Page 657 of 4770

TOYOTA CAMRY 2000 Service Repair Manual mm in. 10 0.39 INSTALLATION Butt Weld Body Sealer Butt Weld about 10 mm Body SealerDo not close the drain hole. Body Sealer Cloth Tape 30° Hemming Tool 1. Before temporarily installing the new parts,

Page 658 of 4770

TOYOTA CAMRY 2000 Service Repair Manual mm in. 75 1502.95 5.91 ROCKER OUTER PANEL (CUT) REMOVAL Cut and Join Location 75 mm 150 mm Cut and Join Location Cut and Join Location [Cut Location for Supply Parts] [Cut and Join Location] [Cut and

Page 659 of 4770

TOYOTA CAMRY 2000 Service Repair Manual INSTALLATION Butt Weld Butt Weld Butt Weld 1. Temporarily install the new parts and check the fit of the front door and rear door. BODY PANEL REPLACEMENTRE-37

Page 660 of 4770

TOYOTA CAMRY 2000 Service Repair Manual QUARTER PANEL (CUT) REMOVAL [Cut and Join Location] Make Incision Cut and Join Location 200 mm Fuel Filler Opening Lid 2. Replace the fuel filler opening lid at the same time as the quarter panel. 1.

Page 661 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Braze Braze BODY PANEL REPLACEMENTRE-39

Page 662 of 4770

TOYOTA CAMRY 2000 Service Repair Manual mm in. 5 0.20 INSTALLATION [Foamed Material Application Areas] Body Sealer Butt Weld about 5 mm [Foamed Material Application Areas] Body Sealer Braze 2. Temporarily install the new parts and check the

Page 663 of 4770

TOYOTA CAMRY 2000 Service Repair Manual Fuel Filler Opening Lid Braze Waterproof Rivet Butt Weld 3. Attach the fuel filler opening lid by rivets to the quarter panel. HINT: 1) Use waterproof rivets. 2) Refer to the introduction when install

Page 664 of 4770

TOYOTA CAMRY 2000 Service Repair Manual QUARTER PANEL (CUT±P) REMOVAL Cut and Join Location Cut and Join Location 1. Cut and join the panels at the location shown above. BODY PANEL REPLACEMENTRE-42
