TOYOTA CAMRY 2000 Service Repair Manual 99camry U
91
(m) Key Reminder Buzzer
This buzzer reminds you to remove the
key when you open the driver s door with
the ignition key in the ºACCº or ºLOCKº
position.
CHECKING SERVICE REMINDER I

Page 858 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
92

Page 859 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
93
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1±6
Ignition switch,
Transmission and
Parking brake
Ignition switch with steering lock
Automatic transmission
Manual transmiss

Page 860 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
94
NOTICE
Do not leave the key in the ºONº
position if the engine is not running.
The battery will discharge and the
ignition could be damaged.

Page 861 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
95
Automatic transmission
Shift while holding the lock
release button in Lock release button
To prevent misshifting
Parking, engine
starting and key
removal postition
Reverse position
Neut

Page 862 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
96
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of ºPº position when the
brake pedal is depre

'99camry U
96
Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of ºPº position when the
brake pedal is depressed (with the ignition
switch in ºONº position and the lock re-
lease button depressed).
(a) Normal driving
1. Start the engine as instructed in ºHow
to start the engineº in Part 3. The
transmission must be in ºPº or ºNº.
2. With your foot holding down the brake
pedal, shift the selector lever to ºDº.
In ºDº position, the automatic transmission
system will select the most suitable gear
for the running conditions such as normal
cruising, hill climbing, hard towing, etc.
Always turn the overdrive switch on for
better fuel economy and quieter driving. If
the engine coolant temperature is low, the
transmission will not shift into overdrive
gear even with the overdrive switch on.
CAUTION
Never put your foot on the accelera-
tor pedal while shifting.
3. Release the parking brake and brake
pedal. Depress the accelerator pedal
slowly for smooth starting.
(b) Using engine braking
To use engine braking, you can downshift
the transmission as follows:
Turn off the overdrive switch. The ºO/D
OFFº indicator light will come on and
the transmission will downshift to the
third gear.
Shift into the º2º position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than the following
speed, and more powerful engine brak-
ing will be obtained.
5S±FE engine 106 km/h (65 mph). . .
1MZ±FE engine 122 km/h (75 mph). .
Shift into the ºLº position. The trans-
mission will downshift to the first gear
When the vehicle speed drops down to
or lower than the following speed, and
maximum engine braking will be ap-
plied.
5S±FE engine 46 km/h (28 mph). . .
1MZ±FE engine 55 km/h (34 mph). . Vehicles with cruise control'When the
cruise control is being used, even if you
downshift the transmission by turning off
the overdrive switch, engine braking is not
applied because the cruise control is not
cancelled.
For ways to decrease the vehicle speed,
see ºCruise controlº in this chapter.
CAUTION
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.
(c) Using º2º and ºLº positions
The º2º and ºLº positions are used for
strong engine braking as described pre-
viously.
With the selector lever in º2º or ºLº, you
can start the vehicle in motion as with the
lever in ºDº.
With the selector lever in º2º, the vehicle
will start in the first gear and automatical-
ly shift to the second gear.
With the selector lever in ºLº, the trans-
mission is engaged in the first gear.

Page 863 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
97
NOTICE
Be careful not to overrev the en-
gine. Watch the tachometer to keep
engine rpm from going into the red
zone. The approximate maximum al-
lowable speed for each position is
given

Page 864 of 4770

TOYOTA CAMRY 2000 Service Repair Manual 99camry U
98
(g) Rocking your vehicle if stuck
CAUTION
If your vehicle becomes stuck in
snow, mud, sand, etc., then you may
attempt to rock your vehicle free by
moving it forward and backward. Do
not
