Page 617 of 4770

TOYOTA CAMRY 2000 Service Repair Manual ABS Antilock Brake System
A/C Air Conditioner
assy assembly
ECT Electronic Controlled Transmission
ECU Electronic Control Unit
e.g. Exempli Gratia (for Example)
Ex. Except
FWD Front Wheel Drive V

Page 618 of 4770

TOYOTA CAMRY 2000 Service Repair Manual CodeMaterial
nameHeat*
resistant
temperature
limit °C (°F)Resistance to
alcohol or gasolineNotes
AASAcrylonitrile
Acrylic Styrene80
(176)Alcohol is harmless if applied
only for short time in sma

CodeMaterial
nameHeat*
resistant
temperature
limit °C (°F)Resistance to
alcohol or gasolineNotes
AASAcrylonitrile
Acrylic Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
ABSAcrylonitrile
Butadiene Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease).Avoid gasoline and
organic or aromatic
solvents.
AESAcrylonitrile
Ethylene Styrene80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
ASAAcrylonitrile
Styrene
Acrylate80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
CABCellulose
Acetate80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic or aromatic
solvents.
EPDMEthylene
Propylene100
(212)Alcohol is harmless.
Gasoline is harmless if applied
only for short time in small
amounts.Most solvents are
harmless but avoid
dipping in gasoline,
solvents, etc.
FRPFiber
Reinforced
Plastics180
(356)Alcohol and gasoline are
harmless.Avoid alkali.
EVAEthylene
Acetate70
(158)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid gasoline and
organic oraromatic
solvents.
PAPolyamide
(Nylon)80
(176)Alcohol and gasoline are
harmless.Avoid battery acid.
PBTPolybutylene
Terephthalate160
(320)Alcohol anal gasoline are
harmless.Most solvents are
harmless.
PC Polycarbonate120
(248)Alcohol is harmless.Avoid gasoline brake
fluid, wax, wax removers
and organic solvents.
Avoid alkali.
HANDLING PRECAUTIONS
1. The repair procedure for plastic body parts must conform with the type of plastic material.
2. Plastic body parts are identified by the codes in the following chart.
3. When repairing metal body parts adjoining plastic body parts (by brazing, frame cutting, welding,
painting etc.), consideration must given to the property of the plastic.
*Temperatures higher than those listed here may result in material deformation during repair.
PLASTIC BODY PARTSPP-2

Page 619 of 4770

TOYOTA CAMRY 2000 Service Repair Manual CodeMaterial
nameHeat*
resistant
temperature
limit °C (°F)Resistance to
alcohol or gasolineNotes
PE
Polyethylene80
(176)Alcohol and gasoline are harmless.Most solvents are
harmless.
PETPolyethyl

CodeMaterial
nameHeat*
resistant
temperature
limit °C (°F)Resistance to
alcohol or gasolineNotes
PE
Polyethylene80
(176)Alcohol and gasoline are harmless.Most solvents are
harmless.
PETPolyethylene
Terephthalate75
(167)Alcohol and gasoline are
harmless.Avoid dipping in water.
PMMAPolymethyl
Methacrylate80
(176)Alcohol is harmless if applied
only for short time in small
amounts.Avoid dipping or
immersing in alcohol,
gasoline, solvents, etc.
POMPolyoxymethylene
(PolyacetaI)100
(212)Alcohol and gasoline are
harmless.Most solvents are
harmless,
PP
Polypropylene80
(176)Alcohol and gasoline are
harmless.Most solvents are
harmless.
PPOModified
Polyphenylene
Oxide100
(212)Alcohol is harmless.Gasoline is harmless if
applied only for quick
wiping to remove
grease.
PS
Polystyrene60
(140)Alcohol and gasoline are
harmless if applied only for
short time in small amounts.Avoid dipping or
immersing in alcohol,
gasoline, solvents, etc.
PUR
Polyurethane80
(176)Alcohol is harmless if applied
only for very short time in small
amounts (e.g., quick wiping to
remove grease).Avoid dipping or
immersing in alcohol,
gasoline, solvents, etc.
PVCPolyvinylchloride
(Vinyl)80
(176)Alcohol and gasoline are harmless
if applied only for short time in small
amounts (e.g., quick wiping to re-
move grease).Avoid dipping or
immersing in alcohol,
gasoline, solvents, etc.
SANStyrene
Acrylonitrile80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease).Avoid dipping or
immersing in alcohol,
gasoline, solvents etc.
TPOThermoplastic
Olefine80
(176)Alcohol is harmless.
Gasoline is harmless if applied
only for short time in small
amounts.Most solvents are
harmless but avoid
dipping in gasoline,
solvents, etc.
TPUThermoplastic
Polyurethane80
(176)Alcohol is harmless if applied
only for short time in small
amounts (e.g., quick wiping to
remove grease.)Avoid dipping or
immersing in alcohol,
gasoline, solvents, etc.
TSOPTOYOTA
Super
Olefine Polymer80
(176)Alcohol and gasoline are
harmless.Most solvents are
harmless.
UPUnsaturated
Polyester11 0
(233)Alcohol and gasoline are
harmless.Avoid alkali.
*Temperatures higher than those listed here may result in material deformation during repair
PLASTIC BODY PARTSPP-3

Page 620 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Parts NameCode
Front Bumper CoverTSOP
Radiator Grille (Models Except USA & CANADA)ABS
Headlight (For USA & CANADA)PC/PP
Front Turn Signal LightPMMA/ASA
Front Fog Light (Models Except USA & CANADA)PC/P

Page 621 of 4770

TOYOTA CAMRY 2000 Service Repair Manual High Strength Sheet Steel
HIGH±STRENGTH STEEL (HSS) PARTS
Generally, High±Strength Steel (HSS) is that which has an intensity value of at 35 kgf/mm2
(343 MPa), and
distinguished from mild steel.
Th

Page 622 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RUST±RESISTANT SHEET STEEL PARTS
Rust±Resistant Sheet have zinc, tin or aluminum etc, plating over the base metal surface in order to improve
the corrosion resistance of the sheet metal. For the veh

Page 623 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Zinc±iron Alloy Double Layer
Galvannealed Sheet Steel Galvannealed Sheet Steel
BODY PANEL CONSTRUCTIONCN-4

Page 624 of 4770

TOYOTA CAMRY 2000 Service Repair Manual RADIATOR UPPER SUPPORT (ASSY)
REMOVAL
BODY PANEL REPLACEMENTRE-2
