unit: mm (in) Items Standard Limit Head surface distortion Less than 0.

Page 2990 of 4731

INFINITI FX35 2005 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-155 [VQ35DE] C D E F G H I J K L M A EM Revision: 2005 July 2005 FX Valve Guide Unit: mm (in) Items Standard 0.2 (0.008) oversize (Service) Valv

Page 2991 of 4731

INFINITI FX35 2005 Service Manual EM-156 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2005 July 2005 FX Valve Seat Unit: mm (in) * 1 : Diameter made by intersection point of conic angles “ α1” and “ α2” *2 :

Page 2992 of 4731

INFINITI FX35 2005 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-157 [VQ35DE] C D E F G H I J K L M A EM Revision: 2005 July 2005 FX CYLINDER BLOCK Unit: mm (in) Surface flatness Standard Less than 0.03 (0.001
