H01983
Code Shape Size
Code Shape Size
Code Shape Size
A
D
G
J
M
PBC
EF
HI
K
NL
O L = 16 (0.63) ù = 5.2 (0.21)mm (in.)
L = 16 (0.63) ù = 6.0 (0.24)
L = 20 (0.79) ù = 6.0 (0.24)
L = 20 (0.79) ù = 6.0 (0.24)
L = 10 (0.39) ù = 5.0 (0.20)
L = 20 (0.79) ù = 5.2 (0.21)
L = 22 (0.87) ù = 8.0 (0.31)
L = 20 (0.79) ù = 6.0 (0.24)
L = 20 (0.79) ù = 6.0 (0.24)
L = 18 (0.79) ù = 6.0 (0.24)
L = 14 (0.55) ù = 5.0 (0.20)
L = 12 (0.47) ù = 5.0 (0.20)
L = 18 (0.17) ù = 8.0 (0.31)8 x 1.256 x 1.00
6 x 1.00 BO±74
± BODYINSTRUMENT PANEL
2422 Author: Date:
HINT:
Screw shapes and size are indicated in the table below. The code (ºAº±ºPº) correspond to those indicated
on the previous page.
Page 2034 of 4770
BO0MC±01
N20987
N21123
± BODYINSTRUMENT PANEL
BO±75
2423 Author: Date:
REMOVAL
1. REMOVE THESE PARTS:
HINT:
Tape a screwdriver tip before use.
(a) Front door inside scuff plates
(b) Cowl side trims
(c) Front pillar garnishes
(d) Front door opening covers
(e) Lower finish plate
2. REMOVE STEERING WHEEL
(See page SR±11)
3. REMOVE STEERING COLUMN COVERS
(a) Remove the steering tilt handle.
(b) Remove the 3 screws, then the upper and lower column
covers.
4. REMOVE COMBINATION SWITCH
5. REMOVE No.1 LOWER PANEL
(a) Remove the 2 screws and hood lock release lever.
(b) Press on the sides of the coin box while pulling the coin
box outward, and remove the coin box.
(c) Remove the screw, bolt and the No.1 lower panel.
6. REMOVE LOWER PANEL INSERT
(a) Remove the 2 screws holding the DLC3 to the LH lower
panel.
(b) Remove the 4 bolts, and the panel.
7. REMOVE No.2 LOWER COVER
Page 2035 of 4770

N20988
N21023
7 Clips
N21024
6 Clips BO±76
± BODYINSTRUMENT PANEL
2424 Author: Date:
8. REMOVE GLOVE COMPARTMENT ASSEMBLY
(a) Using a screwdriver, remove the glove compartment door
finish plate to the glove compartment box inside.
NOTICE:
When handling the airbag connector, be careful not to dam-
age the airbag wire harness.
HINT:
Tape the screwdriver tip before use.
(b) Pull up and disconnect the airbag connector.
(c) Remove the 4 screws, bolt and glove compartment as-
sembly.
9. REMOVE CENTER CONSOLE UPPER PANEL
Using a screwdriver, remove the panel, then disconnect the
connector.
HINT:
Tape the screwdriver tip before use.
10. REMOVE REAR CONSOLE BOX
Remove the 2 bolts, 2 screws and the console box.
11. REMOVE CENTER CLUSTER FINISH PANEL
Using a screwdriver, remove the panel, then disconnect the
connector.
HINT:
Tape the screwdriver tip before using.
12. REMOVE FRONT CONSOLE BOX
Remove the 2 screws and the front console box.
13. REMOVE RADIO ASSEMBLY
14. REMOVE A/C CONTROL ASSEMBLY
(See page AC±82)
15. REMOVE HAZARD WARNING SWITCH
16. REMOVE CLUSTER FINISH PANEL
(a) Remove the 2 screws.
(b) Using a screwdriver, remove the panel.
HINT:
Tape the screwdriver tip before use.
17. REMOVE COMBINATION METER
18. REMOVE REMOTE CONTROL MIRROR HOLE BASE
Page 2036 of 4770

