TROUBLE DIAGNOSIS AT-103
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
Diagnostic Procedure without CONSULT-IIACS008CZ
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-144, "Generic Scan Tool (GST) Function" (for VQ35DE) or EC-835, "Generic Scan Tool (GST)
Function" (for VK45DE).
OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Refer to EC-69, "Malfunction Indicator Lamp (MIL)" (for VQ35DE) or EC-760, "Malfunction Indicator Lamp
(MIL)" (for VK45DE).
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Description
In the unlikely event of a malfunction in the electrical system, when the ignition switch is switched “ON”, the A/
T CHECK indicator lamp lights up for 2 seconds, then flashes for 8 seconds. If there is no malfunction, when
the ignition switch is turned “ON”, the indicator lamp lights up for 2 seconds. As a method for locating the sus-
pect circuit, when the self-diagnostics start signal is input, the memory for the malfunction location is output
and the A/T CHECK indicator lamp flashes to display the corresponding DTC.
Diagnostic Procedure
1. CHECK A/T CHECK INDICATOR LAMP
1. Start the engine with selector lever in “P” position. Warm engine to normal operating temperature.
2. Turn ignition switch “ON” and “OFF” at least twice, then leave it in the “OFF” position.
3. Wait 10 seconds.
4. Turn ignition switch “ON”. (Do not start engine.)
Does A/T CHECK indicator lamp come on for about 2 seconds?
YES >> GO TO 2.
NO >> GO TO AT- 1 9 3
.
2. JUDGEMENT PROCEDURE STEP 1
1. Turn ignition switch “OFF”.
2. Push shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Release accelerator pedal. (Set the closed throttle position signal “ON”.)
5. Depress brake pedal. (Stop lamp switch signal “ON”.)
6. Turn ignition switch “ON”. (Do not start engine.)
7. Wait 3 seconds.
>> GO TO 3.
3. JUDGEMENT PROCEDURE STEP 2
1. Move the selector lever to the manual shift gate side. (Manual mode switch “ON”.)
2. Release brake pedal. (Stop lamp switch signal “OFF”.)
3. Move the selector lever to “D” position. (Manual mode switch “OFF”.)
4. Depress brake pedal. (Stop lamp switch signal “ON”.)
5. Release brake pedal. (Stop lamp switch signal “OFF”.)
6. Depress accelerator pedal fully and release it.
>> GO TO 4.

SHIFT CONTROL SYSTEM AT-235
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
INSTALLATION
Note the following, and install in the reverse order of removal.

After installation is completed, adjust and check A/T position. Refer to AT- 2 3 5 , "Adjustment of A/T Posi-
tion" and AT- 2 3 5 , "Checking of A/T Position" .
Adjustment of A/T PositionACS002RR
1. Loosen nut of control rod.
2. Place PNP switch and selector lever in “P” position.
3. While pressing lower lever toward rear of vehicle (in “P” position direction), tighten nut to specified torque.
CAUTION:
Do not push the bracket.
Checking of A/T PositionACS002RS
1. Place selector lever in “P” position, and turn ignition switch ON (Do not start engine).
2. Check selector lever can be shifted to other than “P” position when brake pedal is depressed. Also check selector lever can be shifted from “P” position only when brake pedal is depressed.
3. Move the selector lever and check for excessive effort, sticking, noise or rattle.
4. Check the selector lever stops at each position with the feel of engagement when it is moved through all the positions. Check whether or not the actual position the selector lever is in matches the position shown
by the shift position indicator and the transmission body.
5. The method of operating the lever to individual positions cor- rectly should be as shown in the figure.
6. When selector button is pressed in “P”, “R”, or “N” position with- out applying forward/backward force to selector lever, check but-
ton operation for sticking.
7. Check the back-up lamps illuminate only when lever is placed in the “R” position. Check the back-up lamps does not illuminate
when selector lever is pushed against “R” position in the “P” or
“N” position.
8. Check the engine can only be started with the selector lever in the “P” and “N” positions.
9. Check transmission is locked completely in “P” position.
10. When selector lever is set to manual shift gate, check manual mode is displayed on combination meter. Shift selector lever to “+” and “-” sides, and check set shift position changes. : 26 N·m (2.7 kg-m, 19 ft-lb)
SCIA2119E
SCIA7465E

