TOYOTA CAMRY 2000 Service Repair Manual I GROUND POINT
BUCKLE SW LH
POWER SEAT CONTROL
SW
(
DRI VER S SE AT)
FUEL PUMP
HIGH MOUNTED
STOP LIGHT
REAR COMBINATION
LIGHT LH
REAR COMBINATION
LIGHT RHBUCKLE SW LH
LICENSE PLATE
LIGHT RH
LICENSE

Page 1458 of 4770

TOYOTA CAMRY 2000 Service Repair Manual : PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
J531J1931J3832
J7A31J2231J3932
J8B31J2331J4032
J1131J2631
: RELAY BLOCKS
CodeSee PageRelay Blocks (Relay Block Location)
124Engine Room R/B No.1 (

: PARTS LOCATION
CodeSee PageCodeSee PageCodeSee Page
J531J1931J3832
J7A31J2231J3932
J8B31J2331J4032
J1131J2631
: RELAY BLOCKS
CodeSee PageRelay Blocks (Relay Block Location)
124Engine Room R/B No.1 (Engine Comportment Left)
224Engine Room R/B No.2 (Near The Battery)
325Engine Room R/B No.3 (Radiator Upper Support RH)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CodeSee PageJunction Block and Wire Harness (Connector Location)
1F20Roof Wire and Instrument Panel J/B (Lower Finish Panel)
1G20Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1J
1M20Cowl Wire and Instrument Panel J/B (Lower Finish Panel)1N20Cowl Wire and Instrument Panel J/B (Lower Finish Panel)
1V
2C22Engine Room Main Wire and Engine Room J/B No 2 (Engine Compartment Left)2F22Engine Room Main Wire and Engine Room J/B No.2 (Engine Compartment Left)
2J22Cowl Wire and Engine Room J/B No 2 (Engine Compartment Left)2K22Cowl Wire and Engine Room J/B No.2 (Engine Compartment Left)
: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CodeSee PageJoining Wire Harness and Wire Harness (Connector Location)
EA136 (1MZ±FE)Engine Room Main Wire and Engine Room Main No 3 Wire (Radiator LH)EA138 (5S±FE)Engine Room Main Wire and Engine Room Main No.3 Wire (Radiator LH)
IE140Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IF240Floor Wire and Instrument Panel Wire (Left Kick Panel)
IH140Instrument Panel Wire and Instrument Panel No.2 Wire (Instrument Panel Brace RH)
II1
II242Engine Wire and Cowl Wire (Under the Blower Motor)
II3
g()
IJ142Engine Wire and Instrument Panel Wire (Under the Blower Motor)
IK242Engine Room Main Wire and Cowl Wire (Right Kick Panel)
IM142Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
BO144Rear Door Wire LH and Floor Wire (Under the Left Center Pillar)
BP144Rear Door Wire RH and Floor No.2 Wire (Under the Right Center Pillar)
BQ146Floor Wire and Seat No.1 Wire (Under the Driver's Seat)
BR146Floor No.2 Wire and Seat No.2 Wire (Under the Passenger's Seat)

Page 1459 of 4770

TOYOTA CAMRY 2000 Service Repair Manual I GROUND POINT
: GROUND POINTS
CodeSee PageGround Points Location
EA36 (1MZ±FE)Right Radiator Side SupportEA38 (5S±FE)Right Radiator Side Support
EB36 (1MZ±FE)Left Radiator Side SupportEB38 (5S±F

Page 1460 of 4770

TOYOTA CAMRY 2000 Service Repair Manual A A A
AAAX X A A A
AAAXXXXAA
AAAA
J38 J39 J40
(Hint : See Page 7)
(Hint : See Page 7) (Hint : See Page 7)

Page 1461 of 4770

TOYOTA CAMRY 2000 Service Repair Manual J OVERALL ELECTRICAL WIRING DIAGRAM

Page 1462 of 4770

TOYOTA CAMRY 2000 Service Repair Manual J
[A]: System Title
[B]: Indicates the wiring color.
Wire colors are indicated by an alphabetical code.
B = Black W = White BR = Brown
L = Blue V = Violet SB = Sky Blue
R = Red O = Orange LG = Light G

Page 1463 of 4770

TOYOTA CAMRY 2000 Service Repair Manual SYSTEM INDEX
J OVERALL ELECTRICAL WIRING DIAGRAM
SYSTEMS LOCATION SYSTEMS LOCATION
ABS
TMC Made 19±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TMMK Ma

SYSTEM INDEX
J OVERALL ELECTRICAL WIRING DIAGRAM
SYSTEMS LOCATION SYSTEMS LOCATION
ABS
TMC Made 19±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TMMK Made 20±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ABS and Traction Control 18±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning
Automatic A/C 29±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual A/C 27±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Auto Antenna 24±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back±Up Light 8±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging 1±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter and Clock 16±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Combination Meter 25±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise Control 17±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Control 14±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronically Controlled Transmission and A/T Indicator
1MZ±FE 4±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5S±FE 5±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Control and Engine Immobiliser System
1MZ±FE 2±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5S±FE 3±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight
w/ Daytime Running Light 7±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
w/o Daytime Running Light 6±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 21±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination 10±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Light 9±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Reminder and Seat Belt Warning 21±3. . . . . . . . . . . . . . . . . . . . . . . . Light Auto Turn Off 9±1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon Roof 21±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Outlet 16±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Seat 22±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Source 1~29±1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Window 13±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Fan and Condenser Fan 26±3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio and Player
Built±In Type Amplifier 24±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Separate Type Amplifier 23±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Window Defogger and Mirror Heater 26±2. . . . . . . . . . . . . . . . . . . .
Remote Control Mirror 12±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lock 16±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS 28±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting and Ignition 1±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stop Light 11±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillight 11±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft Deterrent 15±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Hazard Warning Light 8±2. . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper and Washer 12±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless Door Lock Control 14±5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Page 1464 of 4770

