Unlock all doors manually
Insert key in ignition key cylinder and open driver's doorHINT: Diagnostic mode may be exited
at any time by ungrounding terminal 9
Ground terminal 9 of the wireless door lock ECU and
wait more 1 second.
Remove key from ignition key cylinder and close
driver 's door within 10 seconds.
Press any button on transmitter within 10 seconds.If not performing this operation
within 10 seconds after the
above operation, the mode will
not change into the diagnostic
mode.
If not performing this operation
within 10 seconds after the
above operation, the mode will
not change into the diagnostic
mode.
CONTINUED ON NEXT PAGE
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI±805
1040 Author: Date:
(2) A transmitter recognition code is registered by
pressing any single button of the transmitter to be
registered. Once the code is registered, the ECU
responds again by operating once the lock and un-
lock functions of all the doors.
(3) To register the recognition code of an additional
transmitter, follow the procedure shown in (2).
(4) After completing the registration of the codes, re-
move the test lead from the remote control mirror
switch connector terminals to allow the system to
revert to the normal operation.
(5) Using the registered transmitter, verify that the sys-
tem operates properly.
4. DIAGNOSTIC PROCEDURE
Page 3226 of 4770
Does each
door lock
knob oper-
ate?No
Ye sRF (ECU failure) DATA reception
error (Transmitter of ECU failure)
Exit diagnostic mode, and check
transmitter batteries.
If bad, replace batteries and go to
start.
If not starting, replace transmitter and
go to
start.
Door lock motor of all the doors
operate to lock side 1 time. Door lock motor of all the doors
operate to lock side 3 times.
Valid recognition code received
Motor feedback failure
Diagnostic check OK
Check motor feedback for input
line to receiver:
If bad, fix wiring or replace motor.
Other wise, replace receiver and go to start.How does
it opetate?
If still not starting, replace ECU and
go to start.
DI±806
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1041 Author: Date:
Page 3227 of 4770
DI05O±03
I00217
I00216
I00215
I00241
Ignition Switch
Key Unlock Warning Switch
Wireless Door Lock ECU
Transmitter
Instrument Panel Junction Block
Integration Relay
Engine Room Junction Block
Door Lock Motor
Door Unlock Detection
Switch
Door Courtesy Switch DOME FuseDoor Key Lock and Unlock Switch
Door Lock Motor
Door Unlock
Detection SwitchDoor Lock Motor
Door Unlock
Detection Switch
Door Courtesy Switch
Door Courtesy Switch
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI±807
1042 Author: Date:
PARTS LOCATION
Page 3228 of 4770

DI1KR±03
I00227
1 2
63 74
8 5
9 10 11 12 13 14 15
DI±808
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1043 Author: Date:
TERMINALS OF ECU
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
1 ± Ground (GND ± Ground )W ± BAlways.Below 1 V
4 G d(TAIL G d)GRTAIL lamps ºONºBelow 1 V4 ± Ground ( TAIL ± Ground )G ± RTAIL lamps ºOFFº10 ± 14 V
5 G d ( PINI G d )LGAlways.4 ± 6 V5 ± Ground ( PINI ± Ground )LGPush the PANIC switch.Below 1.5 V
7 G d(UL3 G d)RG
Door key lock and unlock switch ºUNLOCKº.
(Driver's Door)Below 1.5 V
7 ± Ground ( UL3 ± Ground )R ± GDoor key lock and unlock switch ºOFFº or ºLOCKº.
(Driver's Door)8 ± 10 V
8 ± 1 (+B ± E )RAlways.10 ± 14 V
9 ± Ground (PRG ± Ground )VIgnition switch ºONº10 ± 14 V
10 ± Ground (KSW ± Ground )L ± B
Key unlock warning switch ºONº.
(Key is inserted into key cylinder)Below 1 V10 Ground (KSW Ground )L B
Key unlock warning switch ºOFFº.10 ± 14 V
11 G d (LSWD G d)LR
Door unlock detection switch ºONº.
(Driver's Door)Below 1 V
11 ± Ground (LSWD ± Ground)L ± RDoor unlock detection switch ºOFFº.
(Driver's Door)10 ± 14 V
12 G d (LSWP G d)Y
Door unlock detection switch ºONº.
(Passenger's Door)Below 1 V
12 ± Ground (LSWP ± Ground)YDoor unlock detection switch ºOFFº.
(Passenger's Door)10 ± 14 V
13 G d(LSWR G d)LY
Door unlock detection switch ºONº.
(Either Rear Door)Below 1 V
13 ± Ground(LSWR ± Ground)L ± YDoor unlock detection switch ºOFFº.