AV-2Revision: 2005 July 2005 FX
Window Antenna Repair ......................................
... 54
CHECK ELEMENT ........................................... ... 54
Removal and Installation of Roof Antenna .......... ... 56
REMOVAL ........................................................ ... 56
INSTALLATION ................................................. ... 56
INTEGRATED DISPLAY SYSTEM ......................... ... 57
System Description .............................................. ... 57
A/C AND AV SWITCH SYSTEM ....................... ... 57
PRECAUTION OF LCD MONITOR .................. ... 57
POWER SUPPLY AND GROUND .................... ... 57
DRIVE COMPUTER ......................................... ... 58
E/M SWITCH .................................................... ... 59
SETTING SCREEN .......................................... ... 60
WARNING INDICATIONS ................................ ... 61
AV COMMUNICATION LINE ............................ ... 61
CAN Communication System Description ........... ... 61
CAN Communication Unit .................................... ... 61
Component Parts and Harness Connector Location ... 61
Schematic ............................................................ ... 62
Wiring Diagram — INF/D — ................................ ... 63
Schematic ............................................................ ... 68
Wiring Diagram — COMM — .............................. ... 69
Terminals and Reference Value for Display Unit . ... 72
Terminals and Reference Value for A/C and AV
Switch .................................................................. ... 73
On Board Self-Diagnosis Function ...................... ... 74
DESCRIPTION ................................................. ... 74
DIAGNOSIS ITEM ............................................ ... 74
Self-Diagnosis Mode ........................................... ... 74
OPERATION PROCEDURES .......................... ... 74
NETWORK CHECK .......................................... ... 75
PARTS CHECK ................................................ ... 75
HVAC DETAIL SCREEN ................................... ... 76
VERSION CHECK ............................................ ... 76
CAN DIAG MNTR (CAN DIAG MONITOR) ...... ... 76
A/C and AV Switch Self-Diagnosis Function ........ ... 77
STARTING THE SELF-DIAGNOSIS MODE ..... ... 77
EXITING THE SELF-DIAGNOSIS MODE ........ ... 77
DIAGNOSIS FUNCTION .................................. ... 77
Trouble Diagnosis Chart by Symptom ................. ... 78
Power Supply and Ground Circuit Check for Display
Unit ...................................................................... ... 79
Power Supply and Ground Circuit Check for A/C and
AV Switch ............................................................. ... 80
Vehicle Speed Signal Inspection ......................... ... 80
Illumination Signal Inspection .............................. ... 81
Ignition Signal Inspection ..................................... ... 82
Audio Communication Line Inspection ................ ... 82
AV Communication Line Inspection ..................... ... 84
CAN Communication Line Inspection .................. ... 85
Audio Steering Wheel Switch Inspection ............. ... 86
Removal and Installation of Display ..................... ... 86
REMOVAL ........................................................ ... 86
INSTALLATION ................................................. ... 86
Removal and Installation of A/C and AV Switch .. ... 86
NAVIGATION SYSTEM .......................................... ... 87
System Description .............................................. ... 87