TOYOTA CAMRY 2000 Service Repair Manual J
1
234
1 CAMRY ELECTRI CAL WI RI NG DI AGRAM
2ACC
IG1
IG2
ST2 AM1 4
6
8 7AM2
1B 51K 5
2 1
3 5
5A ALT±S30A AM2 40A MAIN
2L 4 2C 3
2A 12B32D52K92J11
1F 2F 1B
1A1K 2
1B 1
40A AM1
1A
1
B
IG
5A
ST ARTER

J
1
234
1 CAMRY ELECTRI CAL WI RI NG DI AGRAM
2ACC
IG1
IG2
ST2 AM1 4
6
8 7AM2
1B 51K 5
2 1
3 5
5A ALT±S30A AM2 40A MAIN
2L 4 2C 3
2A 12B32D52K92J11
1F 2F 1B
1A1K 2
1B 1
40A AM1
1A
1
B
IG
5A
ST ARTER
5A
IGN 1K 41K3
1J 31C8
65
P
N
10 II2
CB
BA BA
B±W
GR (
A/T)
Left kick panel12 I I3
2 1 1C
1A
L
B
A
A B
IG
S 4B 13 A1K 1
1J 2
4IG2
6 EB14IK2 1T 8
4567 32 2 2 AAAAA
C 423 324 BB B
9 10 1 21 1
A
1 1 1 R B±R B±Y W W B±G
B±O(
*5) B
B± R
B± R
B± RB±R B± R
G
Y
LW±RLG±B
BR±YGRBR BR
W± RW± R
W
WB±RB±R
B±RB
B±GB± G B± R W± B GR(
*4)
B± O(
*5) B±WYY Y Y
BR(
*2)
Y±R(
*2)
W± R
W± R
B(
*2)
BR(
*2)
B±R B±R
B±R B±RB±R B±Y R±L R±LB±GW
B±G
W
B±R B±R
(
M/T) (
*1)(
*1)
I16
IGNITION SW
I 7
IGNITION COIL NO. 3 I 6
IGNITION COIL NO. 2 I 5
IGNITION COIL NO. 1
ST REL AYP 1
PARK/ NEUTRAL
POSITI ON SW
J18
JUNCTI ON CONNECTOR
100A
ALTFUSI BLE LI NK
BL OCK
FL MAIN
3. 0W
BATTERYST ARTER
JUNCTION
CONNECTOR To En gi n e
Co nt r ol
Module< 2±10>
To Engine Contr ol
Module< 2±8>C
C
Y
N 1
NOI SE FI LTER
(
I gnit ion)
J25
JUNCTI ON CONNECTOR
I 3
IGNITION
COI L A ND
IGNITER
NO. 1I 4
IGNITION
COIL AND
IGNITER
NO. 2 * 1 : 1MZ±FE
* 2 : 5S±FE
To Dayt ime Running
Light Relay
(
Main)
< 7±2>
GENERATOR
J 1
JUNCTION
CONNECTOR
CHARGE WARNING
LIGHT[ COMB. METER]
1 2
IGC3 IGC2 IGC1 +B
I GF IGT3 I GT2 I GT1 GND* 3 : w/ Dayt ime Running Light
(
*3)
W± RBR
A AA
BR
BR To Engine Control
Module< 3±11>
J19
JUNCTI ON
CONNE CTOR
I 2
IGNITER ,
A
To Eng i ne
Control Module< 3±11>
10A GAUGE
B±R
BR
(
*1)
(
*1)
(
*2) J11
JUNCTION
CONNECTORGR(
*4)
BA
To Bul b
Ch ec k Rel a y
[Comb. Meter]
< 25±6>2 1
11 II2 B
B B
B±W
(
A/T)
B±WJ29
JUNCTION
CONNECTOR13 II3
B±R
(
*2)
1B±RB
N 1
NOISE FILTER
(
Ignition)(
*3)(
*3)
Y
(
w/o Day time Running Light)
* 4 : TMC Made
* 5 : TMMK Made
GR(
*4)
B± O(
*5) GR(
*4)
B±O(
*5)
B±W
C 7
CLUTCH
ST ART
SW
GR(
*1 *4)
B±O(
*1 *5)
GR(
*2 *4)
B±O(
*2 *5)
GR(
*4)
B±O(
*5)
1
3 2
(
M/ T)
Rear side of the s urge
tank(
*1)
Intake manifold(
*2) ED : * 1
EC : * 2 B±R(
*2)
GN D I GT I GF I GF I GT GN D+B +B
Power Source Starting and Ignition Charging
B±R
(
*2)
W± BTo Engine Cont rol
Module< 2±9> < 3±10>
(
A/T)
, F 5 F 4 A B
, F 9 F 6 C F
, S 2 S 1 B A
B J 7 J 8A, B C 8 C 9A,
A G 1 G 2B,
1 2
CB
(
*1)
(
*1)
(
*1)
(
*1) (
*2)(
*2)