(All Rear Doors)10 ± 14 V
14 G d (CTY G d )RWDoor courtesy switch ºONºBelow 1 V14 ± Ground (CTY ± Ground )R ± WDoor courtesy switch ºOFFº10 ± 14 V
15 G d (L G d )LWDoor key lock and unlock switch ºLOCKºBelow 1 V15 ± Ground (L ± Ground )L ± WDoor key lock and unlock switch ºOFFº or ºUNLOCKº8 ± 10 V
Page 3229 of 4770

DI05Q±03
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI±809
1044 Author: Date:
PROBLEM SYMPTOMS TABLE
Perform troubleshooting of the circuit for the applicable problem symptom in the order given in the chart be-
low. Proceed to the page located for each circuit.
HINT:
Troubleshooting of the wireless door lock control system is based on the premise that the door lock
control system and theft deterrent system are operating normally. Accordingly, before troubleshooting
the wireless door lock control system, first make certain that the door lock control system and theft de-
terrent system are operating normally.
If the instruction ºProceed to next circuit inspection shown on matrix chartº is given in the flow chart
for each circuit, proceed to the circuit with the next highest number in the table to continue the check.
If the trouble still reappears even through there are no abnormalities in any of the other circuits, check
and replace the Wireless Door Lock ECU as the last step.
SymptomSuspect AreaSee page
All functions of wireless door lock control system do no operate.
3. ECU Power Source Circuit.
4. Door Courtesy Switch Circuit.
5. Door Key Lock and Unlock Switch Circuit.
(Unlock Side)
6. Door Key Lock and Unlock Switch Circuit.
(Lock Side)
7. Key Unlock Warning Switch Circuit.
8. Wireless Door Lock ECU.DI±810
DI±821
DI±815
DI±817
DI±819
IN±31
Only door unlock operation is not possible (Lock operation is pos-
sible).
1. Door Key Lock and Unlock Switch Circuit
(Unlock Side)
2. Door Unlock Detection Switch Circuit
3. Wireless Door Lock ECU.DI±815
DI±819
IN±31
Only door lock operation is not possible (Unlock operation is pos-
sible).1. Door Key Lock and Unlock Switch Circuit
(Lock Side)
2. Wireless Door Lock ECUDI±817
IN±31
Only key confinement prevention function is not possible.1. Key Unlock Warning Switch Circuit
2. Wireless Door Lock ECUDI±819
IN±31
Wireless door lock function operates even when each door is
opened.
Automatic lock function operates even if any door is opened
within 30 seconds after all doors are unlocked by wireless door
lock control system.
1. Door Courtesy Switch Circuit
2. Wireless Door Lock ECUDI±821
IN±31
Wireless door lock functions incorrectly.
(Although one door is unlocked, when the transmitter switch is
pressed, all doors are unlocked.)1. Door Unlock Detection Switch Circuit
2. Wireless Door Lock ECUDI±813
IN±31
Warning operation will not be performed even if the panic button is
pressed.1. Panic Circuit
2. Wireless Door Lock ECUDI±823
IN±31
Page 3230 of 4770
DI05R±03
I00225
Wireless Door Lock ECU
SHORT PIN
2A2J
DOME Engine Room J/B No.2
FL BLOCK
BatteryRR± J16J17
W±BJ5
A
GND B±G1
B12
FL MAIN
A
IF R
RED 1
1
1 1
8
12 R±YDIODE(DOME) 1W
1G
R8 Instrument
panel J/B F6
F4
J/C
W±B DI±810
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1045 Author: Date:
CIRCUIT INSPECTION
ECU Power Source Circuit
CIRCUIT DESCRIPTION
Battery positive voltage is always applied to the terminal +B of the wireless door lock ECU.
WIRING DIAGRAM
Page 3231 of 4770
N14677
AB0117
N14690
I00242
LOCK
E(±)
+B(+)
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI±811
1046 Author: Date:
INSPECTION PROCEDURE
1 Check DOME fuse.
PREPARATION:
Remove DOME fuse from engine room junction block.
CHECK:
Check continuity of DOME fuse.
OK:
Below 1.0 W or continuity
NG Check for short in all the harness and compo-
nents connected to DOME fuse.
(See attached wiring diagram.)
OK
2 Check voltage between terminals +B and E of wireless door lock ECU connector.
PREPARATION:
Remove the wireless door lock ECU from No.1 instrument pan-
el brace.
CHECK:
Measure voltage between terminals +B and GND of wireless
door lock ECU.
OK:
Voltage: 10 ± 14 V
OK Proceed to next circuit inspection shown on
problem symptoms table (See page DI±809).
NG
Page 3232 of 4770
DI±812
± DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1047 Author: Date:
3 Check for open in harness and connector between terminal GND of wireless
door lock ECU and body ground (See page IN±31).
NG Repair or replace harness or connector.
OK
Check and repair harness and connector between wireless door lock control ECU and battery.