TRAVEL DISTANCE ......................................... ... 87
TRAVEL DIRECTION ....................................... ... 87 MAP-MATCHING ..............................................
... 87
GPS (GLOBAL POSITIONING SYSTEM) ........ ... 88
COMPONENT DESCRIPTION ......................... ... 89
BIRDVIEW™ ..................................................... ... 89
MAP DISPLAY .................................................. ... 90
FUNCTION OF CENTER SWITCH .................. ... 91
“VIEW” MODE ................................................... ... 97
“HEADING” MODE ........................................... ... 98
“NEARBY DISPLAY ICONS” MODE ................. ... 98
“SAVE CURRENT LOCATION” MODE ............. ... 98
“ADJUST CURRENT LOCATION” MODE ........ ... 98
“AUTO RE-ROUTE” MODE .............................. ... 99
“AVOID AREA SETTING” MODE ..................... ... 99
“CLEAR MEMORY” MODE ............................... ... 99
“EDIT ADDRESS BOOK” MODE ...................... .100
“GPS INFORMATION” MODE .......................... .100
“QUICK STOP CUSTOMER SETTING” MODE .100
“SET AVERAGE SPEED” MODE ..................... .100
“TRACKING” MODE ......................................... .101
GUIDANCE VOLUME ....................................... .101
DISPLAY WITH PUSHED “TRIP” BUTTON ...... .101
TRIP 1 OR TRIP 2 ............................................ .102
FUEL ECONOMY ............................................. .102
MAINTENANCE ................................................ .102
ENGINE OIL OR TIRE ROTATION ................... .102
TIRE PRESSURE ............................................. .103
WARNING INDICATIONS ................................. .103
CAN Communication System Description ........... .104
CAN Communication Unit .................................... .104
Component Parts Location and Harness Connector
Location ............................................................... .104
Schematic—NAVI— ............................................. .105
Wiring Diagram —NAVI— .................................... .106
Schematic — COMM — ....................................... .113
Wiring Diagram — COMM — ............................... .114
Terminals and Reference Value for NAVI Control
Unit ....................................................................... .119
Terminals and Reference Value for Display Control
Unit ....................................................................... .121
Terminals and Reference Value for Display ......... .125
Terminals and Reference Value for A/C and AV
Switch .................................................................. .127
On Board Self-Diagnosis Function ....................... .128
DESCRIPTION ................................................. .128
DIAGNOSIS ITEM ............................................ .128
Self-Diagnosis Mode (DCU) ................................. .129
OPERATION PROCEDURE ............................. .129
SELF–DIAGNOSIS RESULT ............................ .130
Self-Diagnosis Mode (NAVI) ................................ .131
OPERATION PROCEDURE ............................. .131
SELF–DIAGNOSIS RESULT ............................ .132
Confirmation/Adjustment Mode ............................ .133
OPERATION PROCEDURE ............................. .133
DISPLAY DIAGNOSIS ...................................... .134
VEHICLE SIGNALS .......................................... .134
AUTO CLIMATE CONTROL ............................. .135
NAVIGATION .................................................... .135
DISPLAY DIAGNOSIS ...................................... .135
VEHICLE SIGNALS .......................................... .136

