Page 689 of 4770

TOYOTA CAMRY 2000 Service Repair Manual INSTALLATION Body Sealer Braze (Both sides) [Foamed Material Application Areas] 1. Before temporarily installing the new parts, apply body sealer to the windshield header panel, roof panel reinforceme

Page 690 of 4770

TOYOTA CAMRY 2000 Service Repair Manual ROOF PANEL: w/ Moon Roof REMOVAL Arc Brazing (Both sides) 1. Grind off the roof panel tip at the quarter panel arc brazing connection with a cut grinder. BODY PANEL REPLACEMENTRE-68

Page 691 of 4770

TOYOTA CAMRY 2000 Service Repair Manual INSTALLATION Body Sealer Braze (Both sides) [Foamed Material Application Areas] 1. Before temporarily installing the new parts, apply body sealer to the windshield header panel, roof paneI reinforceme

Page 692 of 4770

TOYOTA CAMRY 2000 Service Repair Manual mm in. 3.8 4.1 4.5 5.0 6.0 6.2 8.0 8.8 19.80.150 0.161 0.177 0.197 0.236 0.244 0.315 0.346 0.780 FIT STANDARDS After doors and the engine hood are installed, be sure to perform fit adjustment to preve

Page 693 of 4770

TOYOTA CAMRY 2000 Service Repair Manual For anti±corrosion measures, always apply the weld±through primer (spot sealer) to welding sur- faces where the paint film has been removed. HINT: Apply the weld±through primer (spot sealer) so tha

Page 694 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Steel MetalUndercoat (ED Primer) Anti±Chipping PaintSecond Coat Steel Metal Undercoat (ED Primer) Second Coat Top Coat ANTI±RUST TREATMENT AFTER PAINTING PROCESS 1. ANTI±RUST AGENT (WAX) APPLICATIO

Page 695 of 4770

TOYOTA CAMRY 2000 Service Repair Manual BODY PANEL UNDERCOATING AREAS HINT: 1. First wipe off any dirt, grease or oil with a rag soaked in a grease, wax and silicone remover. 2. Cover the surrounding areas with masking paper to avoid coatin

Page 696 of 4770

TOYOTA CAMRY 2000 Service Repair Manual BODY PANEL SEALING AREAS HINT: 1. Prior to applying body sealer, clean the area with a rag soaked in a grease, wax and silicone remover. 2. If weld±through primer was used, first wipe off any excess