W03509
N20991
N20992
N20993
± BODYINSTRUMENT PANEL
BO±77
2425 Author: Date:
19. REMOVE FRONT PASSENGER AIRBAG ASSEMBLY
(See page RS±28)
Remove the 2 bolts, 4 nuts and the front passenger airbag as-
sembly.
Torque:
Bolt: 20 N´m (200 kgf´cm, 14 ft´lbf)
CAUTION:
Store the front passenger airbag door facing upward
(never downward).
Never disassemble the front passenger airbag as-
sembly.
NOTICE:
The 2 bolts to the instrument panel have been anti±rust
treated. After removing the front passenger airbag assem-
bly, always replace the bolts and nuts with new ones.
20. REMOVE No.1 AND No.2 INSTRUMENT PANEL
BRACKETS
Remove the 4 bolts and the No.1 and No.2 panel brackets.
21. REMOVE NO.2 SIDE DEFROSTER NOZZLE
22. REMOVE INSTRUMENT PANEL ASSEMBLY
(a) Disconnect the connectors from the LH and RH connector
holders.
(b) Remove the bolts holding the ground wire to the body.
(c) Remove the connector holder from the body.
(d) Disconnect the connectors.
(e) Remove the bolt holding the ground wire to the No.2
instrument panel brace.
Page 2037 of 4770

N20994
N20995
N20996
N20997
BO±78
± BODYINSTRUMENT PANEL
2426 Author: Date:
(f) Remove the bolt, nut, screw and the instrument panel as-
sembly.
23. REMOVE INSTRUMENT PANEL BRACES
(a) Remove the wire brackets and connector.
(b) Remove the bolt and connector from the No.1 instrument
panel brace.
(c) w/ Wireless Control:
Remove the nut and the wireless control unit from the
No.1 instrument panel brace.
(d) Remove the nut holding the radio antenna to the No.2
instrument panel brace.
(e) Remove a nut and brace mount bracket.
(f) Remove the 6 nuts, 2 bolts and No.1 and No.2 instrument
panel braces.
24. REMOVE INSTRUMENT PANEL REINFORCEMENT
(a) Remove the connectors from the steering column tube.
(b) Remove the 4 wire brackets and connectors.
(c) Remove the 2 nuts and bolt holding the No.1 Junction Box
(J/B) to the reinforcement.
(d) Remove the 4 nuts and the steering column from the rein-
forcement.
(e) Remove the brake pedal spring from the reinforcement
and brake pedal.
(f) Remove the 4 nuts, 3 bolts and the reinforcement.
Page 2038 of 4770
BO0MD±01
N21124
± BODYINSTRUMENT PANEL
BO±79
2427 Author: Date:
DISASSEMBLY
1. REMOVE THESE PARTS:
(a) No.1 defroster nozzle garnish
(b) No.1 defroster nozzle
(c) RH side defroster duct nozzle
(d) No.1 side defroster duct nozzle
(e) No.1 heater duct to register
(f) No.2 heater duct to register
(g) No.2 register assembly
(h) No.3 register assembly
(i) No.1 register assembly
2. REMOVE INSTRUMENT PANEL WIRE HARNESS
Remove the 2 brackets, 8 clips and wire harness.
3. REMOVE INSTRUMENT PANEL CENTER BRACKET
4. REMOVE THESE PARTS:
(a) Clock unit
(b) Glove box light assembly
Page 2039 of 4770
BO0ME±01
BO±80
± BODYINSTRUMENT PANEL
2428 Author: Date:
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO±79).
Page 2040 of 4770
BO0MF±01
± BODYINSTRUMENT PANEL
BO±81
2429 Author: Date:
INSTALLATION
Reassembly is in the reverse order of removal (See page BO±75).