AV-46
AUDIO
Revision: 2005 July 2005 FX
3. CHECK VEHICLE SPEED SIGNAL
1. Connect unified meter and A/C amp. connector.
2. Start engine and drive vehicle at more than 40 km/h (25MPH).
3. Check the signal between audio unit harness connector M60 terminal 22 (W/L) and ground with CON- SULT-ll or oscilloscope.
OK or NG
OK >> INSPECTION END (System is OK.)
NG >> Replace unified meter and A/C amp.
Locking CD Auto-Changer MechanismAKS007GD
CAUTION:

Prior to removing a malfunctioning CD auto-changer unit that will be shipped for repair, the
changer mechanism MUST BE LOCKED to prevent the mechanism from being damaged during
shipping.

If a CD is jammed or unable to be removed from the unit, do NOT lock the changer mechanism. If
the unit is to be shipped for repair, carefully package the unit to prevent vibration and shock.
DAMPER LOCK PROCEDURE
1. Eject and remove any CDs from the audio unit.
2. Turn ignition switch OFF. Wait until audio unit display is off and mechanism stops moving (mechanism sound stops).
3. Press any one of the disc selection buttons once. When a display shows on the audio unit, press the same disc selection button again within 5 seconds.

The changer mechanism will lock itself within 10 seconds.
4. After mechanism stops moving (mechanism sound stops), open the driver and passenger window, and then disconnect negative battery cable.
NOTE:
After installing a new or remanufactured audio unit, switching the audio unit ON will automatically unlock the
mechanism. A special unlocking procedure is not required.
Terminal Condition Reference
signal
(+) (–)
22
(W/L) Ground When vehicle
speed is approx.40
km/h (25MPH)
SKIA6809EELF1080D

NAVIGATION SYSTEM AV-97
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
Navigation Settings
How To Perform Navigation Settings
1. Start the engine.
2. Push “SETTING” button.
3. Select “Navigation”.
Application Items
“VIEW” MODE

To open the map screen display with Birdview™, select “Bird-
view™”.

To open the map screen display with Plan View, select “Plan
View”.
SKIA0551E
Icon Description Reference
page
View Map display mode can be switched. AV- 9 7
Heading Heading of the map display can be customized for either north heading or the actual
driving direction of the vehicle. AV- 9 8
Nearby Display Icons
Icons of facilities can be displayed.
Facilities to be displayed can be selected from the variety selections. AV- 9 8
Save Current Location Current vehicle location can be registered in Address Book.
AV- 9 8
Adjust Current Location Current location of position marker can be adjusted. Direction of position marker
also can be calibrated when heading direction of the vehicle on the display is not
matched with the actual direction. AV- 9 8
Auto Re-route On/Off ON/OFF of Auto Re-route can be switched.
AV- 9 9
Avoid Area Setting A particular area can be avoided when routing.AV- 9 9
Clear Memory Address Book, Previous destination or Avoid area can be deleted.AV- 9 9
Edit Address Book Address Book can be edited.AV- 1 0 0
GPS Information The GPS data includes longitude, latitude and altitude (distance above sea level) of
the present vehicle position, and current date and time for the area in which the
vehicle is being driven.
Also indicated are the GPS reception conditions and the GPS satellite position. AV- 1 0 0
Quick Stop Customer Setting One facility of your selection can be added to your quick stop.
AV- 1 0 0
Set Average Speed for Estimated
Journey Time Average vehicle speed can be set to calibrate estimated journey time for the desti-
nation. AV- 1 0 0
Tracking On/Off Tracking to the present vehicle position can be displayed.
AV- 1 0 1
SKIA0554E

BL-122
INTELLIGENT KEY SYSTEM
Revision: 2005 July 2005 FX
List of Operation Related PartsAIS004N8
Parts marked with × are the parts related to operation.
Will not operate if there is a malfunction in
the area where there is a ×.
Intelligent Key
Key switch
Ignition knob switch ACC switch
Ignition switch
Door unlock sensor
Door switch
Door request switch
Inside key antenna
Out side key antenna
Intelligent Key warning buzzer Intelligent Key unit
CAN communication system
BCM
Combination meter
Steering lock unitStop lamp switch Detention switch
Passenger side select unlock relay
Door lock/unlock operation using Intelligent
Key remote controller button operation ×××××××
Door lock/unlock operation using door
request switch operation ×××××××××
Selective door unlock function using door
request switch operation ××××××× ×
Selective door unlock function using Intelli-
gent Key remote controller button opera-
tion ××× ×××
Door lock/unlock operation using mechani-
cal key ×
Ignition knob rotation permission using
Intelligent Key ××× × × × × ×
Ignition knob rotation permission using
mechanical key ×× × × ×× ×
Engine start using Intelligent Key ×× ×××××××
Engine start using mechanical key ×× × × × × ×
Key reminder door lock operation ××××××××
Selector lever reminder operation ×× ××× ×
Ignition switch return forgotten warning ××× × × × ×
Ignition key warning (when using mechani-
cal key) ××××
Ignition switch OFF position warning (for
inside car: when door closed) ×××× × × ×
Ignition switch OFF position warning (for
outside car: when door opened/closed) ×××× × ×× × ××
Warning for removal of Intelligent Key to
outside the car (when door open/closed) ××× × × ×× × × ×
Warning for removal of Intelligent Key to
outside the car (from window) ××× × × × × ×
Door lock non-operation warning ×××××××××
Intelligent key low battery warning ×× ×××

DI-38
COMPASS
Revision: 2005 July 2005 FX
COMPASSPFP:24835
System DescriptionAKS007AO
This unit displays earth magnetism and heading direction of vehicle.
DIRECTION DISPLAY
Push the switch when the ignition key is in the “ON” or “START” position. The direction will be displayed.
Pushing the “COMP” switch a second time will turn off the display.
1. If the display reads “C” calibrate the compass by driving the vehicle in 3 complete circles at less than 8 km/h (5 MPH).
2. To adjust for compass variance:
a. Press the “COMP” switch for more than 3 seconds. The current zone number will appear in the display.
b. Find your current location and variance zone number on the zone map.
c. Press the “COMP” switch until the new zone number appears in the display. After you stop pressing the button in, the display will show a compass direction within a few seconds.
NOTE:
1. Do not install the ski rack, antenna, etc. which are attached to the vehicle by means of a magnet. They affect the operation of the compass.
2. If the compass deviates from the correct indication soon after repeated adjustment, have the compass checked at an authorized dealer.
3. The compass may not indicate the correct compass point in tunnels or while driving up or down a steep hill. (The compass returns to the correct compass point when the vehicle moves to an area where the
geomagnetism is stabilized.)
3. Cleaning the Mirror When cleaning the mirror, use a paper towel or similar material dampened with glass cleaner. Do not
spray glass cleaner directly on the mirror as that may cause the liquid cleaner to enter the mirror housing.
“C” is displayed in the compass window.
SKIA5335E

SC-6
BATTERY
Revision: 2005 July 2005 FX
CHARGING THE BATTERY
CAUTION:

Never “quick charge” a fully discharged battery.

Keep the battery away from open flame while it is being charged.

When connecting the charger, connect the leads first, then turn on the charger. Never turn on the
charger first, as this may cause a spark.

If battery electrolyte temperature rises above 55 °C (131 °F), stop charging. Always charge battery
at a temperature below 55 °C (131 °F).
Charging Rates
Never charge at more than 50 ampere rate.
NOTE:
The ammeter reading on your battery charger will automatically decrease as the battery charges. This indi-
cates that the voltage of the battery is increasing normally as the state of charge improves. The charging amps
indicated above refer to initial charge rate.

If, after charging, the specific gravity of any two cells varies more than 0.050, the battery should be
replaced.
Trouble Diagnosis with Battery/Starting/Charging System Tester (Battery)AKS0079A
CAUTION:
When working with batteries, always wear appropriate eye protection.
NOTE:

To ensure a complete and thorough diagnosis, the battery, starter and alternator test segments must be
done as a set from start to finish.

If battery surface charge is detected while testing, the tester will prompt you to turn on the headlamps to
remove the surface charge.

If necessary, the tester will prompt you to determine if the battery temperature is above or below 0 °C (32
° F). Choose the appropriate selection by pressing the up or down arrow button, then press “ENTER” to
make the selection.
16 (60) −0.008
10 (50) −0.012
4 (40) −0.016
− 1 (30) −0.020
− 7 (20) −0.024
− 12 (10) −0.028
− 18 (0) −0.032
Corrected specific gravity Approximate charge condition 1.260 - 1.280 Fully charged
1.230 - 1.250 3/4 charged
1.200 - 1.220 1/2 charged
1.170 - 1.190 1/4 charged
1.140 - 1.160 Almost discharged 1.110 - 1.130 Completely discharged
Battery electrolyte temperature
°C ( °F) Add to specific gravity reading
Amp Time
50 1 hour
25 2 hours
10 5 hours 5 10 hours
